Owner's Operator and Maintenance Manual
P9000
XDT
™
DEALER: This manual MUST be given to
the user of the wheelchair.
USER: BEFORE using this wheelchair, read
this manual and save for future reference.
For more information regarding
Invacare products, parts, and services,
please visit www.invacare.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P9000 XDT and is the answer not in the manual?

Questions and answers

Ольга
June 22, 2025

возможно ли сопровождающему лицу пользоваться джойстиком

0

Related Manuals for Invacare P9000 XDT

Summary of Contents for Invacare P9000 XDT

  • Page 1 Owner’s Operator and Maintenance Manual P9000 ™ DEALER: This manual MUST be given to the user of the wheelchair. USER: BEFORE using this wheelchair, read this manual and save for future reference. For more information regarding Invacare products, parts, and services, please visit www.invacare.com...

  • Page 2: Reference Documents

    INVACARE TECHNICAL SUPPORT BEFORE ATTEMPTING TO SERVICE OR OPERATE THIS EQUIPMENT - OTHERWISE, INJURY OR DAMAGE MAY RESULT. REFERENCE DOCUMENTS DOCUMENT PART NUMBER ™NX™Electronics Manual 1110532 NOTE: Updated versions of this manual are available on www.invacare.com. ™ P9000 Part No. 1118386...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS REFERENCE DOCUMENTS ..............2 REGISTER YOUR PRODUCT ............... 6 SPECIAL NOTES ................7 TYPICAL PRODUCT PARAMETERS ............ 8 LABEL LOCATIONS ................9 SECTION 1—GENERAL GUIDELINES ..........10 Controller Settings/Repair or Service ....................10 Operating Information..........................10 Tire Pressure .............................12 Electrical Accessories ..........................12 Batteries..............................12...
  • Page 4 TABLE OF CONTENTS TABLE OF CONTENTS SECTION 4—SAFETY INSPECTION/TROUBLESHOOTING ....24 Safety Inspection Checklists........................24 Inspect/Adjust Initially .........................24 Inspect/Adjust Weekly........................25 Inspect/Adjust Monthly........................25 Inspect/Adjust Periodically.........................25 Troubleshooting - Mechanical .......................26 Troubleshooting Guide ...........................26 Checking Battery Charge Level......................27 SECTION 5—WHEELCHAIR OPERATION ........... 28 SPJ™Joystick Switches and Indicators ....................28 Multi Function Charger Port ......................28 On/Off Toggle Switch .........................28 Speed Control switch .........................28...
  • Page 5 Installing/Adjusting ..........................61 Using ...............................62 SECTION 14—ANTI-TIPPERS ............63 Installing/Removing/Adjusting Anti-Tippers..................63 Installing..............................63 Removing ...............................63 Adjusting Height...........................63 SECTION 15—TRANSPORTING ............65 Transporting the P9000 XDT........................65 Unfolding/Folding the Wheelchair ....................65 Unfolding ............................65 Folding ...............................65 LIMITED WARRANTY ..............68 ™ Part No. 1118386 P9000...

  • Page 6: Register Your Product

    3. Receiving updates with product information, maintenance tips and industry news. Register ONLINE at warranty.invacare.com Please have your model number and purchase date available to complete your registration. Any registration information you submit will only be used by Invacare Corporation and protected as required by applicable laws and regulations. ™...

  • Page 7: Special Notes

    CHANGE WITHOUT NOTICE. WHEELCHAIR USER As a manufacturer of wheelchairs, Invacare endeavors to supply a wide variety of wheelchairs to meet many needs of the end user. However, final selection of the type of wheelchair to be used by an individual rests solely with the user and his/her healthcare professional capable of making such a selection.

  • Page 8: Typical Product Parameters

    TYPICAL PRODUCT PARAMETERS TYPICAL PRODUCT PARAMETERS P9000 XDT SEAT WIDTH 18 inches SEAT DEPTH 16 or 18-inches (by extension) BACK HEIGHT 17, 18, or 19 inches SEAT-TO-FLOOR 19½ inches OVERALL WIDTH Unfolded - 24½ inches (EXCLUDING JOYSTICK) Folded - 13 inches...

