AV Receiver
TX-NR1009
Instruction Manual
Thank you for purchasing an Onkyo AV Receiver.
Please read this manual thoroughly before making
connections and plugging in the unit.
Following the instructions in this manual will enable
you to obtain optimum performance and listening
enjoyment from your new AV Receiver.
Please retain this manual for future reference.
Contents
Introduction ...................................2
Connections.................................12
Turning On & Basic Operations ......22
Advanced Operations .................44
Controlling Other Components...70
Appendix ......................................79
E
n

Advertisement

Table of Contents
loading

Related Manuals for Onkyo TX-NR1009

Summary of Contents for Onkyo TX-NR1009

  • Page 1 Instruction Manual Advanced Operations ....44 Controlling Other Components...70 Appendix ........79 Thank you for purchasing an Onkyo AV Receiver. Please read this manual thoroughly before making connections and plugging in the unit. Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your new AV Receiver.

  • Page 2: Supplied Accessories

    LIEGNITZERSTRASSE 6, 82194 GROEBENZELL, remote control sensor, as shown below. GERMANY Transmission declare in own responsibility, that the ONKYO product described in this instruction manual is in compliance with the Remote control sensor corresponding technical standards such as EN60065, AV receiver EN55013, EN55020 and EN61000-3-2, -3-3.

  • Page 3: Table Of Contents

    Components ......20 Controlling Other Components Connecting a Recording Component ......20 Connecting the Antennas ..........21 iPod/iPhone Playback via Onkyo Dock ......70 Connecting the Power Cord ......... 21 Using the Onkyo Dock..........70 Controlling Your iPod/iPhone ........71 Turning On &...

  • Page 4: Features

    • Jitter Cleaning Circuit Technology Connections • 8 HDMI Inputs (1 on front panel) and 2 Outputs • Onkyo for System Control • 6 Digital Inputs (3 Optical/3 Coaxial) • Component Video Switching (2 Inputs/1 Output) • Universal Port for the Dock for iPod ®...
  • Page 5 (Hollywood Quality Video) is registered trademark of This HD Radio Ready™ receiver is ready to receive IDT, inc. HD Radio broadcasts when connected to the Onkyo UP-HT1 “x.v.Color” is a trademark of Sony Corporation. HD Radio tuner module (sold separately).

  • Page 6: Front & Rear Panels

    Front & Rear Panels Front Panel (North American models) (European and Asian models)

  • Page 7: Display

    The actual front panel has various logos printed on it. They are not shown here for clarity. The page numbers in parentheses show where you can find the main explanation for each item. ON/STANDBY button (22) PHONES jack (42) Remote control sensor and transmitter (4) ZONE 2, ZONE 3, and OFF buttons (67) Display (9) TONE and Tone Level buttons (63)

  • Page 8: Rear Panel

    Rear Panel DIGITAL IN COAXIAL and OPTICAL jacks Composite, S-Video and analog audio jacks (BD/DVD IN, VCR/DVR IN and OUT, CBL/SAT RS232 port IN, GAME IN, PC IN, TV/CD IN and PHONO IN) Terminal for control. Multichannel input jacks REMOTE CONTROL jack (FRONT L/R, CENTER, SURR L/R, SURR BACK USB port L/R and SUBWOOFER)

  • Page 9: Remote Controller

    Controlling the AV Receiver To control the AV receiver, press RECEIVER to select Receiver mode. You can also use the remote controller to control Onkyo Blu-ray Disc/DVD player, CD player, and other components. See “Entering Remote Control Codes” for more page 74).

  • Page 10: Connections

    Connections Connecting the AV Receiver Connecting Your Speakers Connecting the Speaker Cables The following illustration shows which speaker should be connected to each pair of terminals. If you’re using only one surround back speaker, connect it to the SURR BACK L terminals. Front high Front wide Front wide...
  • Page 11 Speaker Configuration Speaker Connection Precautions The following table indicates the channels you should use Read the following before connecting your speakers: depending on the number of speakers that you have. • You can connect speakers with an impedance of between No matter how many speakers you use, a powered 4 and 16 ohms.
  • Page 12 Using Dipole Speakers You can use dipole speakers for the surround and surround back speakers. Dipole speakers output the same sound in two directions. TV/screen Dipole speakers typically have an arrow printed on them to indicate how they should be positioned.
  • Page 13 Connecting a Power Amplifier If you want to use a more powerful power amplifier, you can use the AV receiver as a preamp. Connect all speaker outputs to the power amplifier. See the manuals supplied with your amplifier for details. Note Specify “None”...

