INSTALLATION AND
OPERATION INSTRUCTIONS
FIREGEAR REVOLUTION UNVENTED GAS
LOG HEATER & VENTED DECORATIVE
GAS LOG HEARTH KIT - ON / OFF REMOTE
AF-1100 VALVE SERIES
If for any reason, you cannot follow these instructions, FOR
ANY REASON WHATSOEVER, just return the product to your
dealer, and the dealer will refund your money. "PLEASE" do
not use this product if you cannot follow these instructions.
CONGRATULATIONS, on the purchase of your new firegear
REVOLUTION VENTED / UNVENTED GAS LOG HEATER.
GENERAL INFORMATION
These instructions are intended as a general guide and do not
supersede national or local codes in any way. State or local
codes may only allow operation of this appliance in a vented
configuration. Check your state or local codes. Authorities
having jurisdiction should be consulted before installation.
Installation and provision for combustion and ventilation air
must conform to the National Fuel Gas Code, ANSI
Z223.1/NFPA 54, or CAN/CGA-B149.1, Natural Gas
Installation Code, or CAN/CGA-B149.2, Propane Installation
Code.
This appliance has been tested to, and complies with, ANSI
Z21.11.2 (2002), Standard for Gas-Fired Unvented Room
Heaters, & ANSI Z21.60 ( 2003 ) and CAN/CGA 2.26 ( 2003 ),
Standards For Decorative Gas Appliances For Installation In
Solid-Fuel Burning Fireplaces.
!!! IMPORTANT !!!
Read these instructions carefully before installing or operating
this gas appliance. These instructions should be left with the
homeowner for future reference.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
!!! WARNING !!!
If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury
or loss of life.
This is an un-vented gas-fired heater. It uses air ( Oxygen )
from the room in which it is installed. Provisions for adequate
combustion and ventilation air must be provided. Refer to
section " PROVISIONS FOR ADEQUATE COMBUSTION &
VENTILATION AIR " on page 6.
This appliance may be installed in an aftermarket, permanently
located manufactured ( mobile ) home, where not prohibited by
local codes.
This appliance is only for use with the type of gas indicated on
the rating plate. This appliance is not convertible for use with
other gases.
TABLE OF CONTENTS
WHAT TO DO IF YOU SMELL GAS:
<
Do not try to light any appliance.
<
Do not touch any electrical switch; do not use
any phone in your building.
<
Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
<
If you can not reach your gas supplier, call the
fire department.
Do not store combustible materials or use gasoline
or other flammable vapors and liquids in the vicinity
of this or any other appliance.
Installation and service must be performed by a:
Qualified technician, service agency, or the gas
supplier.
ANSI Z21.11.2 - (2002) STANDARD FOR GAS-FIRED
UNVENTED ROOM HEATERS (US ONLY) & ANSI Z21.60 -
(2003) / CGA 2.26 - (2003) STANDARD FOR DECORATIVE
GAS APPLIANCES FOR INSTALLATION IN SOLID-FUEL
BURNING FIREPLACES (US & CANADA). 15LP
15LP
1
1
2
2
2
3
4
6
7
8
14
15
16
16
17
21
22
REVA11 - 3.4
Advertisement
Table of Contents
Summary of Contents for Firegear AF-1100 VALVE SERIES
-
Page 1: Table Of Contents
“PLEASE” do not use this product if you cannot follow these instructions. GENERAL INFORMATION MODELS CONGRATULATIONS, on the purchase of your new firegear SHIPPING AND PACKING LIST REVOLUTION VENTED / UNVENTED GAS LOG HEATER. SAFETY INFORMATION... -
Page 2: Models
B420A11-P-T On / Off Remote Valve Liquid Propane appliance. with Thermo Remote Hearth Kit Models are to be used with the following FIREGEAR < NEVER use liquid propane gas in a natural gas unit, or Log Sets: natural gas in a liquid propane unit. -
Page 3: Specifications
SAFETY INFORMATION PERTINENT TO FIREGEAR REVOLUTION FG-360A11 GAS UNVENTED APPLICATIONS continued LOG HEARTH KIT SPECIFICATIONS NATURAL GAS - RATED PRESSURE – 3.5” W.C. WARNING: Any modification to this heater or its controls can be dangerous. MINIMUM GAS MAXIMUM GAS ORIFICE... -
Page 4: Clearances
SIDEWALL & CEILING CLEARANCES MINIMUM FIREPLACE DIMENSIONS continued MINIMUM FIREPLACE DIMENSIONS FACTORY BUILT FIREPLACES Chimney Height minimum of 10 feet – Vented Applications FRONT DEPTH HEIGHT MINIMUM WIDTH IN VENT IN SIZE INCHES INCHES INCHES SQ INCHES 30" 14" 19" 16.6 sq. - Page 5 MANTEL CLEARANCES WITHOUT HOOD continued FLOOR CLEARANCES MANTEL WITHOUT HOOD If installing the appliance at floor level, the minimum clearance to combustible material is six ( 6” ) inches. ( SEE FIGURE 5 ) HEAT RESISTANT MATERIAL 12” WITHOUT HEATER IN HOOD FIREPLACE 28”...
