Icom IC-M302 Service Manual page 21

6-2 HM-141
[MAIN UNIT]
REF ORDER
NO. NO.
R1 7010007590 RESISTOR
R2 7010007600 RESISTOR
R3 7010007610 RESISTOR
R4 7010007620 RESISTOR
C1 4030018660 S.CERAMIC
C2 4030018670 S.CERAMIC
MC1 7700002640 MICROPHONE
S1 2260002780 SWITCH
S2 2260002790 SWITCH
S3 2260002790 SWITCH
S4 2260002790 SWITCH
W1 9027150010 WIRE
W2 9027150010 WIRE
W3 9027150020 WIRE
W4 9027150030 WIRE
EP1 0910056860 PCB
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
DESCRIPTION M.
RD1/4S 123JTA <FG>
RD1/4 682JTA <FG>
RD1/4 153JTA <FG>
RD1/4 333JTA <FG>
C1608 JB 1H 223K-T <FG>
C1608 CH 1H 471J <FG>
KUC3523-040245 <FG>
SKHHLPA010 <FG>
SKHHAMA010 <FG>
SKHHAMA010 <FG>
SKHHAMA010 <FG>
71/98/010/X98/X98 <FG>
71/98/010/X98/X98 <FG>
24/00/020/W01/W01 <FG>
24/04/020/W01/W01 <FG>
B 6067
S.=Surface mount
T
T
T
T
B
T
T
B
T
T
T
B
B
T
T
6 - 5
