Page 3
Before carrying out the installation, read the instructions and take account of the product’s specific mounting location. Do not open up, dismantle, alter or modify the device except where specifically required to do so by the instructions. All Legrand products must be opened and repaired ex- clusively by personnel trained and approved by Legrand.
2. Overview and controls This section provides information about front panel and rear panel. When you install the DVR, refer to this part first. 2.1 Front Panel NVR 4 306 80 ENTER SHIFT Front panel buttons information: Name Icon Function...
Page 6
Name Icon Function One-window monitor mode, click on this button to display assistant function: PTZ control and image color. Backspace function: in numeral control or text control, press it for 1.5 seconds to delete the previous character before the cursor. In motion detection setup, working with Fn and direction keys to ENTER realize setup.
2.2 Front Panel NVR 4 306 81 Name Icon Function Power button, press this button for three seconds to boot up or Power button shut down DVR. Number buttons 0 - 9 Camera select/numeric button. 0 to 9 Input number more than If you want to input a number more than 10, click on this button -/-- and you can input more than one number.
Page 8
Name Icon Function Play previous In playback mode, playback the previous video. In normal playback or pause mode, click on this button to reverse Reverse/Pause Playback. In reverse playback, click this button to pause playback. In playback mode, playback the next video. Play Next In menu setup, go to down ward of the dropdown list.
2.3 Rear Panel NVR 4 306 80 Rear panel is shown below. Main power switch. Power supply. Network port. RS232 port. It is for general COM debug to configure IP adress or transfer transparent COM data. USB port to connect USB key or mousse.
2.6 Remote control Name Icon Function When you have several DVR, input the device number you have Address set in MAIN MENU -> SETTING -> GENERAL, field “DVR N°”, so you can control it. Multiple-window switch Switch between one-window and multiple-window. Input password, channel or switch channel.
Page 12
Name Icon Fonction Activate current control, modify setup. Increase/decrease Up/down number. Assistant function such as PTZ menu. Shift current activated control. Left/right When playback, click these buttons to control playback bar. Forward Various forward speeds and normal speed playback. Previous Please refer to the previous in the front panel.
2.7 Mouse operation Please refer to the following sheet for mouse operation instruction. Left click System pops up password input dialogue box if you have not logged in. mouse: In real-time monitor mode, you can go to the main menu. When you have selected one menu item, left click on the mouse to view menu content.
2.8 Front Panel Click “Fn” key and use direction keys to select number you want. Click on “Enter” button to valid. Use > or < to shift between small letter and capital letter.
3 Installation and Connections Note: All the installation and operations here should conform to your local electric safety rules. 3.1 HDD Installation 4 306 80) The DVR is provided with a SATA HDD and it can be equipped with maximum 8 SATA HDDs. Recommended models are: - SEAGATE Barracuda series - SEAGATE SV35 series...
3.2 HDD Installation (NVR 4 306 81) The DVR is provided with a SATA HDD and it can be equipped with maximum 8 SATA HDDs. Recommended models are: - SEAGATE Barracuda series - SEAGATE SV35 series - WESTERN DIGITAL Caviar series. Follow the instructions below to install hard disk.
3.3 Rack Installation (4 306 81) The DVR occupies 2 rack units of vertical rack space. Use twelve screws to fix the unit. • Please make sure the indoor temperature is below 35°C (95°f). • Please make sure there is 15cm (6 inches) space around the device to guarantee sound ventilation. •...
3.6 Connecting Audio Input & Output, Bidirectional Audio (4 306 81) Audio Input The DVR audio inputs adopt BNC port. Device supports bidirectional talk via BNC. Due to high impedance of audio input, use active sound pick-up. Audio transmission is similar to video transmission.
3.7 Alarm Input and Output Connection Refer to the following sheet for alarm input and output connection. You can select two alarm input types: Normal Open (NO) and Normal Close (NC). Alarm Output Alarm Input 1. Alarm input a. Make sure alarm input mode is grounding alarm input. b.