-
Page 6: Provisions For Combustion & Air
An unvented room heater having an input rating of more than PROVISIONS FOR ADEQUATE 10,000 Btu per hour shall not be installed in a bedroom or COMBUSTION & VENTILATION AIR bathroom; or IN UNVENTED APPLICATIONS An unvented room heater having an input rating of more than 6,000 Btu per hour shall not be installed in a bathroom. -
Page 7: Installation
Propane. If you have purchased an inappropriate unit for your flue and constructed of noncombustible materials. This unit is application, contact your retailer, installer, or the firegear NOT for use with solid fuel. Solid fuels shall NOT be burned in Customer Service Center. -
Page 8: Set-Up & Assembly
FIGURE 11 – REVOLUTION BURNER ASSEMBLY ANGLE VIEW WHEN INSTALLING THE APPLIANCE, DO NOT OBSTRUCT THE FLOW OF COMBUSTION AND VENTILATION AIR. SET UP AND ASSEMBLY Your FIREGEAR REVOLUTION VENTED / UNVENTED GAS !!! IMPORTANT !!! LOG HEARTH KIT comes assembled, ready for the gas BEFORE YOU BEGIN –... - Page 9 SET UP AND ASSEMBLY continued Affix the appliance to the fireplace / firebox floor using the Remove all contents from the Hearth Kit shipping container. appropriate screws. ( Box One ) Check the contents of the shipping container against the shipping and packing list, or the parts list in this manual.
- Page 10 FOR UNITS WITH REMOTE SYSTEMS All Firegear burner systems are capable of operation with a latching solenoid, remote control system. See the instructions, packaged with the remote system that you have purchased, for detailed installation and operational characteristics. The following instructions are a general guide for installation only.
- Page 11 HAND HELD REMOTE RECEIVER WALL MOUNT REMOTE RECEIVER See the instructions, packaged with the remote system for directions See the instructions, packaged with the remote system for directions on programming the coding switches on both transmitter and receiver. on programming, (“Learning”) both transmitter and receiver. FIGURE 15 –...
- Page 12 FINAL SET UP Lightly, spread the Glowing Embers over the lower section !!! WARNING !!! of the burner ( the burner section closest to the front of the Failure to position the parts in accordance with all included fireplace ); very little is needed to cover the area, and the pictures, diagrams, and drawings, or failure to use only parts use of too much, will retard the yellow flame, and eliminate specifically approved with this heater may result in property...
- Page 13 FINAL SET UP continued STOP! Arrange the decorative gas logs, on the burner base, according to the instructions, packaged with the gas logs. Refer to the log set up instructions, packaged with your Place the Lava Rock ( cinders ) around the Grate / Burner assembly.
