- Page 1 TV Ears Digital System Installation Guide...
-
Page 2: Important Safety Instructions
Warning: To reduce the risk of fire or electric shock, do not expose the TV Ears product to rain or moisture. The TV Ears product should not be exposed to dripping or splashing liquids. Do not place objects filled with liquid such as vases on or near the TV Ears product. -
Page 3: Table Of Contents
Table of Contents Important Safety Instructions Included in Box Ideal TV Ears Set Up Installation instructions Step 1 Connect the Transmitter to Your TV Step 2 Place and Power the Digital Transmitter Step 3 Charging the Headset Alternative Methods of Installation... -
Page 4: Included In Box
Included in Box TV Ears Digital Transmitter TV Ears Headset Optical Cord... - Page 5 Included in Box Audio Cord AC Adapter Microphone Extension Cord Microphone Balance Tool Headphone Jack Adapter...
-
Page 6: Ideal Tv Ears Set Up
Ideal TV Ears Set Up... -
Page 8: Installation Instructions
2. Plug the single end of the audio cord into the port labeled Analog Audio In on the back of the TV Ears transmitter. 1. Ports on the front of TVs are usually audio in ports and will not send sound to your TV Ears. -
Page 9: Step 2 | Place And Power The Digital Transmitter
Installation | Step 2 Place and Power the Digital Transmitter The infrared diodes must be in direct line of sight with the headset so the headset can receive the infrared signal. 1. Place the transmitter on a flat surface 3 - 5 feet off the ground. Point it towards the seating area where the headset will be used. -
Page 10: Step 3 | Charging The Headset
Installation | Step 3 Charging the Headset Each headset comes pre-charged with enough battery power for at least 10 minutes of use. The headset will last around 6 - 8 hours on a full charge, but will decrease as the volume reaches higher levels. A fully exhausted battery will take between 8 - 10 hours to charge completely. -
Page 11: Alternative Methods Of Installation
2. If using the optical cord, remove clear sleeves from each end. Plug in the appropriate digital audio cable into the appropriate jack labeled Digital Audio In on the back of the TV Ears transmitter. 3. Plug the other end of the digial audio cord into your chosen digital audio output jack of your TV, satellite, or cable box. -
Page 12: Option 2 | Aik - Power Microphone
2. Plug the male end of the extender cord into the port labeled Analog Audio In on the back of the TV Ears transmitter. 3. Remove the protective cover from the Velcro on the power microphone and stick the microphone to the front of the... -
Page 13: Option 3 | Aik - Headphone Jack Adapter
Alternative Installation Option 2: AIK Headphone Jack Adapter This method of installation often cuts off the volume to the TV speakers, but may also be used for single audio out port installations which would not cut off the volume to the TV speakers. 1. -
Page 14: Using The System | Using The Headset
Using the System Using the Headset Put on the Headset: Using both hands, gently separate the bow arms at the top by the ear tips and place earpieces into each ear. ON/OFF and Volume To turn the headset ON, rotate the volume dial and set the volume to your comfort level. -
Page 15: Maintenance And Replacement Parts
Silicone TV Ears Tips 5 Pair of Washable Tips If you normally watch television for longer than 6 hours or have more than one television in your home, we recommend that you purchase an additional TV Ears Headset. (see back cover) -
Page 16: Frequently Asked Questions
Yes, the Digital systems operate at 95kHz, which is compatible with many movies and play houses. While it works in most places, TV Ears does not guarantee that its products will work in all public places. Check with individual places to verify system compatibility. -
Page 17: Warranty And Guarantee Information | Contact Information
Also if the TV Ears product is taken outside of Canada the warranty becomes void. This warranty is provided at the discretion of TV Ears Canada and does not cover cosmetic damage or damage due to acts of nature, accident, misuse, abuse, negligence, commercial use, or modification of or to any part of the product. -
Page 18: Manufacturer Declarations
TV•EARS® Inc. reserves the right to change product content and product specifications without notice. CE Declaration of Conformity TV Ears is in compliance with the essential safety requirements and other relevant provisions of Standard IEC 60065:2001 + Ammd 1:2005 / EN 60065:2002 and Directive 2004/108/EC; 2006/95/EC, 89/336/EEC, 92/31/ EC, 93/68/EEC. Before putting the device into operation, please observe the respective country specific regulations. -
Page 19: Technical Specifications
Technical Specifications Specifications System Modulation Infrared, Mono Carrier frequencies 95 kHz Range 2000 sq. ft (185.5 m Audio frequency response 80-18,000 Hz < 1% Headset Max SPL 120 dB Power Supply NiMH (Nickel Metal Hydride) rechargeable Operating Time Between 6 and 8 hours on a full charge Weight 1.6 oz (45g) Height... - Page 20 TV Ears Digital System Accessories Since 1998 Digital Transmitter Kit TV Ears has MSRP $149.95 Item # 11211 been helping Digital Transmitter, Optical Cord, people hear TV. Audio Cord, AIK and AC Adapter Backed by the recommendation of thousands TV Ears Headset of Audiologists MSRP $99.95 Item # 10221...