Page 20
Alarm Input and Output Details You can refer to the following sheet for input and output alarm information. From the left to Alarm input 1 to Alarm input 16. The alarm becomes active in low voltage. the right,: 1, 2, 3, 4, 5, 6, 7, 8, 9,10, 11, 12, 13, 14, 15, 16...
Page 21
Alarm Output Port Provide power to peripheral alarm device. • To avoid overloading, please read the following relay parameters sheet carefully. • Controllable +12V, can be used to provide power to devices such as reset smoke sensor. • RS485 A/B cable is for the A/B cable of the decoder PTZ. •...
3.8 RS232 You can connect the DVR with POS or Keyboard through RS232. Please contact the technical support to implement this function. 3.9 RS485 When the DVR receives a camera control command, it transmits that command up the cable to the PTZ device. RS485 is a single-direction protocol;...
4 Graphic User Interface Operations Connect the device to the monitor and to the cameras, insert the mouse and connect the power cable. Push the on/off button in the rear panel and then you can see the analog video output. You can use the mouse to imple- ment some simple GUI operation.
Preview Zoom Function: Move your mouse to the left top corner of the preview interface; you can see the preview zoom button. You see a hook icon on the picture below, left click on this one. Now you have enabled the preview zoom function. You can drag the mouse to zoom in the image.
4.3 Right Click Menu After you logged in the device, a right click mouse, display the short cut menu. You can set windows display, PTZ control, video color, search record etc. The live view window includes 1/4/9 (4 306 80) and 16 (4 306 81). Important : Before starting record or setting action, set the language, the date and time system in MAIN MENU ->...
Page 26
Manual record operations Use mouse or direction key to highlight a channel number, means it is not in recording status, means is in recording status. There are three statuses: Schedule/Manual/Stop. Statuses Functions Schedule Channel will record as you have previously set in MAIN MENU -> SETTING -> SCHEDULE. All channel Schedule record: highlight “All”...
4.6 Schedule Go to MAIN MENU ->SETTING -> SCHEDULE The default schedule setting is 24 hours regular mode. You can define 6 periods for each week days per channel. If “All” “Week Day” is selected, the periods apply for all the week days. Number Item Function...
4.7 Research recording and playback Click search button in the main menu, search interface is shown as below. Usually there are three file types: - R: Regular recording file. - A: External alarm recording file. - M: Motion detection recording file Please refer to the following sheet for more information.
Page 29
Name Function - Double click it, you can view the picture/record file list of current day. - The file list is to display the first channel of the record file. - The system can display max 128 files in one time. Use the or the mouse to view the file.
Page 30
Name Function The option includes: 24H, 12H, 1H and 30M. The smaller the unit, the larger the zoom rate. You can accurately set the time in the time bar to playback the record. Time bar unit The time bar is beginning with 0 o'clock when you are setting the configuration. The time bar zooms in the period of the current playback time when you are playing the file.
Page 31
4.8 PAN / TILT / ZOOM In the short cut menu select “Pan/Tilt/Zoom”, the motorized camera view display and the PTZ control interface appears. Number Item Function Speed Value ranges from 1 to 8. Set the camera movement speed. Zoom Click icon to adjust zoom.
Page 32
Preset Preset Setup 1 - Use eight direction arrows to adjust camera to the proper position. 2 - Click on the “Set” button in the interface below and enter the preset number you want. 3 - The system saves the speed dome position and the preset number when you click on the “Set” button. You can set the following items: •...
Page 33
To enter in OSD menu, click "Menu". The OSD menu displays. OSD menu control (On-Screen Display) : - Use the down and up direction arrows to select parameter. - Save the value and exit with - focus “near”. - Modify with the up and down arrow. - Cancel the value with - focus “far”.
