Dolphin
6500 Mobile Computer
®
with Windows
Embedded Handheld 6.5
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Wireless Speaker and is the answer not in the manual?

Questions and answers

Related Manuals for TV Ears Wireless Speaker

Summary of Contents for TV Ears Wireless Speaker

  • Page 1 ™ Dolphin 6500 Mobile Computer ® with Windows Embedded Handheld 6.5 User’s Guide...
  • Page 2 Disclaimer Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other infor- mation contained in this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been made. The information in this publication does not rep- resent a commitment on the part of HII.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1 - Agency Approvals Label Locations ........................1-1 Safety & RF Approvals by Country: ..................1-2 Dolphin RF Terminal—802.11b/g and/or Bluetooth .............1-3 Chapter 2 - Getting Started Out of the Box ........................2-1 LED Indicators........................2-2 Home Screen ........................2-4 Title Bar..........................2-4 Horizontal Scroll ........................2-5 Tile Bar..........................2-6 Pop-Up Menus ........................2-6...
  • Page 4 Function Key Combinations....................4-3 CTRL Key Combinations ..................... 4-4 Program Buttons........................4-5 Chapter 5 - Using the Image Engine Overview..........................5-1 Available Engines ........................ 5-1 Depth of Field ........................ 5-1 Supported Bar Code Symbologies ..................5-2 Activating the Engine......................5-3 Decoding ..........................
  • Page 5 Connections Manager ......................8-4 To Access the Connections Manager................8-4 Tasks ..........................8-4 Advanced........................8-5 Dolphin Wireless Manager ....................8-6 Dolphin Wireless Manager Window................8-7 Enabling the Radios....................... 8-7 Accessing Radio Configuration Utilities ................. 8-8 Network Cards........................8-8 Connecting and Synchronizing the Terminal and Workstation..........8-9 Installing Additional Software ....................
  • Page 6 Parts and Functions......................12-2 Front Panel ........................12-2 Back Panel ........................12-3 Bottom Panel ....................... 12-4 Power ..........................12-4 Connecting Power to the Net Base................12-4 Charging the Main Battery....................12-5 To Power a Terminal and Charge its Main Battery............12-5 Communication........................

  • Page 7: Chapter 1 - Agency Approvals

    Agency Approvals Label Locations Dolphin 6500 mobile computers meet or exceed the requirements of all applicable standards organizations for safe operation. However, as with any electrical equipment, the best way to ensure safe operation is to operate them according to the agency guidelines that follow. Read these guidelines carefully before using your mobile computer.

  • Page 8: Safety & Rf Approvals By Country

    Safety & RF Approvals by Country: Country Safety RF (Radio) U.S.A. UL60950-1 FCC Part 15, Sub part B, Sub part C Canada* C-UL CSA C22.2 No. 60950-1-03 ICES-003, RSS 210 European IEC 60825-1:1993+A1:1997+A2:2001 EN55022 (CISPR 22) Class B EN55024:1998 Community EN300 328 EN301 489-1 EN301 489-7...

  • Page 9: Dolphin Rf Terminal-802.11B/G And/Or Bluetooth

    Laser Safety Label If the following label is attached to your product, it indicates the product contains LASER LIGHT. DO NOT STARE INTO BEAM an imager engine with a laser aimer (5300) or a laser engine (IS4813). CLASS 2 LASER PRODUCT 1.0 mW MAX OUTPUT: 650nM IEC60825-1: 1993+A1+A2 Laser Eye Safety Statement: This device has been tested in accordance with...
  • Page 10 This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. To maintain compliance with FCC RF exposure guidelines for body- worn operation, do not use accessories that contain metallic components. CAUTION! Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to operate the equipment.

  • Page 11: Chapter 2 - Getting Started

    Getting Started Out of the Box Verify that your carton contains the following items: • Dolphin 6500 mobile computer (the terminal) • Main battery pack (3.7v, Li-Ion) • AC power supply • Localized plug adapters Note: Be sure to keep the original packaging in case you need to return the Dolphin terminal for service; see Technical Assistance on page 14-1.

  • Page 12: Led Indicators

    5. Replace the hand strap. We recommend use of Honeywell Li-Ion battery packs. Use of any non-Honeywell battery may result in damage not covered by the warranty. Step 2. Charge the Batteries Dolphin 6500s ship with both the main battery pack and internal backup battery significantly discharged of power.
  • Page 13 The power adapter on the power cable converts the voltage from the power source to 5 volts DC. Only power adapter cables from Honeywell convert the voltage appropriately. The power cable contains a plug adapter for each geography (US, UK, EU, etc.). Plug Adapter Power Adapter Power Cable...