  • Page 9: Label Locations

    LABEL LOCATIONS LABEL LOCATIONS Crossmember Lower Frame Tube Serial Number Label Location IMPORTANT NOTICE The wheel locks on this wheelchair have been pre-set at the factory to comply with the Veterans Administration functional Standard 8320.01 of the Federal Register, paragraph 3.2.4.5.3.

  • Page 10: Section 1-General Guidelines

    SECTION 1—GENERAL GUIDELINES SECTION 1—GENERAL GUIDELINES WARNING This section contains important information for the safe operation and use of this product. DO NOT use this product or any available optional equipment without first completely reading and understanding these instructions and any additional instructional material such as Owner’s Manuals, Service Manuals or Instruction Sheets supplied with this product or optional equipment.
  • Page 11 DO NOT engage or disengage the motor release levers until the power is in the off position. Invacare strongly recommends proceeding down ramps or slopes at half speed or slower and to avoid hard braking or sudden stops. DO NOT attempt to lift the wheelchair by lifting on any removable (detachable) parts.

  • Page 12: Tire Pressure

    Batteries The warranty and performance specifications contained in this manual are based on the use of deep cycle gel cell or sealed lead acid batteries. Invacare strongly recommends their use as the power source for this unit. If wet cell batteries are used, follow all manufacturer guidelines and instructions for installation and maintenance.

  • Page 13: Charging Batteries

    SECTION 1—GENERAL GUIDELINES Charging Batteries DANGER When using an extension cord, use only a three wire extension cord having at least 16 AWG (American Wire Gauge) wire and the same or higher electrical rating as the device being connected. Use of improper extension cord could result in a risk of fire and electric shock.

  • Page 14: Grounding Instructions

    Invacare DOES NOT recommend the use of its wheelchairs as a weight training apparatus. Invacare wheelchairs have not been designed or tested as a seat for any kind of weight training. If occupant uses said wheelchair as a weight training apparatus, Invacare shall NOT be liable for bodily injury and the warranty is void.

  • Page 15: Weight Limitation

    SECTION 1—GENERAL GUIDELINES Weight Limitation The P9000 XDT has a weight limitation, including seating system and accessories, of 250 lbs. Invacare recommends that only heavy-duty wheelchairs should be used for individuals weighing more than 250 lbs. Further, the activity level of the individual wheelchair user is important.

  • Page 16: Section 2-Emi Information

    SECTION 2—EMI INFORMATION SECTION 2—EMI INFORMATION WARNING CAUTION: IT IS VERY IMPORTANT THAT YOU READ THIS INFORMATION REGARDING THE POSSIBLE EFFECTS OF ELECTROMAGNETIC INTERFERENCE ON YOUR POWERED WHEELCHAIR. Electromagnetic Interference (EMI) From Radio Wave Sources Powered wheelchairs and motorized scooters (in this text, both will be referred to as powered wheelchairs) may be susceptible to electromagnetic interference (EMI), which is interfering electromagnetic energy (EM) emitted from sources such as radio stations, TV stations, amateur radio (HAM) transmitters, two way radios, and...
  • Page 17 2) This device has been tested to a radiated immunity level of 20 volts per meter. 3) The immunity level of the product is unknown. Modification of any kind to the electronics of this wheelchair as manufactured by Invacare may adversely affect the EMI immunity levels. ™ Part No. 1118386...

  • Page 18: Section 3-Safety/Handling Of Wheelchairs

    Individual wheelchair users often develop skills to deal with daily living activities that may differ from those described in this manual. Invacare recognizes and encourages each individual to try what works best for him/her in overcoming architectural obstacles that they may encounter.

  • Page 19: Coping With Everyday Obstacles

    Keep in mind your center of gravity to maintain stability and balance. While the P9000 XDT is designed for use primarily in and around the home, the provider should determine whether this chair is suitable for the actual environment the chair will be used in.

