Summary of Contents for AEE PD20
- Page 1 PD20 Video and Voice Recording Bluetooth Headset Data Security Encryption Continuous Capture 3-Million-Pixel High-definition Camera A Video Camera with Bluetooth Function...
- Page 2 FCC Notices 1. The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user's authority to operate the equipment. 2. This device complies with Part 15 of the FCC Rules. (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 3: Table Of Contents
Contents Preface..............1 Product Warranty............1 Product Features............2 Product Description...........3 Product Structure............4 Operating Instruction..........5-10 Operating Instruction for Bluetooth Headset..10-12 Power Supply Certification........13 Package Accessories..........14 Product Structure............15 Functional & Parameter..........16... -
Page 4: Preface
Preface Thanks for purchasing our high-definition digital video camera PD20. Featured by mini, delicate and unique humanistic design, the product fulfills 360° r e c o r d i n g / m o n i t o r i n g / e v i d e n c e c a p t u r e . -
Page 5: Product Features
Product Features > Video recording function: Record into AVI; output:736 x480@30 FPS; video codec:M-JPEG; > Continuous capture function; > Separate voice recording function; it is able to meet the requirement of long voice recording to capture evidences; and it can record the call information by Bluetooth;... -
Page 6: Product Description
Product Description As a high-end mini high-definition digital video camera designed to meet the market demand, this product features leading-edge performance in functions such as digital video recording, voice storage, sound- activated video recording, USB data transmission, USB charging and Bluetooth transmission, etc. Besides, the product has been awarded many patents of invention and technology. -
Page 7: Product Structure
Product Structure Bluetooth Headset Volume Loop Control Shutter Stop Bluetooth Power Switch/Answer Ring Off Voice Recording Camera Lens Voice operated switch USB Interface Voice Recording MIC Camera Power Switch Video Recording... -
Page 8: Operating Instruction
(2): Voice- activated Recording: Turn on PD20 and turn the voice operated switch to “On”, a: If the external sound goes beyond 75db, PD20 will auto enter the video recording mode to start recording; during long term video recording,the system will generate a file automatically in every 30 minutes;... - Page 9 30 minutes; Note: During the functional shift between video recording, voice recording and photo shooting, in case that PD20 is recording video or sound, you need to press “Stop” firstly to save the current file of video or voice recording;...
- Page 10 In the state of power on, long press “Shutter” for 4s, the free space of memory will be detected. The free space of PD20 is determined according to the number of times the red indicator light flashes (flashing times: 1-4) ; the more times the green indicator light flashes, the less the free space is.
- Page 11 Figure 3 Figure 4 Figure 5 Figure 6 WORDPAD Help File Edit Format View After entering U-Disk, you'll see a text file as shown in Figure 5; you can set the file to enable/disable video recording loop overwrite, select TV-OUT output system and change TV-OUT password.
- Page 12 (3)Enter the main menu of TV OUT by password. The initial password is “000000”; if you want to change the password, you can set any six digit password in configuration setting “TVOUT_PASSWORD=000000”. Note: After saving the configuration settings, the settings will be valid by restarting the machine.
-
Page 13: Operating Instruction For Bluetooth Headset
Video Recording Stop Shutter Voice Recording 10. PC Camera Turn voice operated switch to ON; connect USB with PC, and then turn POWER switch to ON; at this moment, the machine will enter PC Camera function, i.e. it can be used as a visual communication medium, and the green light flashes fast. - Page 14 2.Start Bluetooth function of mobile phone to search for Bluetooth devices, and “D20” will pop up on the mobile phone, which indicates PD20 Bluetooth headset has been searched. You can “Pair” the Bluetooth headset via mobile phone; after successful pairing, a prompt tone “tick”...
- Page 15 7. Volume Control If you want to turn up the volume, you can press “Volume Control” once; if you want to turn down the volume, you can long press “Volume Control”. 8. Turn off Bluetooth Headset If you long press “Answer/Ring Off” on the headset for 3s, the blue light will be on for 1s and then off.
-
Page 16: Power Supply Certification
Power Supply Cer tification This product uses the power supply passing authoritative certifications. C-TICK USA Power Supply Australia Power Certification Supply Certification EU Power Supply Germany Power Certification Supply Certification PRC Power Supply Japan Power Certification Supply Certification UK Power Certification... -
Page 17: Package Accessories
Package Accessories Vehicle USB Power Supply AV Cable Power Adaptor USB Connector USB Cable Convertible Rubber Earcap Installation Disc Portable Power Supply and Accessories Velcro USB charging cable MINI B 8PIN Discharge Cloth bag wire Note: There might be some disparities between the picture and the real object. -
Page 18: Product Structure
Product Structure Memory Green Function Bluetooth Headset Light Battery Light Switch on with the prompt Switch on Always on tone “click” Battery charging Flash slowly Fully charged Always on Flash fast for 30s Low power warning, with Low power and switch off continuous warning tone indication “toot”... -
Page 19: Functional & Parameter
3000000 Color CMOS 80° 150mA/3.7V(max) 4GB Nand Flash ℃ — ℃ ℃ ℃ -10 —50 15~85%RH JPEG 2048*1536 AVI Video Files Video Function D1 (736 × 480@30 (Max.)FPS) and Format Video Codec: M-JPEG USB 2.0 Windows 98SE/2000/Me/XP/Vista/Win7... - Page 20 PD20 Add:AEE Hi-Tech Park, Sun Industrial Area, Xili, Nanshan District, Shenzhen, P.R.C Tel:+86-755-29518999 Fax:+86-755-27358999 E-mail:aee@aee.com S-MPD20G18011R0...