  • Page 14: Home Screen

    Home Screen After the Dolphin terminal initializes the first time, you see the Home screen. to reach the Start screen from the home screen. to access the Dolphin Wireless Manager (see page 8-6) from the home screen. For more information about the touch screen, see Touch Screen Display on page 3-2.

  • Page 15: Horizontal Scroll

    Horizontal Scroll Indicator Meaning Synchronizing data The terminal could not synchronize data with the workstation via ActiveSync. New e-mail New text message New voicemail New instant message Ringer off A battery error has occurred. Replace the main battery pack with a Honeywell Li-poly or Li-ion battery pack.

  • Page 16: Tile Bar

    The Horizontal Scroll, located at the top of most application windows, provides access to additional application screens. You can flick left or right on the scroll or tap each label on the scroll, until you get to the desired screen. Tapping a label to the left or right of the center item brings new labels into view. Note: Tap the Title bar to access the horizontal scroll if it is not visible on the screen.

  • Page 17: File Explorer

    File Explorer You can also use the File Explorer to find files and organize these files into folders. 1. Tap > File Explorer 2. Tap the Up button at the bottom of the screen to move up one level in the directory. 3.
  • Page 18 2 - 8...

  • Page 19: Chapter 3 - Terminal Hardware Overview

    Terminal Hardware Overview Dolphin 6500 terminals include a number of standard terminal configurations as well as charging and communication peripherals and accessories to maximize the efficiency of your application setting. Standard Terminal Configurations There are two standard Dolphin 6500 configurations: WPAN only and WPAN/WLAN. Both configurations include the following options;...

  • Page 20: Front Panel Features

    Front Panel Features (28-key keypad (numeric) (52-key keypad (full alphanumeric) Scan/Decode LED Scan/Decode LED Touch Screen Touch Screen Display (screen Display (screen protector protector installed at the installed at the factory) factory) Software Reset Key Navigation Keys (arrow keys) Navigation Keys Software Reset Key Power Key Power Key...

  • Page 21: Using Screen Protectors

    For touch screen input, use the stylus included with the terminal or your finger. The method you choose depends on which one is most appropriate for your application. While there is a great deal of variation in different applications, you generally achieve greater accuracy with the stylus for buttons or icons that are close together.

  • Page 22: Removing The Screen Protector

    Removing the Screen Protector Dolphin 6500s ship with a touch screen protector already installed. To replace the screen protector, you must remove the one already installed. 1. Press the red Power button to suspend the 28-key unit or press the Blue then Z (Power) keys to suspend the 52-key unit.
  • Page 23 4. Align the exposed edge of the screen protector along the left edge of the touch panel. Make sure that it lies flush with edges of the touch panel. Backing Paper Screen Protector Note: To reposition the screen protector, lift up gently and reapply. 5.
  • Page 24 6. Pull smoothly and evenly from left to right until the screen protector is applied. Press gently but firmly. Use the card as necessary to smooth out any air pockets or bumps after application. 7. Press the Power key to wake the terminal and check the touch panel with the stylus. 8.
  • Page 25 12. For maximum performance, recalibrate the screen. Tap > Settings > System > Screen > Align Screen. 13. Tap Recalibrate and follow the instructions on the screen. 3 - 7...

  • Page 26: Back Panel Features

    Back Panel Features Engine Window Hand Strap (with Stylus) Speaker Rear Scan Button Finger Saddle Installed Battery Hand Strap The Dolphin 6500 comes with an adjustable, elastic hand strap. The strap is attached to the device with the two small screws. It is threaded through the slot on the bottom of the back of the unit.

  • Page 27: Installing Memory Cards

    • 1KHz–72db • 4KHz–72db Stylus Dolphin 6500 terminals ship with a stylus inserted in a loop on the hand strap. Store the stylus in the hand strap when you’re not using it. Installing Memory Cards The Dolphin 6500 supports Secure Digital (SD) memory cards. 2GB and 4GB cards have been tested for reliability.

  • Page 28: Left Side Panel Features

    3. Press the SD card towards the front of the terminal until you hear a click to confirm that it has unlocked. The card will stops when it hits the pin. 4. Depress the small pin at the edge of the card. The card will pop out enough for you to grab its edge. Left Side Panel Features Side Button Headset Jack...

