- Page 29 Installation and Use of Wi-Fi Plug (DW10) 1. Installation: install AEE DW10 onto your camera (as shown in the figure below), and it will auto recognize AEE DW10 and enter the standby state when you turn on your camera.
- Page 30 Wi-Fi and operate. 2. For iPhone users: Entering the iphone APP store, search AEE , download and install it, following the user manual to connect the Wi-Fi and operate.
- Page 31 1) Turn on your camera and DW10 and wait until the blue WiFi indicator flashes. Enable the WiFi searching function of a mobile receiving device to find the wireless signal source named “AEE Magicam” and then click “Connect” to connect the mobile device to your camera (default password: 00000000).
- Page 32 : Recording duration / photo No. 2. The mobile device must be used within a distance of max. 40 meters from the SD22W in an obstacle- free and horizontal angle.
- Page 33 Operating Instructions for WiFi Control Interface 1. Video Recording Click the Video recording mode icon " ". The current state icon will dispaly as " ", click it to start / stop video recording. Click the icon " " to maximize the preview (See Fig. 3).
- Page 34 2. Single shot Click the Single shot mode icon " " ,it will turn blue " ". The current state icon will dispaly as " ", click it to take one picture. Click the icon " " to maximize the preview (See Fig. 4).
- Page 35 3. Fast Shot Click the Fast shot mode icon " " ,it will turn blue " ". The current state icon will dispaly as " ", click it to take pictures within one second. Click the icon " " to maximize the preview (See Fig. 5).
- Page 36 4. Playback Click the icon " " to enter the interface shown in Fig. 7 to remotely play videos and photos. Camera Mobile Device Storage Storage Slide the icon " ". If you select "Camera Storage", you can Settings replay the files stored on the camera.
- Page 37 In the large preview mode: Click the icon " " to return to the thumbnail preview interface. Click the icon " " to share the current file to a social networking website or send it by E-mail. Click the icon "...
- Page 38 Download Files to Mobile Device Return to the thumbnail preview interface and click the icon " " to enter the Download interface. Click the desired files to download them to your mobile device. Files downloaded Files in waiting Files in downloading...
- Page 39 In the thumbnail preview mode, slide the icon " " to view local files. Click the icon " " to enter the interface shown in the figure below, and then click the desired files to share them to social networking websites or send them by E-mail.
- Page 40 Trim Videos When viewing the downloaded files on the mobile device, you can click the icon " " at the bottom of the screen to enter the video trimming interface shown in the figure below: Trim Storyboard Menu Current frame...
- Page 41 "AP_PASSWD=".) Note: 1. If the TF card is formatted, you need to reconnect AEE SD22W to your camera in order to find the folder "MISC" and change the name and password. 2. Above images for reference only, subject to our available App.