5.4 Info Here is for you to view system information. There are total five items: HDD INFO (hard disk information), BPS (data stream statistics), LOG, VERSION, and ONLINE USERS. 5.4.1 HDD Info Here is to list hard disk type, total space, free space, video start time and status. means current HDD is normal means there is error means there is no HDD...
Page 36
5.4.2 BPS You can see current video data stream in Kilo Bytes per second (KB/s) and occupied hard disk storage in Mega Bytes per hour (MB/h). 5.4.3 LOG You can see the system log file. The log file contents 1024 lines and it lists the following information. The log types include system operation, configuration operation, data management, alarm event, record operation, log clear and etc.
Page 37
5.4.4 VERSION Here you can view some version information and upgrade the system. Channels • Alarm in • Alarm out • System version: • Build Date • • Serial No • USB Upgrade instructions 1) Rename the firmware file to “update.bin”. e.g.: rename “General_DVR0804LB-U_Eng_P_V2.602.0000.1.20080723.bin”...
5.4.5 ONLINE USERS Here you can manage online users. You can disconnect one user or block one user if you have proper system right. Max disconnection setup is 65535 seconds 5.5 Setting MAIN MENU -> SETTING interface is shown below. 5.5.1 General ...
Page 39
1 - System time: Here is for you to set system time 2 - Date format: There are three types: YYYYY-MM-DD: MM-DD-YYYYY or DD-MM-YYYY. 3 - Date separator: There are three denotations to separate date: dot, beeline and solidus. 4 - DST: Here you can set DST time and date.
Page 40
5.5.2 Encode ENCODE setting includes the following items. 1 - Channel: Select the channel you want. 2 - Type: Select the recording mode associated with the current setting 3 - Compression: System only supports H.264. 4 - Resolution: System supports various resolutions, you can select from the dropdown list. The main stream supports D1/HD1/BCIF/CIF/QCIF and the extra stream supports CIF/QCIF .
Page 41
5.5.3 Menu Calendrier After system booted up, it is in default 24-hour regular mode. You can set record type and time in the MAIN MENU -> SETTING -> SCHEDULE, 1 - Channel: select the channel number first. You can select “all” if you want to set for the whole channels. 2 - Week day: there are eight options: ranges from Saturday to Sunday and all.
Page 42
Quick Setup : Copy and paste This function allows you to copy one channel setting to another. After set a channel, you can click on “Paste” button, turn to another channel and then click on the “Copy” button. The schedule and the setting are the same for both channels. You can set for one channel and then click on “Save’...
Page 43
2- In the MAIN MENU -> ADVANCED -> HDD MANAGE, you can set one or more disk(s) as redundant. You can select from the drop down list. Note: only read/write disk or read-only disk can backup file and support file search function, so you need to set at least one read-write disk otherwise you cannot record video.
Page 44
5.5.4 RS232 RS232 interface is shown below. There are five items. See below 1 - Function: You can select various devices. 2 - Baud rate: Select the proper baud rate. 3 - Data bit: You can select proper data bit. The value ranges from 5 to 8. 4 - Stop bit: There are two values: 1 / 2.
Page 45
Subnet Mask / Gateway If you have not enabled DHCP function, IP/Subnet mask/ Gateway display as zero. You need to disable DHCP function to view current IP information. Besides, when PPPoE is operating, you cannot modify IP/Sub- net mask /Gateway. TCP port: Default value is 37777.
Page 46
2) NTP Setup You need to install SNTP server (Such as Absolute Time Server) in your PC first. In Windows XP OS, you can use command “net start w32time” to boot up NTP service. Server IP: input the NTP server address or name. •...
Page 47
IP multiple to cast group address • -224.0.0.0-239.255.255.255 -“D” address space The higher four-bit of the first byte=”1110” • Reserved local multiple cast group address • -224.0.0.0-224.0.0.255 -TTL=1 When sending out telegraph -For example 224.0.0.1 All systems in the sub-net 224.0.0.2 All routers in the sub-net 224.0.0.4...