  • Page 29: Top Panel Features

    Top Panel Features Imager or Laser Aperture Window Imager or Laser Aperture Window The angled image engine or laser engine reads and decodes most popular bar code symbologies and takes images like a digital camera (image engine only). For more information, see Using the Image Engine on page 5-1 or see Using the Laser Engine...

  • Page 30: Dolphin Peripherals/Accessories For The Dolphin 6500

    • USB Host D- • USB Host Detect • Clear To Send • Received Data • • RS-232 Shutdown • USB Client D+ • USB Client D- • USB Client +5V Note: Signals referenced are for a DTE device. Dolphin Peripherals/Accessories for the Dolphin 6500 The following items are sold separately and enhance your Dolphin 6500’s capabilities.

  • Page 31: Battery Power

    Li-Ion Battery Packs The Li-Ion battery pack provides the main power supply for the terminal. For more information, see Battery Power on page 3-13. For information on how to purchase these items, contact a Honeywell sales representative. Battery Power The intelligent battery technology inside the terminal features two types of battery power: •...

  • Page 32: Managing Main Battery Power

    Charging Options When the battery is installed in the terminal, you can use any of the peripherals listed below to charge the battery. • Dolphin HomeBase/eBase Device (see page 10-1) • Dolphin Comm/Charge Cable; Managing Main Battery Power (see page 3-14) You may charge the device using the USB connection if you do not have a wall adapter.
  • Page 33 • Avoid storing batteries outside the specified range of -4 to 140° F (-20 to 40°C) or in extremely high humidity. • For prolonged storage, it is recommended that the battery be at a 40% - 50% charge level, be removed from the device, and stored in a controlled temperature environment.

  • Page 34: Resetting The Terminal

    Charging Guidelines Follow these guidelines to maximize the life of the Dolphin 6500’s internal backup battery under normal usage conditions: • Keep a charged Li-Ion battery pack in the Dolphin terminal. • Keep the Dolphin terminal connected to a power source when the terminal is not in use. Resetting the Terminal Reset Soft Reset:...

  • Page 35: Care And Cleaning Of The Dolphin Terminal

    Troubleshooting Suspend/Resume If the terminal does not wake when you press the Power button on the 28-key Dolphin 6500 or press the Blue then Z (Power) keys on the 52-key Dolphin 6500, the main battery might be too low to resume operation.

  • Page 36: Dolphin 6500 Technical Specifications

    Dolphin 6500 Technical Specifications Operating System Microsoft Windows Embedded Handheld 6.5 Development Honeywell SDK for Windows Embedded Handheld 6.5 Environment Application Software Honeywell Power Tools and Demos Processor Marvell PXA 300 624MHz Memory 256 MB RAM X 256 MB Flash Expansion Memory User accessible SDHC memory card slot.
  • Page 37 Operating Temperature 14° to122°F (-10° to 50°C) Charging Temperature 32° to 104°F (0° to 40°C) Storage Temperature -4° to 158°F (-20° to 70°C) Humidity 95% humidity, non-condensing Construction High impact resistant PC/ABS housings Magnesium alloy internal chassis with component shock mounts Drop 4 ft.
  • Page 38 3 - 20...

  • Page 39: Chapter 4 - Using The Keypad

    Using the Keypad Overview The 28-key and 52-key keypads are as follows: 28-key keypad (numeric) 52-key keypad (full alphanumeric) Navigation keys (arrow keys) Navigation keys Power key Power key combination Navigation Keys The navigation keys enable you to move the cursor up and down lines and from character to character. 4 - 1...

  • Page 40: Basic Keys

    Basic Keys Name Function ALPHA (28- Toggles the keyboard between alpha (upper and lowercase) and numeric key) modes on the 28-key keypad. The 'A/a/1” indicator on the title bar changes SFT (52-key) accordingly. Pressing SFT two times in rapid succession on a 52-key keypad toggles between upper and lowercase.

  • Page 41: Function Key Combinations

    Function Key Combinations On the 28-key keypad, hold down the Function key (FUNC) and then press a key with the blue text/icons below it to perform specific functions. 28-key Function Key Combination FUNC + 1 FUNC + 2 FUNC + 3 FUNC + 4 Toggle the wireless radio on and off FUNC + 5...

  • Page 42: Ctrl Key Combinations

    52-key Function Key Combination FUNC + 10 F10 - user programmable FUNC PG Page up or down - used in conjunction with Up and Down arrows CTRL Key Combinations On the 28-key keypad, hold down the Control key (CTRL) and then press a key with the red characters below it to type the desired character.