-
Page 14: Operation
OPERATION FOR YOUR SAFETY – READ BEFORE LIGHTING FIGURE 27 – REAR VIEW - REVOLUTION 360 NATURAL GAS FIGURE 28 – REAR VIEW – REVOLUTION 420 LIQUID PROPANE !!! WARNING !!! Do not use this appliance if any part has been under water. Immediately call a qualified service technician to inspect the appliance, and replace any part of the control system and any gas control that has been under water. -
Page 15: Lighting Instructions
CONTROL KNOB! If gas control knob will not rotate, A fireplace screen must be in place when this appliance is in contact your installer or the firegear Service Center. operation. Unless other provisions for combustion air are ( SEE FIGURE 30 & 31 ) provided, the screen shall have an opening(s) for introduction of combustion air. -
Page 16: Maintenance & Service
See the instructions that are packaged with the remote, and/or instructions on Page 10, of this manual. Your firegear Decorative Gas Log Set should be thoroughly inspected on a regular basis, at least once a year, by a Before attempting to light the appliance with the remote, qualified installer. -
Page 17: Parts Listing
FIREGEAR REVOLUTION NATURAL GAS HEARTH KIT PARTS LIST PART NUMBER ITEM DESCRIPTION 48-38-38FL VALVE OUT & IN – REGULATOR IN – NG ONLY – BRASS HEX NIPPLE – 3/8 MALE X 3/8 MALE FLARE 49-38-38/T REGULATOR OUT – ORIFICE MOUNT – TAPPED ½ 20 FOR ORIFICE - NATURAL GAS ONLY DC-1 B –... - Page 18 FIREGEAR REVOLUTION LIQUID PROPANE HEARTH KIT PARTS LIST PART NUMBER ITEM DESCRIPTION 48-38-38FL VALVE OUT – LP ONLY - BRASS HEX NIPPLE – 3/8 MALE X 3/8 MALE FLARE 49-38-38FL REGULATOR INPUT FEED – BRASS HEX ELBOW – 3/8 MALE X 3/8 MALE FLARE – LP ONLY 49-38-38FL/T ORIFICE MOUNT –...
- Page 19 Part Number DO NOT order bolts, screws, washers or nuts. They are standard hardware items, and can be purchased at any local hardware store. Shipments are contingent upon strikes, fires, and any circumstance, beyond the control of firegear. firegear LLC Attention: Customer Service Department 38236 Abruzzi Dr.
- Page 20 FIREGEAR HEARTH KIT ACCESSORIES FIREGEAR HAND HELD REMOTE SYSTEMS FIREGEAR WALL MOUNT REMOTE SYSTEMS FG-WS-LT – WIRED WALL SWITCH FG-LT2 – HAND HELD ON/OFF REMOTE FG-WWS-LT – WIRELESS WALL SWITCH FG-LT-TH2 – HAND HELD ON/OFF THERMOSTAT REMOTE FG-WWT-LT – WIRELESS WALL TIMER FG-LMF/SM1 or 2 –...
-
Page 21: Trouble Shooting
FIREGEAR REVOLUTION VENTED / UNVENTED GAS LOG HEARTH KIT TROUBLE SHOOTING PROBLEM OBSERVED POSSIBLE CAUSE CORRECTIVE MEASURE Gas odor during set up Gas leak See " What to do if you smell gas " page 1 Check all gas connections... -
Page 22: Warranty
Refractory Gas Logs 5 years firegear is not liable for any special, indirect or consequential damages. firegear’s liability is limited to Revolution Burner 2 years the purchase price of this firegear Decorative Gas Log Set. - Page 23 NOTES:...
- Page 24 www.firegearusa.com REVA11 – 3.4...
Need help?
Do you have a question about the AF-1100 VALVE SERIES and is the answer not in the manual?
Questions and answers
How to start the pilot light
To start the pilot light on a Firegear AF-1100 Valve Series, follow these steps:
1. Read Warnings: Carefully read all safety warnings and instructions in the manual.
2. Smell for Gas: Smell around the appliance area for gas, especially near the floor since LP gas is heavier than air.
3. Turn Off Gas Control Knob: Push the gas control knob slightly and turn it clockwise to the "OFF" position. Do not force it.
4. Turn On Manual Shut-Off Valve: Slowly turn on the gas at the manual shut-off valve next to the fireplace.
5. Wait Five Minutes: Stop and wait for five minutes to ensure there is no gas buildup.
6. Check for Gas Smell: If you smell gas, stop. Turn off the gas at the manual shut-off valve, check all connections for leaks, and correct them before proceeding.
7. Locate the Pilot: The pilot is located at the rear, left-center of the burner.
8. Light the Pilot: Use a long hearth match, hand fire starter, or another approved method to light the pilot. Always light the unit using the Safety Pilot.
9. Follow Safety Instructions: Ensure all steps are followed exactly to avoid hazards.
Do not use tools to turn the gas control knob. If the knob does not turn by hand, contact a qualified service technician or installer.