Page 48
After rebooting, open IE and input as below: Please Note DDNS includes: CN99 DDNS - NO-IP DDNS - Private DDNS - and Dyndns DDNS. All the DDNS can be valid at the same time. 6) UPnP 7) Email EMAIL interface is shown below ...
Page 49
5.5.6 Alarm Setup and Alarm Activation Avant de commencer, s’assurer que les dispositifs d’alarme (ex. buzzer) sont correctement raccordés. Accéder à l’interface de configuration des alarmes par MAIN MENU -> SETTING -> ALARM / MENU PRINCIPAL -> PARAMETRES -> ALARME. Voir ci-dessous : 8 - 9 - 10 1- Event Type There are two types.
Page 50
5 - Anti-dither: System only memorizes one event during the anti-dither period. The value ranges is from 1 to 600 seconds. 6 - Alarm Out : When alarm occurred, system enables peripheral alarm devices. 7 - Latch : You can set delay duration, system automatically delays specified seconds in turning off alarm and activated output after external alarm cancelled.
Page 51
5.5.7 Detect / Détection In the MAIN MENU -> SETTING -> DETECT, you can see motion detection interface. You can see in the dropdown list three detection types: - Motion Detect, - Video Loss, - Camera Masking. 1) Motion Detect Analysis the video, system enable motion detection alarm when it detects the motion signal reached the speci- fied sensitivity.
Page 52
4 - Alarm Out: When alarm occurred, system enables peripheral alarm devices. 5 - Latch: After higger alarm, alarm output will change state during the time set. The value range is from 1 to 300 seconds. 6 - Show Message System can pop up a message to alarm you in the local host screen if you enabled this function.
Page 53
Notes: - In motion detection mode, you cannot use copy/paste to set channel setup since the video in each channel may not be the same. - To activate motion detection go to MAIN MENU -> SETTING -> SCHEDULE and select “MD” or “MD Alarm” for “Channel”...
Page 54
1 - Transparency You can adjust the transparency of the menu display. The value ranges from 128 to 255. 2 - Channel name You can modify the channel name. All your modifications are only applied to local end. System max support 25 characters. ...
Page 55
5.5.10 Default Click on the “DEFAULT” icon, system pops up a dialogue box. You can highlight to restore default factory setup. You can “Select all” settings or select menu by menu, General, Encode, Schedule, RS232, Network, Alarm, Detect, Pan/tilt/zoom, Display and Channel name. After all the setups please click on the “Save”...
5.6 Advanced Click on the ADVANCED icon in the main window, the interface is shown below. There are ten function keys: HDD MANAGE, ABNORMALITY, ALARM OUTPUT, RECORD, ACCOUNT, AUTO MAINTAIN, TV ADJUST, VIDEO MATRIX, TEXT OVERLAY and CONFIG BACKUP . 5.6.1 HDD manage You can see and implement hard disk management.
Page 57
5.6.2 Abnormality The abnormality interface is shown above. You can associate an event type and one or several alarm. 1 - Event type There are several options for you such as “Disk error”, “No disk”, “No space”, “IP con- flict”...
Page 58
5.6.5 Account You can implement the account management. 1 - Add/Modify User Click on “Add user” button, the interface is shown below. Input the user name and the password select the group it belongs to from the dropdown list. Then you can check the corresponding rights for current user.
Page 59
3 - Modify Password Click on “Modify Password” button, the interface is shown below. Select the account from the dropdown list, input the old password and then input the new password twice. Click the “Save” button to confirm current modification. For the users of user account right, it can modify password of other users.
Page 60
5.6.6 Auto Maintain You can set auto-reboot time for the specified day from the dropdown list and you can auto-delete old files setup it means the record time. After all the setups please click on the “Save” button, system goes back to the previous menu. ...