  • Page 43: Program Buttons

    52-key Function Key Combination CTRL + H “ CTRL + I CTRL + K CTRL + L CTRL + M CTRL + N CTRL + P – CTRL + Q CTRL + U Windows Explorer CTRL + . CTRL + , CTRL + VOL Increase/decrease volume Program Buttons...
  • Page 44 4 - 6...

  • Page 45: Chapter 5 - Using The Image Engine

    Using the Image Engine Overview ™ The Dolphin 6500 houses a compact image engine using Adaptus Imaging Technology that instantly reads all popular 1D and 2D bar codes and supports omni-directional aiming and decoding. The image engine can also capture digital images, such as signatures and pictures. Available Engines The Dolphin 6500 can be equipped with a 5300 Standard Range (5300SR) image engine (depending on the configuration purchased).

  • Page 46: Supported Bar Code Symbologies

    Supported Bar Code Symbologies Symbology Type Symbology Name 1D Symbologies Codabar Interleaved 2 or 5 Code 3 of 9 Matrix 2 of 5 Code 11 Plessey Code 32 Pharmaceutical (PARAF) PosiCode Code 93 Straight 2 of 5 IATA Code 128 Straight 2 of 5 Industrial EAN with Add-On Telepen...

  • Page 47: Activating The Engine

    Activating the Engine When a scanning application is open, press the Scan key to activate the image engine. Using Demos Dolphin Demos are software utilities loaded on Dolphin terminals that demonstrate the advanced features of the terminal. There are two Demos that feature the image engine: Image Demo and Scan Demo. To access these demos, tap >...

  • Page 48: Capturing Images (5300 Engine Only)

    Sample Bar Codes You can use the following bar codes to verify decoding: Sample 128 Sample PDF417 Code 128 PDF417 Test Message Omni-Directional Scanning Positions The high-vis aiming pattern frames the bar code to provide you with the best scanning performance. Note: To achieve the best read, the aiming beam should be centered horizontally across the bar code.
  • Page 49 Taking an Image 1. Tap > Demos > Image Demo. 2. Point the Dolphin terminal at the object. 3. Press the Scan key to activate the engine. The touch screen displays a preview of the object. 4. Adjust the terminal’s position until the preview on the screen is as you want it to appear in the image. 5.
  • Page 50 5 - 6...

  • Page 51: Chapter 6 - Using The Laser Engine

    Using the Laser Engine Overview The Dolphin 6500 (IS4813 laser version) contains a laser diode that emits a beam toward an oscillating mirror that scans through the code and the reflected light is bounced off of two mirrors back to the collector.

  • Page 52: Activating The Engine

    Activating the Engine When a scanning application is open, press the Scan key to activate the laser engine. Using Demos Dolphin Demos are software utilities loaded on Dolphin terminals that demonstrate the advanced features of the terminal. To access these demos, tap >...

  • Page 53: Chapter 7 - System Settings

    System Settings Overview Customized settings are available on the System Settings menu. Tap > Settings and the settings screen opens. Icon Description Bluetooth Configures the Bluetooth radio. See Enabling the Bluetooth Radio on page 9-1. Clock & Set the system clock, date, time and schedule alarms. See Clock &...

  • Page 54: Clock & Alarms

    Icon Description System Adjusts system settings. See System Menu on page 7-6. Clock & Alarms The Clock & Alarms settings can be accessed from the Home screen or the Settings Menu. 1. On the Home screen, tap the line that displays the time and date >...

  • Page 55: Personal Menu

    Personal Menu To access the Personal Menu, tap > Settings > Personal. The screen opens displaying the Per- sonal Menu. Icon Description Buttons Program the side buttons to perform specific tasks. See Buttons on page 7-3. Owner Enter your contact information (e.g., name, company, address, telephone number and E-mail address).
  • Page 56 Changing Button Assignments 1. Tap > Settings > Personal > Buttons Note: The buttons that appear on this window are the only buttons that can be programmed via the Buttons setting. You cannot add buttons to this window. 2. To change button assignment, tap on the name of the button in the Application Key section, and then select a program or command in the drop down list below the Application Key section.
  • Page 57 1. Tap > File Explorer , and navigate to the program (My Device > Program Files). 2. Tap and hold on the program, then tap Copy on the pop-up menu. 3. Navigate to the Windows folder and open the Start Menu (My Device > Windows > Start Menu > Programs), tap and hold a blank area of the window, and tap Paste Shortcut on the pop-up menu.