  • Page 14: About Av Connections

    About AV Connections Connecting AV components HDMI cable : Video & Audio Other cables : Video : Audio AV receiver AV receiver Blu-ray Disc/DVD Blu-ray Disc/DVD player player TV, projector, etc. Game console TV, projector, etc. Game console • Before making any AV connections, read the manuals supplied with your AV components. •...

  • Page 15: Connecting Components With Hdmi

    Connecting Components with HDMI VCR or DVD recorder/Digital Video Recorder Game console TV, projector, etc. Blu-ray Disc/DVD player Personal computer Camcorder Satellite/cable set-top box, etc. Connect your components to the appropriate jacks. The default input assignments are shown below. ✔: Assignment can be changed (➔...

  • Page 16: Connecting Your Components

    Connecting Your Components The on-screen menus appear only on a TV that is connected to the HDMI OUT MAIN. If your TV is connected to other video outputs, use the AV receiver’s display when changing settings. Front Rear Connect your components to the appropriate jacks. The default input assignments are shown below. See “Connection page 88).
  • Page 17 Jack/Port Components Assignable MONITOR OUT TV, projector, etc. BD/DVD IN Blu-ray Disc/DVD player VCR/DVR IN VCR or DVD recorder/digital video recorder, RI dock CBL/SAT IN Satellite/cable set-top box, etc. GAME IN Game console, RI dock Personal computer PC IN TV/CD IN TV, CD player, cassette tape deck, MD, CD-R, Turntable , RI dock...

  • Page 18: Connecting Onkyo Components

    Connecting Onkyo Components Make sure that each Onkyo component is connected with an analog audio cable (connection in the hookup examples) (➔ page 18). Make the connection (see the illustration). If you’re using an RI Dock, or cassette tape deck, page 41).

  • Page 19: Connecting The Antennas

    Connecting the Antennas This section explains how to connect the supplied indoor FM antenna and AM loop antenna. The AV receiver won’t pick up any radio signals without any antenna connected, so you must connect the antenna to use the tuner. North American models European and Asian models...

  • Page 20: Playback

    • “Remote Playback” (➔ • “Listening to AM/FM Radio” (➔ page 28) TOP MENU • “iPod/iPhone Playback via Onkyo Dock” (➔ page 70) This button displays the top menu for each media or service. • “Controlling Other Components” (➔ page 73) / and ENTER These buttons navigate through the menus.

  • Page 21: Understanding Icons On The Display

    MENU Playing an iPod/iPhone via USB This button returns to top menu of the Internet Radio service. This section explains how to play music/video files on the iPod/iPhone. RETURN Compatible iPod/iPhone models This button returns to the previous menu. Made for: iPod touch (1st, 2nd, 3rd and 4th generation), iPod classic, This button selects the next song.

  • Page 22: Playing A Usb Device

    (Video) is not guaranteed. any time. To enhance your Internet radio experience, the Standard Mode control http://onkyo.vtuner.com/ portal is available to you as an easy way to browse to find stations, set up/organize your The content information is not displayed, but can be favorites, add your own stations, get help, etc.

  • Page 23: Registering My Favorites

    Registering My Favorites Use / to select a program and then press ENTER. You can add the currently playing song or station to the Playback starts. “My Favorites”. You can save up to 40 Internet radio stations. Once you’ve added a station to the list, simply select it in the “My Favorites”...

  • Page 24: Playing Music Files On A Server

    Windows Media Player 11 Setup Playing Music Files on a Server This section explains how to configure Windows Media Player 11 so that the AV receiver can play the music files You need to connect the AV receiver to your home stored on your computer.

  • Page 25: Using Basic Functions

    Using Basic Functions Using the Automatic Speaker Setup With the supplied calibrated microphone, Audyssey MultEQ ® XT automatically determines the number of speakers connected, their size for purposes of bass management, optimum crossover frequencies to the subwoofer (if present), and distances from the primary listening position.
  • Page 26 When you’ve finished making the settings, press Use / to select an option, and then press ENTER. ENTER. MultEQ XT: Auto Setup MultEQ XT: Auto Setup AUDYSSEY AUDYSSEY Speakers Type(Front) Normal -- Review Speaker Configuration -- Powered Zone 2 Subwoofer Powered Zone 3 Front 100Hz...
  • Page 27 If the “Subwoofer” appears on the “Review Speaker If this message appears after 2 or 3 attempts, contact Configuration” screen as “No”, increase the subwoofer’s your Onkyo dealer. volume to the half-way point, set it to its highest crossover • Speaker Detect Error frequency, and then try running Audyssey MultEQ XT This message appears if a speaker is not detected.