5.7 Backup / Exportation The DVR supports USB device backup and network download. Here we introduce USB backup and eSATA backup. You can refer to Chapter on Web Client Operation for network download backup operation. In SEARCH menu you can export or backup the specific records or a part of a record you have seen (refer to SEARCH menu) and in MAIN MENU ->...
Page 62
2 - “Backup” button Select backup device and then select channel, file start time and end time. Click on “Add” button, system begins to search. All matched files are listed below. System automatically calculates the needed and remained capacities. System only backups files with a √ before record name. You can use “Fn“ button and Up/Down arrow on the remote control or on the front panel to select and deselect a record.
5.8 Shutdown There are two ways to logout - One is from the menu option : in the “MAIN MENU”, select “SHUTDOWN” icon, system pops up a dialogue box and you can select: Logout menu user: log out menu. You need to input password when you login the next time. •...
6. Auxiliary Menu Surveillance mode, right click mouse. The interface is shown below: 6.1 View 1, 4, 9, 16 Refer to DISPLAY menu (MAIN MENU -> SETTING -> DISPLAY) chapter 5.5.9 6.2 Pan/Tilt/Zoom Menu Refer to Pan/Tilt/Zoom chapter 5.5.8 6.3 Color Setting You can set the camera color according to two defined periods like the day and the night.
7 Mobile install You can find the firmwares for Mobile Phone Symbian, Blackberry and Androïd Windows Mobile on the CD. 7.1 Androïd mobile phone and IPhone 3G (8G) This software has the following features: • Use mobile phone to view real-time video. •...
Page 66
4) Using the application for IPhone and Androïd Click on “DMSS” button, the initial interface is shown as below. Please refer to the following tab for detailed information. PTZ up PTZ right Zoom in Focus + Aperture + Channel 1 Channel 2 PTZ down...
Page 67
6) Click the icon to switch between the normal screen and then full screen. Normal screen Full screen When you knife-hold the iPhone, system goes to the full-screen automatically. 7) Select the corresponding channel name, system can open the specified channel and then play the video automatically.
7.2 Blackberry mobile phone 7.2.1 Environment Just support Blackberry Version 4.6.0 and 5.0 • The connected devices shall support RTSP service. • You can download the firmware from the CD. • 7.2.2 Mobile Phone Software Please refer to the Blackberry mobile phone user’s manual to install the software to the mobile phone. Usually you need to use the Blackberry desktop manager to install.
Page 69
Mobile phone monitor software can remember the recent login device information, so that you can login conveniently the next time. If you cannot login, please check: • Input information is valid. • Server is running properly now. • Network connection is OK (please access a website via browser to make sure you have connected to the Internet.) 7.2.3 Main Interface When you log in you can see the interface below with the available channels.
Page 70
7.2.5 PTZ Control Please select the PTZ button to go to the PTZ operation interface. You can use the rolling ball to select the corresponding button here. In the full-screen mode, you can use the rolling ball directly to control the PTZ direction. In video monitor mode, you can use E/S/X/F to realize the up/down/left/right PTZ operation.
Page 71
7.2.7 Exit Select “Exit” button, you can see the following interface. Select the “Yes” button; you can exit the mobile phone monitor software. Note This user’s manual is for reference only. Slight difference may be found in user interface. All the designs and software here are subject to change without prior written notice. ...
7.3 Symbian Mobile Phone 7.3.1 Environment Technically speaking, this software can support all Symbian S60 3rd Edition Symbian S60 3rd Edition FP1, Symbian S60 3rd Edition FP2, Symbian S60 5th OS mobile phones. We recommend the mobile phone such as E71, N82, N85, 5530XM that have passed our test.
Page 73
7.3.4 Software Login Click login button, you can see the following interface. Mobile phone monitor software can remember the recent login device information, so that you can login conve- niently the next time. If you can not login, please check if: - Input information is valid.