  • Page 58: System Menu

    System Menu The System menu enables you to verify and sometimes alter system parameters. To access the System menu, go to > Settings > System. Tap the appropriate icon to open that system setting. Icon See Page About About on page 7-7.

  • Page 59: About

    Icon See Page External External GPS on page 7-9. Managed Managed Programs on page 7-10. Programs Memory Memory on page 7-10. Regional Regional Settings on page 7-12. Settings Remove Remove Programs on page 7-13. Programs Screen Screen on page 7-14. Task Task Manager on page...

  • Page 60: Certificates

    > Settings > System > Backlight. On Battery Tab On External Tab Keypad Backlight Tab The On Battery tab determines the backlight timeout when the terminal is running on battery power. The On External tab determines the backlight timeout when the terminal is running on external power. The options on the On Battery and On External tabs are the same.

  • Page 61: Encryption

    Encryption Encryption gives you the option of encrypting files placed on storage cards so that those files cannot be read by any other device. Error Reporting Error Reporting gives you the option of enabling or disabling the error reporting function of Windows Embedded Handheld 6.5.

  • Page 62: Managed Programs

    Managed Programs Managed Programs are a list of programs that are managed if enrolled to enterprise domain. Managed Programs is the client-side that works with the server product System Center Mobile Device Manager (MDM). MDM consists of MDM Gateway Server and one or more computers that run MDM Device Man- agement Server;...

  • Page 63: Power

    Storage Card—You can install one memory card in Dolphin terminals (see Installing Memory Cards on page 3-9). If a storage card is installed in the terminal, you can see capacity and usage statistics for the card. Data stored on the SD card is not affected when the operating system is upgraded.

  • Page 64: Regional Settings

    CPU Power Setting Tab Allows you to configure the CPU power setting to extend the battery life or to increase the CPU performance. Choose either Auto Power or Manual Power. Selecting Manual Power allows for either 104, 416, or 624 MHZ. The CPU operates at or above the selected frequency depending on the terminal’s state.

  • Page 65: Remove Programs

    Remove Programs Remove Programs enables you to remove programs installed on the terminal. Any program (usually CAB or DLL files) stored in the \\Honeywell\Autoinstall folder on the storage card re-installs after a software upgrade or a factory reset. If a program is manually removed using the Remove Programs application, the program does not re-install on a hard or soft reset.
  • Page 66 Screen The Screen system setting contains three screens: General, Clear Type, and Text Size. General Screen Orientation The General screen enables you to set the dynamic screen rotation. Three choices of screen orientation are supported: Portrait, Landscape (right-handed), and Landscape (left- handed).

  • Page 67: Task Manager

    Text Size Screen The Text Size screen enables you to perform font scaling within certain views of the: • Home screen, • Contacts, • Calendar, • Messaging, and • Tasks. Font scaling means that you can increase or decrease the point size of the font on application windows.
  • Page 68 Using the Task Manager Applications To view the status of the programs running on your mobile computer, tap the Menu button at the bottom of the screen, then tap View > Applications. From the application list, you can: • Tap and hold on an application, then tap Switch To on the pop-up menu.

  • Page 69: Chapter 8 - Communication

    Communication Connecting the Dolphin 6500-USB Communication Cable To facilitate USB communication between the Dolphin terminal and the host workstation, you may connect your unit to a host by using either the supplied power cable or by using the optional Dolphin 6500- USB Communication Cable.
  • Page 70 2. Select the USB charging option (100mA or 500mA). If you do not disconnect the cable, the option will be grayed out. 3. Re-connect the cable. 8 - 2...

  • Page 71: Connections Menu

    Connections Menu The Connections system setting provides access to the terminal’s various wireless communication options. Icon Tapping this icon… Connections Opens Microsoft’s connections manager. Manages the wireless radios installed in the terminal. See Dolphin Dolphin Wireless Manager Wireless on page 8-6. Note: The Dolphin Wireless Manager icon may not appear on the Connections Manager menu on terminals running Microsoft Windows Embedded Handheld 6.5...

  • Page 72: Connections Manager

    Connections Manager Microsoft’s Connections Manager sets up multiple network connections to Internet Service Providers (ISPs) via external modem. Do NOT enter connection parameters in the Connections Manager if: • you are using one of the on-board wireless radios to connect to a network. The Dolphin terminal uses the settings from each radio’s configuration utility to connect.

  • Page 73: Advanced

    • Modem • Virtual Private Network (VPN) • Proxy server connection Note: If you are connected to your ISP or private network during synchronization, the terminal should download the proper proxy settings during synchronization with the workstation. If these settings are not on your workstation or need to be changed, ask your ISP or network administrator for the proxy sever name, server type, port, type of Socks protocol used, and your user name and password.