  • Page 28: Advanced Operations

    Advanced Operations Advanced Setup Common Procedures in Setup Menu The on-screen menus appear only on a TV that is connected to the HDMI OUT MAIN. If your TV is connected to other video outputs, use the AV receiver’s display when changing settings. This section describes the procedure for using the RECEIVER remote controller unless otherwise specified.

  • Page 29: Input/Output Assign

    Changing the “Monitor Out” setting manually Input/Output Assign Press MONITOR OUT on the front panel. Main Menu Input/Output Assign The current setting is displayed. Monitor Out If you connect your TV to HDMI output, “Monitor Out” setting is automatically set and composite video, S-Video, Press MONITOR OUT on the AV receiver and component video sources are upconverted repeatedly to select:...
  • Page 30 HDMI Input Note • If no video component is connected to HDMI output (even if the If you connect a video component to an HDMI input, you HDMI input is assigned), the AV receiver selects the video must assign that input to an input selector. For example, if source based on the setting of “Component Video Input”.

  • Page 31: Speaker Setup

    Digital Audio Input Speaker Setup If you connect a component to a digital audio input, you Main menu Speaker Setup must assign that input to an input selector. For example, if you connect your CD player to the OPTICAL IN 1, you Some of the settings in this section are set automatically must assign “OPTICAL1”...
  • Page 32 Note Note • If the “Speakers Type(Front)” setting is set to “Bi-Amp”, “Full Band” can be selected only when “Full Band” is Powered Zone 2 cannot be used. selected in the “Front” setting. • When the “Powered Zone 2” setting is set to “Yes”, the If the “Surround”...
  • Page 33 ■ Wireless Subwoofer Level Calibration When an optional unit is connected to the This setting is set automatically by UNIVERSAL PORT jack on the AV receiver, the Audyssey MultEQ XT Room Correction and Speaker speaker setting menu may appear on screen. page 31).
  • Page 34 ■ Equalizer Settings THX Ultra2/Select2 Subwoofer With the Equalizer settings, you can adjust the tone of speakers individually with a 7-band equalizer. The volume If you’re using a THX-certified subwoofer, set this setting page 49). of each speaker can be set (➔...

  • Page 35: Audio Adjust

    Dimension Audio Adjust –3 to 0 to +3 With this setting, you can move the sound field forward or Main menu Audio Adjust backward when using the Dolby Pro Logic IIx Music With the Audio Adjust functions and settings, you can listening mode.
  • Page 36 ■ Dolby Volume ■ Neo:X Music Dolby Volume automatically adjusts the difference in Center Image volume levels which can occur between different contents 0 to 2 to 5 or source components, freeing the user from having to The DTS Neo:X Music listening mode creates 9-channel make volume adjustments.

  • Page 37: Listening Mode Preset

    ■ Fixed Mode Listening Mode Preset Off: The format is detected automatically. If no digital You can assign a default listening mode to each input input signal is present, the corresponding analog source that will be selected automatically when you select input is used instead.

  • Page 38: Miscellaneous

    1, 2, or 3 • If the absolute value is set to 82, “82Ref” will appear on the When several Onkyo components are used in the same display and the THX indicator will flash. room, their remote ID codes may overlap. To differentiate ■...
  • Page 39 Multi Zone HDMI ■ ■ Zone 2 Out, Zone 3 Out HDMI Control(RIHD) Fixed: The Zone 2/3 volume must be set on the amp in that zone. Turn this setting on to allow -compatible Variable: components connected via HDMI to be controlled by the The Zone 2/3 volume can be set on the AV receiver.

  • Page 40: Auto Standby

    ■ Audio Return Channel Note • Only the input source assigned to the HDMI IN via “HDMI Auto: Input” is enabled (➔ page 45). The audio signal from your TV tuner can be sent to • The power consumption during standby mode will increase the HDMI OUT MAIN of the AV receiver.
  • Page 41 • Perform the firmware update only when such an announcement ■ MAC Address is posted on the Onkyo web site. Visit the Onkyo web site for the This is the AV receiver’s MAC (Media Access Control) latest information. address. This address cannot be changed.

  • Page 42: Multi Zone

    Multi Zone In addition to the main listening room, you can also enjoy playback in the other room, or as we call Multi Zone. And, you can select a different source for each room. Making Multi Zone Connections Note • With this setup, the volume of Zone 2/3 is controlled by the AV There are two ways you can connect Zone speakers: receiver.

  • Page 43: Using The Remote Controller In

    • Before selecting a different input source, stop your depending on the region. iPod/iPhone playback to prevent the AV receiver from For the latest information on the Onkyo Dock selecting the iPod/iPhone input source by mistake. components, see the Onkyo web site at: •...