Page 74
7.3.6 PTZ Control The running function depends on the mobile phone. Use the navigation button to select the PTZ item and then click the navigation button; you can see the following interface. Use the navigation button to select the operation button you desire and then click the navigation button again; you can realize the corresponding function.
7.4 Windows Mobile Phone 7.4.1 Environment This software supports Windows Mobile OS (5.0 or higher); Please refer to the following brand list: - Dopod: C730, HTC Touch, HKC Pearl, HTC6800, HTC6900, HTC6850, P3450, P4550, S1, S420, S730, Touch; , LG KC1, KS20, 830, 838, 900, Athena, C800(C858), CHT 9000, CHT 9100, D600, D802, D810, E806c, M700, MUSE, P800W, U1000;...
Page 76
After software installation, you can see the following interface. 7.4.3 Surveillance Software In the mobile phone, from Start to the Program, you can see the software shortcut menu. Its icon is (DMSS). Click DMSS button Input Device IP , Device port, User name and Password.
Page 77
7.4.4 Software Login Click login button, you can see the following interface. Mobile phone monitor software can remember the recent login device information, so that you can login conveniently the next time. If you can not login, please check: - Input information is valid. - Server is running properly now.
Page 78
7.4.6 PTZ Control There are two ways for you to control PTZ. - In the full-screen mode (or you have open the PTZ control interface), you can use the direction buttons in the mobile phone to control the PTZ direction. - In non-real-time monitor mode, you can click the PTZ button to go to the PTZ control interface.
7.5 DVR Setup Please set the connected DVR encode information to make the device suitable for the mobile phone monitor. You can go to the DVR Web or go to the DVR local end to complete the setup. In this user’s manual, we introdu- ce how to finish setup at the local end.
8. Web client operation 8.1 Network Connection This device supports Web access and management via PC. Web includes several modules including monitor channel list, record search, alarm setup, system configuration, PTZ control, monitor window, etc. IP camera factory default setup: - IP address: 192.168.1.108.
Page 81
After installation, the interface is shown below. Please input your user name and password. Default factory name is “admin” and password is “admin”. Note: For security reasons, please modify your password after you first login. After you are logged in, you can see the main window.
8.2 Connexion After you are logged in, you can see the main window. This main window is divided in the following sections: - Section 1 with five tab: “SEARCH”, “ALARM”, “CONFIGURATION”, “ABOUT” and “LOGOUT”. - Section 2 with all the channel names and four function buttons: “Open/Close All”, “Start/End Dialogue”, “Local Play”, “Refresh”.
Page 83
On the top right corner, there are six function buttons. Digital zoom : Click on this button and left drag the mouse to zoom in the zone. A right click mouse system restores original status. Change display mode: resize or switch to full screen mode. Local record: When you click on “local record”...
Page 84
Section 3: there are PTZ, “color” tab and “more” tab” where you can select “picture path” and “record path” and also you can reboot the DVR. Before PTZ operation, please make sure you have properly set PTZ protocol. In MAIN MENU -> SETTING -> PAN/TILT/ZOOM.
Page 85
Click “PTZ setup” button you can see the following interface. - Auto Scan (Not available) - Pattern (Not available) - Preset Move the camera to your desired location and then input preset value. Click “Add” button, you have set one preset. - Auto tour (Not available) - Assistant:...
Page 86
Color Click on “Color” tab in section 3. You have this interface. Here you can select one channel and then adjust its brightness, contrast, hue and saturation. (Current channel border becomes green). Or you can click reset button to use system default setup. ...
Page 87
Click on “reboot” button, system pops up the following dialogue box Click on “OK” to reboot. If there is local use logged in the system menu, or the Web logged in user has no right to reboot the device system pops up a dialogue box to alert you.
8.3 CONFIG / Configuration (section 1) System Information Version Information You can see the device hardware features and the software version information. HDD information You can see local storage status and network status including, free capacity and total capacity.