  • Page 74: Dolphin Wireless Manager

    Dolphin Wireless Manager The Dolphin Wireless Manager provides a centralized interface that enables and disables all the on- board radios. Each radio has its own configuration program. The Dolphin Wireless Manager also pro- vides shortcuts to the configuration utilities for each radio. on the Home screen to access the Dolphin Wireless Manager.

  • Page 75: Dolphin Wireless Manager Window

    Dolphin Wireless Manager Window These buttons show you the state of the radio. Enabling the Radios 1. Tap on the Home screen to access the Dolphin Wireless Manager. 2. Tap anywhere inside the rectangle of the radio you want to enable. 3.

  • Page 76: Accessing Radio Configuration Utilities

    Accessing Radio Configuration Utilities Each radio has its own configuration utility that you can access by tapping Menu on the tile bar. Radio Type Menu Option Tap WLAN Settings and the Honeywell WLAN Security Supplicant opens. 802.11/b/g The Honeywell WLAN Security Supplicant User’s Guide is available for download from the Dolphin 6500WEH product page at www.honeywellaidc.com.

  • Page 77: Connecting And Synchronizing The Terminal And Workstation

    Connecting and Synchronizing the Terminal and Workstation To synchronize data between the terminal and the workstation, ActiveSync (version 4.5 or higher) or Windows Mobile Device Center must be installed and configured for the appropriate communication type on the host workstation (Windows-based PC) and the Dolphin terminal. Dolphin terminals ship with ActiveSync already installed.
  • Page 78 Setting Up the Host Workstation To synchronize data between the terminal and the workstation, ActiveSync (v4.5 or higher) or Windows Mobile Device Center must be configured for same communication type on both the host workstation and the Dolphin terminal. ActiveSync Verify that ActiveSync is configured to use the appropriate communication type.

  • Page 79: Installing Additional Software

    Installing Additional Software Dolphin terminals ship with the operating system, radio drivers, and custom Honeywell software already installed. These are the default programs that install when your terminal first boots up. You can install additional software programs to the terminal provided that the following parameters are met: •...

  • Page 80: Connecting The Terminal To A Wireless Network

    a. Open ActiveSync and click Explore, or b. Open Windows Mobile Device Center and click File Management 2. On the workstation, navigate to the workstation folder containing the program file(s). Copy and paste the file(s) into the Program Files folder on the terminal. •...

  • Page 81: Software Upgrades

    2. Select the program version that matches your Dolphin terminal and processor. 3. Read any installation instructions, Read Me files, or documentation that comes with the program. Many programs provide special installation instructions. 4. Download the program to the terminal directly from the Internet. You would normally store the program in the \Program Files folder unless another location is required by the program.
  • Page 82 8 - 14...

  • Page 83: Chapter 9 - Working With The Bluetooth Radio

    Working with the Bluetooth Radio Enabling the Bluetooth Radio You enable the Bluetooth radio in the Dolphin Wireless Manager (see page 8-6). 1. Tap on the Home screen to access the Dolphin Wireless Manager. 2. Tap anywhere inside the Bluetooth rectangle and Bluetooth begins activating. 3.

  • Page 84: Pairing And Trusted Devices

    Pairing and Trusted Devices The terminal does support pairing. Pairing happens during general connection setup. Paired devices are "trusted" devices. This means that there is unrestricted access to all services (including services that require authorization and authentication). A connection can exclude pairing. A device that is connected to the terminal but not paired with it is considered an untrusted device.
  • Page 85 4. Select a device from the list and tap Next. The types of devices in the vicinity of the radio appear in the list of discovered devices. 5. You are prompted to enter a passcode. • If the device has a specific passcode, enter it in the Passcode field and tap Next. When attempting to connect to a printer or headset with Bluetooth capabilities, the passcode may default to either 1111 or 0000.

  • Page 86: Transferring Files

    8. When the connection is complete, a list of matching and supported services on the device appears. Only the services that are mutually supported on both devices appear in the Partnership Settings window. 9. Select the services you want to use and tap Save. The services on the new devices have to be selected or the pairing won’t include those services, even though the devices are paired.
  • Page 87 4. The Bluetooth radio begins searching for devices. When a Bluetooth device is first found, it appears as an Unknown device; the icon indicates that the device is a Bluetooth device. As data is retrieved, the device IDs appear in the list. 5.

