features of your new

air conditioner

• Cool Summer Offer
On those hot sweltering summer days and long restless nights, there is no better escape
from the heat than the cool comforts of home. Your new air conditioner brings an end to
exhausting hot summer days and lets you rest. This summer, beat the heat with your own
air conditioner.
• Cost Efficient System
Your new air conditioner not only provides maximum cooling power in the summer, but can
also be an efficient heating method in the winter with the advanced "Heat pump" system.
This technology is up to 300% more efficient than electrical heating, so you can further
reduce its running cost. Now, meet year-round needs with one air conditioner.
• A Look for Everywhere
The elegant and harmonious design gives priority to the esthetics of your space and
complements any of your existing interior décor. With its soft color and rounded-edge shape,
the new air conditioner adds class to any room. Enjoy what your air conditioner offers both
functionally and esthetically.
having sound sleep.
For easy future reference write the model and serial number
down. You will find your model number on the right side of
the air conditioner.
02_ features
function
mode allows you to set a comfortable sleep temperature while saving energy and
Model #
Serial #

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Wall Mounted Type Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Samsung Wall Mounted Type Series

  • Page 1: Air Conditioner

    features of your new air conditioner • Cool Summer Offer On those hot sweltering summer days and long restless nights, there is no better escape from the heat than the cool comforts of home. Your new air conditioner brings an end to exhausting hot summer days and lets you rest.
  • Page 2: Safety Information

    If you have any questions, call your nearest contact center or find help and information online at www.samsung.com. Important safety symbols and precautions: Hazards or unsafe practices that may result in severe personal injury or death.
  • Page 3 safety information SEVERE WARNING SIGNS WARNING Do not place the air conditioner near hazardous substances or equipment that releases free flames to avoid fire, explosions or injuries. • Potential risk of fire hazard or explosion. Do not install the outdoor unit at an unstable place or elevated surface where there is potential risk of falling.
  • Page 4 Make sure that children take precautions against access to the air conditioner and they do not play with the unit. Do not clean the interior of air conditioner on your own. • You may damage the parts which can cause electric shock or fire •...
  • Page 5 safety information SEVERE WARNING SIGNS (CONT’D) WARNING Use a receptacle that has a ground terminal. The receptacle must be used exclusively for the air conditioner. • Improper electrical grounding may cause electric shock or fire. Be sure to ground the unit. Do not connect the ground wire to gas or water pipes, lighting rods, or telephone grounding lines.
  • Page 6 Do not touch the pipe connected to the air conditioner. Install the indoor unit away from lighting apparatus using the ballast. • If you use the wireless remote control, reception error may occur due to the ballast of the lighting apparatus. Install the outdoor unit where operating noise and vibration will not disturb your neighbor and in a well-ventilated area with no obstacle.
  • Page 7 safety information CAUTION SIGNS (CONT’D) CAUTION Inspect the condition, electric connections, pipes and external case of the air conditioner regularly by a qualified service technician. Do not open doors and windows in the room being cooled during operation unless necessary. Do not block the air conditioner vents.
  • Page 8: Table Of Contents

    contents VIEWING YOUR AIR CONDITIONER 10 Checking the indoor unit and display Main parts Display 11 Removing the front panel CLEANING AND MAINTAINING 12 Cleaning the exterior 12 Cleaning the filter THE AIR CONDITIONER Air filter Bio filter 14 Replacing the filter Deodorizing filter 15 Maintaining your air conditioner Periodical checks...
  • Page 9: Viewing Your Air Conditioner

    viewing your air conditioner Congratulations on the purchase of the air conditioner. We hope you enjoy the features of your air conditioner and stay cool or warm with optimal efficiency. Please read the user manual to get started and to make the best use of the air conditioner.
  • Page 10: Removing The Front Panel

    REMOVING THE FRONT PANEL Tightly grab both side of the front panel and lift up the panel to open. Then slide the panel towards to remove the panel. Power button and Room temperature sensor You may locate the Power button on the right bottom side of the air conditioner. If the front panel is open, you can check the room temperature sensor.
  • Page 11: Cleaning And Maintaining The Air Conditioner

    cleaning and maintaining the air conditioner CLEANING THE EXTERIOR 1. Wipe the surface of the unit with a slightly wet or dry cloth when needed. Do not use Benzene, Thinner or CAUTION Clorox They may damage the surface of the air conditioner and can create a risk of fire.
  • Page 12: Bio Filter

    Bio filter Washable foam based Bio filter leads to reduction in allergens that thrive in polluted air. The filter is cleaned with a vacuum or by hand washing. 1. Remove the front panel. Tightly grab both side of the front panel and lift up the panel to open. Then slide the panel towards you to remove the panel.
  • Page 13: Replacing The Filter

    cleaning and maintaining the air conditioner REPLACING THE FILTER Replacement filter may be purchased from the retail store or ordered from the dealer where you purchased the unit. If you cannot find one, please call a contact center. Deodorizing filter Deodorizing filter absorbs efficiently cigarette smoke, pet odors and other unpleasant smells.
  • Page 14: Maintaining Your Air Conditioner

    MAINTAINING YOUR AIR CONDITIONER If the air conditioner will not be used for an extended period of time, dry the air conditioner to maintain it in best condition. 1. Dry the air conditioner thoroughly by operating in Fan mode for 3 to 4 hours and disconnect the power plug.
  • Page 15: Internal Protections Via The Unit Control System

    cleaning and maintaining the air conditioner MAINTAINING YOUR AIR CONDITIONER Internal protections via the unit control system This internal protection operates if an internal fault occurs in the air conditioner. Type Description The internal fan will be off to against cold air when the heat pump is Against cold air heating.
  • Page 16: Appendix

    appendix TROUBLESHOOTING Refer to the following chart if the air conditioner operates abnormally. This may save time and unnecessary expenses. PROBLEM SOLUTION The air conditioner • Because of the protective mechanism, the appliance does not operate does not start operating immediately to keep the unit from overloading.
  • Page 17: Operation Ranges

    appendix PROBLEM SOLUTION • Check if your batteries are depleted. Remote control is not working. • Make sure batteries are correctly installed. • Make sure nothing is blocking your remote control sensor. • Check that there are strong lighting apparatus near the air conditioner. Strong light which comes from fluorescent bulbs or neon signs may interrupt the electric waves.
  • Page 18 appendix _19...
  • Page 19 QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT www.samsung.com/ca (English) 1-800-SAMSUNG(726-7864) CANADA www.samsung.com/ca_fr (French) MEXICO 01-800-SAMSUNG(726-7864) www.samsung.com U.S.A 1-800-SAMSUNG(726-7864) www.samsung.com - Consumer Electronics 0800-333-3733 www.samsung.com ARGENTINE URUGUAY 40543733 www.samsung.com 98005420001 www.samsung.com PARAGUAY 0800-124-421 www.samsung.com BRAZIL 4004-0000 800-SAMSUNG(726-7864) www.samsung.com/cl CHILE From mobile 02-24 82 82 00...
  • Page 20: User Manual

    Wall Mounted Type Series Air Conditioner user manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register DB68-03773A -1...

Table of Contents