Page 89
Here you can see the system log. Click on the “Backup” button, you have this interface. Refer to the following tab for log parameter information. Parameter Function Type Log types include: system operation, configuration operation, data ma- nagement, alarm event, record operation, user management, log clear and file operation.
Page 90
System Configuration Click on “Save” button to save your current setup. General Setup You can set system time, record length, video format and etc.. Refer to the following tab for detailed information. Parameter Function Here is for you to modify system time. Please click on “Save” button after your comple- System Time ted modification.
Page 91
There are two options: stop recording or overwrite the previous files when HDD is full. HDD Full When current working HDD is overwriting or it is full now, system stops record. If current working HDD is full now, system goes to overwrite the previous file. Pack Here you can select record time.
Page 92
Parameter Function Channel Select a channel first. Input pre-record value here. Pre-record System can record the three to five seconds video before activating the record operation into the file. (Depends on data size). Click on “Set” button, you can go to the corresponding setup interface. Set schedule period and then select corresponding record or schedule, motion detection and alarm.
Page 93
RS232 The RS232 is the following interface. Parameter Function RS232 There are two options: COM 01 and keyboard. Function Console is to upgrade the program or debug via COM or mini terminal software. Keyboard: COM control protocol. You can use keyboard to control DVR via COM. Data Bit The value ranges from 5 to 8.
Page 94
Network Network is the following interface. Parameter Function Ethernet Please select the network card first. DHCP Dynamically get IP address. You can get the device IP from the DHCP server if you enabled this function. TCP Port Default value is 37777. HTTP Port Default value is 80.
Page 95
a- Email The email interface is the following interface Parameter Function SMTP Server Input server address and then enable this function. Port Input port value here. User Name The sender email account user name. Password The sender email account password. Sender Sender email address.
Page 96
b- DDNS The DDNS interface is shown Parameter Function You can select DDNS protocol from the dropdown list and then Server Type enable DDNS function. The private DDNS protocol means you use your self-defined private protocol to realize DDNS function. Server IP DDNS server IP address.
Page 97
c- NAS NAS interface is shown below. Parameter Function NAS enable Please select network storage protocol and then enable NAS function. Server IP Input remote storage server IP address. Port Input Remote storage server port number. User Name Log in user account. The file length you upload to the FTP .
Page 98
d- NTP The NTP interface is shown below. Here you can realize network time synchronization. Enable current function and then input server IP , port num- ber, time zone and update interval. NTP only supports TCP transmission and its port shall be 123.The update interval ranges from 1 to 65535.
Page 99
e- Alarm Center Alarm center interface is shown as below. The alarm signal can be uploaded to the alarm centre when there is local alarm. Set the corresponding parameters such as server IP , port and etc. The system can send out the data as the protocol defined to the client end. Alarm Alarm setup interface is shown below Make sure you have connected the corresponding alarm output device such as the light, buzzer and etc.
Page 100
Parameter Function It includes local alarm/network alarm. Event Local alarm: Device detects alarm from input port. Type Network: Device detects alarm from network. Alarm in Select corresponding alarm channel. Enable You need to draw a circle here so that system can detect the alarm signal. There are two options: normal open and normal close.
Page 101
Detect Analysis the video, system enable motion detection alarm when it detects the motion signal reached the speci- fied sensitivity. The detection interface is shown below. ...
Page 102
Parameter Function Event There are three types: Motion detection/video loss/Camera Masking. Type Channel Select channel name from the dropdown list. Enable You need to draw a circle to enable motion detection function. Sensitivity There are six levels. The sixth level has the highest sensitivity. Region: If you select motion detection type, you can click this button to set motion detection zone.
Page 103
PTZ interface is shown below Before operations make sure you have set the speed dome address. The DVR and the speed dome connection are OK. Parameter Function Channel You can select monitor channel from the dropdown list. Protocol Select the corresponding dome protocol (such as PELCOD). Address Set corresponding dome address.