  • Page 88: Making The Terminal Discoverable

    Making the Terminal Discoverable By default, the Dolphin terminal is not discoverable, which means that the terminal will not be found by other Bluetooth devices. To make the terminal discoverable, tap Mode on the Horizontal scroll. Select Make this device visible to other devices and tap OK. 9 - 6...

  • Page 89: Chapter 10 - Dolphin Homebase/Ebase Device

    Dolphin HomeBase/eBase Device Overview Note: The information in this chapter applies to both the Dolphin HomeBase and Dolphin eBase devices unless otherwise indicated. As the hub of your Dolphin 6500 system, the Dolphin HomeBase charging and communication cradle supports full-speed USB 1.1 and RS-232 communication with a workstation. The Dolphin eBase is identical to the Dolphin HomeBase except it supports Ethernet communication as well as USB 1.1, and RS-232.

  • Page 90: Front Panel

    Front Panel Terminal Well Charging LED Terminal Well Place the Dolphin terminal in the terminal well to communicate with a host device, power the terminal, and charge the terminal’s battery. Make sure that the device is securely seated. Rubber Feet The bottom panel has four rubber feet to stabilize the unit on a flat surface.

  • Page 91: Back Panel

    Back Panel HomeBase eBase Serial Port Serial Port USB Port USB Port Ethernet Port DC Power Jack DC Power Jack DC Power Jack Connect the power cable to this power jack; see Powering the Dolphin HomeBase Device page 10-4. USB Port The USB port is full-speed (v1.1).

  • Page 92: Powering The Dolphin Homebase Device

    Powering the Dolphin HomeBase Device The terminal requires 5 volts DC input for communication and battery charging; the power adapter on the power cable converts the voltage from the power source to 5 volts DC. Only power adapter cables from Honeywell convert the voltage appropriately.

  • Page 93: Charging The Main Battery

    The following illustration shows how to install the ferrite on the cable. It should be placed approximately 1.57 inches (40mm) from the RJ45 plug. The cable should be looped around the core, as shown. Charging the Main Battery The base powers the terminal and fully charges its main battery pack in an average of 5 1/2 hours for a fully depleted battery.

  • Page 94: Charging A Spare Battery

    Charging a Spare Battery The base can also charge a second battery while the terminal is positioned in the base. The second battery can be inserted in the battery charging well in back of the terminal connection. Place the battery in the well with the label facing up and toward the back of the unit.

  • Page 95: Technical Specifications

    Technical Specifications Structural Dimensions 5.3 in. high X 4.5 in. wide X 3.1 in. deep (13.5 cm. X 11.4 cm. X 7.9 cm.) Weight Dolphin HomeBase - 11.0 oz. (313g) Dolphin eBase - 11.3 oz (320g) Material Polycarbonate Color Black Environmental Operating Temperature 14°...
  • Page 96 10 - 8...

  • Page 97: Chapter 11 - Dolphin Quadcharger Device

    Dolphin QuadCharger Device Overview The Dolphin QuadCharger device is a four-slot charging station that charges up to four Li-ion battery packs in an average of 5 1/2 hours for a fully depleted battery. It takes less time if the battery has some charge.

  • Page 98: Battery Charging

    Power Supply Connector Use this connector to attach the power supply to the charger. The universal power supply accepts input voltages between 90–265 volts. Battery Charging Charging Process This charger charges Dolphin 6500 Li-Ion 3300mAh packs in an average of 5 1/2 hours for a fully depleted battery.

  • Page 99: Recommendations For Storing Batteries

    3. When the Status LED turns green, the battery in the slot has completed charging. Recommendations for Storing Batteries To maintain top performance from batteries, follow these storage guidelines: • Avoid storing batteries outside of the specified temperature range of -4 to 104°F (-20 to 40°C) or in extremely high humidity.

  • Page 100: Technical Specifications

    Technical Specifications Structural Dimensions 7.3 in. long X 3.7 in. wide X 2.4 in. high (18.5 cm. X 9.4 cm. X 6.1 cm.) Weight 11.5 oz. (325g) Material Case: Polycarbonate Color: Black Capacity Supports up to four Li-Ion battery packs Environmental Operating Temperature 32°...

  • Page 101: Chapter 12 - Dolphin 6500 Net Base Device

    Dolphin 6500 Net Base Device Overview The Net Base enables up to four Dolphin 6500 mobile computers to communicate with a host device over an Ethernet network. In addition, the Net Base provides a second RJ45 Ethernet port for connec- tion to an additional device such as a printer, workstation, eBase, or another Net Base.