Page 104
Default & Backup Default: Restore factory default setup. You can select corresponding items. Backup: Export current configuration to local PC or import configuration from current PC. System cannot restore some information such as network IP address. Parameter Function Select All Restore factory default setup.
Page 105
Advanced HDD Management HDD management includes net storage management and local storage management. Please select the storage device first and then you can see the items on your right become valid. You can check the corresponding items. Parameter Function Format Clear data in the disk.
Page 106
Alarm I/O Here you can search alarm output status Important The alarm output port should not be connected to high power load directly (It shall be less than 1A) to avoid high current which may result in relay damage. Please use the contactor to realize the connection between the alarm output port and the load.
Page 107
Record Record control interface is shown below. Parameter Function Auto System enables auto record function as you set in record schedule setup. Manual Enable corresponding channel to record no matter what period applied in the record setup. Stop Stop current channel record no matter what period applied in the record setup. Operation here is the same as Record chapter.
Page 108
Auto Maintenance You can select auto reboot and auto delete old files interval from the dropdown list.
Page 109
Abnormity The abnormity interface is shown as below. Parameter Function Event Type The abnormal events include: no disk, no space, disk error, net error. • You need to draw a circle to enable this function. • Alarm Out The corresponding alarm activation output channel when alarm occurs, There are six channels.
Page 110
Remote Device Paramètre Fonction Channel Select the local device channel number to connect to the remote device. You need to highlight the enable item to activate this function. Now you can see remote device type, IP address and etc. IP address, port, Input remote device IP adress, port number, remote device channel number and remote channel account.
Page 111
Auto Register Auto register interface is shown as below Parameter Function Enable Enable auto register function. Device management server number. Device management server IP address. Port Server port number. Device ID Device ID in the device management server.
8.4 Search (section 1) Click search button, you can see an interface is shown as in picture below. Network Download The record type includes the general record, alarm record, motion detect record, local record, picture, card number record. Please select record playback mode, and then select start time, end time and channel. Then please click on “Search”...
Page 113
Now you can see system begins download and the download button becomes stop button. You can click it to terminate current operation. At the bottom of the interface, there is a process bar for your reference. When download completed, you can see a dialogue box shown below. Please click on “OK” to exit. ...
Remote Backup If you want to download the file(s) to your USB device (flash disk/burner) connected to the DVR, you can click the “Search” button at the bottom of the picture below. You can view the devices available and their corresponding information in the bottom pane.
Page 115
Type Parameter Function Type Record Search general record, alarm record and motion detection record. Alarm Search alarm record. Motion Search motion detection record. Detection Local Search local record. Snapshot Search snapshot file. Card This function is not available in current device. Item Begin Set the file start time.
Playback device IP address and channel number. Playback control bar 8.5 Alarm Click alarm function, you can see an interface is shown as in Figure below. Here you can set device alarm type and alarm sound setup. ...
Please make sure current device can upload the alarm. Type Parameter Function Alarm Video loss System alarms when video loss occurs. Type Motion detection System alarms when motion detection alarm occurs. Disk full System alarms when disk is full. Disk error System alarms when disk error occurs.
10. Specifications Specifications 4 306 80 4 306 81 Main Processor High performance embedded microprocessor Operating System Embedded LINUX System System Resources Pentaplex function: live, recording, playback, backup & remote access Control Mode Front panel, USB mouse, IR remote control, Keyboard, Network Input 8 channels IP 16 channels IP...
Page 120
Specifications 4 306 80 4 306 81 Delivered Hard Disk 1 x 2TB 2 x 2 TB Space Occupation 8 SATA ports, 8 HDDs or 6 HDDs + 1 CD/DVD-RW, Max 2TB per HDD supported Hard Disk HDD Management Hard disk hibernation technology, HDD faulty alarm & Raid (Redundancy) USB Interface 2 ports, 1 for mouse control,...