  • Page 102: Parts And Functions

    Parts and Functions Front Panel Terminal Wells Power/Dock LED COMM LED Terminal Wells The Net Base contains four terminal wells. Each well has its own dedicated Power/Dock LED and COMM LED indicator. Place the Dolphin terminal in any one of the four wells to communicate with a host device, power the terminal, and charge the installed battery pack.

  • Page 103: Back Panel

    Back Panel Green LED Yellow LED Two RJ45 Ethernet Ports DC Power Jack DC Power Jack Use the power cable from Honeywell that comes with the Net Base to supply power to this power jack. For more information, see Power on page 12-4.

  • Page 104: Bottom Panel

    Bottom Panel For details on how to mount the Net Base, see Mounting the Net Base on page 12-6. Serial Number and Compliance Label MAC Address Label Power The terminal requires 12 Volts DC input for communications and battery charging; the power adapter on the power cable converts the voltage from the power source to 12 volts DC.

  • Page 105: Charging The Main Battery

    Charging the Main Battery The base provides power to the Dolphin terminals and allows the charging of the main batteries in the terminals. The main battery of each terminal charges in 4 hours for the standard 3.7V battery or 6 hours for the extended 3.7V battery. The intelligent battery charging system incorporated into all Dolphin terminals prevents overcharging, which means that Dolphin terminals may be stored in the base indefi- nitely without damage to the terminals, battery packs, or the base.

  • Page 106: Mounting The Net Base

    3. Plug the Ethernet cable into the network. 4. Insert the Dolphin into one of the terminal wells. The DOCK LED for the well changes from red to green and the connection icon on the Dolphin’s title bar changes from 5.
  • Page 107 Bottom Panel DIN Rail Slot Rubber Feet, Qty. 6 Desk Mounting The DIN Rail (7.5 X 35 mm) slot on the bottom panel enables secure mounting on a horizontal surface. Hardware Required • 3/16 in. dia x 5/8 in. long pan head screw •...
  • Page 108 3. Then, using the appropriate nuts and bolts, secure the DIN Rail to a stable, flat horizontal surface. DIN Rail (7.5 X 35 mm) Wall Mounting The optional wall mount bracket enables secure mounting of the base on a vertical surface. The wall mount bracket can be used in conjunction with the DIN rail but does not require the DIN Rail for use.
  • Page 109 2. Slide the bolt through the wall bracket, and thread the toggle nut onto Toggle Nut the bolt. Bolt 3. Press the ends of the toggle nut together, and insert the bolt/nut into the pilot hole until the nut clears inside wall surface. The toggle nut should spring open preventing the screw from being removed.
  • Page 110 3. Slide the washer onto the screw and tighten the nut to secure the assembly. Wall Bracket, Qty. 1 Screw, Qty. 2 Washer, Qty. 1 DIN Rail, Qty. 1 Nut, Qty. 1 Washer, Qty. 1 Nut, Qty. 1 4. Remove the rubber feet on the bottom of the Net Base. 5.

  • Page 111: Chapter 13 - Dolphin 6500 Slide-On Handle

    Dolphin 6500 Slide-On Handle Overview The optional slide-on handle provides a productivity-enhancing solution for applications that require high volume scanning, such as inventory management and stock replenishment. Removing the Hand Strap Prior to installing the Dolphin 6500 handle on the terminal, you must remove the hand strap. 1.
  • Page 112 13 - 2...

  • Page 113: Chapter 14 - Customer Support

    Customer Support Technical Assistance If you need assistance installing or troubleshooting your device, please contact us by using one of the methods below: Knowledge Base: www.hsmknowledgebase.com Our Knowledge Base provides thousands of immediate solutions. If the Knowledge Base cannot help, our Technical Support Portal (see below) provides an easy way to report your problem or ask your question.

  • Page 114: Limited Warranty Duration

    FROM A CLAIM BASED ON CONTRACT, WARRANTY, TORT, OR OTHERWISE) EXCEED THE ACTUAL AMOUNT PAID TO HII FOR THE PRODUCT. THESE LIMITATIONS ON LIABILITY SHALL REMAIN IN FULL FORCE AND EFFECT EVEN WHEN HII MAY HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH INJURIES, LOSSES, OR DAMAGES.
  • Page 116 Honeywell Scanning & Mobility 9680 Old Bailes Road Fort Mill, SC 29707 www.honeywellaidc.com ™ 65-WEH-UG Rev B 4/12...