  • Page 20: Tipping

    SECTION 3—SAFETY/HANDLING OF WHEELCHAIRS Tipping WARNING DO NOT tip the wheelchair without assistance. When tipping the wheelchair, an assistant should grasp the back of the wheelchair on a non-removable (non-detachable) part. Inform the wheelchair occupant before tipping the wheelchair and remind him/her to lean back. Be sure the occupant’s feet and hands are clear of all wheels.

  • Page 21: Lifting/Stairways

    2. Remove the battery boxes from the wheelchair. Refer to Removing/Installing the Battery Boxes on page 49. 3. If necessary, fold the wheelchair. Refer to Transporting the P9000 XDT on page 65. 4. Bend your knees and keep your back straight.

  • Page 22: Transferring To And From Other Seats

    SECTION 3—SAFETY/HANDLING OF WHEELCHAIRS Transferring to and From Other Seats WARNING ALWAYS turn the wheelchair power OFF and engage the clutches to prevent the wheels from moving BEFORE attempting to transfer in or out of the wheelchair. Also make sure every precaution is taken to reduce the gap distance by turning both casters parallel to the object you are transferring onto.

  • Page 23: Reaching And Bending - Backward

    *Wheel locks are an option. You can order the wheelchair with or without wheel locks. Transfer to and from the wheelchair in the presence of a qualified healthcare professional to determine individual safety limits. Invacare strongly recommends ordering the wheel locks as an additional safeguard for the wheelchair user.

  • Page 24: Section 4-Safety Inspection/Troubleshooting

    SECTION 4—SAFETY INSPECTION/TROUBLESHOOTING SECTION 4—SAFETY INSPECTION/TROUBLESHOOTING NOTE: Every six months or as necessary take your wheelchair to a qualified dealer for a thorough inspection and servicing. Regular cleaning will reveal loose or worn parts and enhance the smooth operation of your wheelchair. To operate properly and safely, your wheelchair must be cared for just like any other vehicle.

  • Page 25: Inspect/Adjust Weekly

    SECTION 4—SAFETY INSPECTION/TROUBLESHOOTING Inspect tires for flat spots and wear. If tires are pneumatic, check for proper inflation. Ensure seat and/or back upholstery have no rips and do not sag. Replace if necessary. Inspect/Adjust Weekly Ensure seat is secured to wheelchair frame. Ensure seat release latch is not worn and is functional.

  • Page 26: Troubleshooting - Mechanical

    Charger malfunction. Contact dealer/Invacare. Electrical malfunction. Poor connections between charger and wheel- chair. Contact dealer/Invacare for service. Battery indicator flashes the Batteries not charged. Have charger checked. charge level is low too soon Weak batteries. Replace batteries if necessary.

  • Page 27: Checking Battery Charge Level

    Power on, battery indicator flashes. Only one drive wheel turns. Electrical malfunction. Contact dealer/Invacare for service. One clutch is disengaged. Engage clutch. Joystick erratic or does not Electrical malfunction. Contact dealer/Invacare for service. respond as desired.

  • Page 28: Section 5-Wheelchair Operation

    SECTION 5—WHEELCHAIR OPERATION SECTION 5—WHEELCHAIR OPERATION WARNING After ANY adjustments, repair or service and BEFORE use, make sure that all attaching hardware is tightened securely - otherwise injury or damage may result. Set-up/programming of the Electronic Control Unit is to be performed ONLY by a qualified technician.

  • Page 29: Information Gauge Display

    SECTION 5—WHEELCHAIR OPERATION Horn Joystick Information Gauge On/Off Button Speed Control Knob To Controller Multi-Function Charger Port FIGURE 5.1 SPJ™Joystick Switches and Indicators Information Gauge Display The Information Gauge Display is located on the front of the joystick housing. It provides the following information to the user on the status of the wheelchair - 1.
  • Page 30 SECTION 5—WHEELCHAIR OPERATION DISPLAY DESCRIPTION DEFINITION COMMENTS All LEDs are off. Power is Off. All LEDs are on. Power is On. Fewer than three (3) LEDs on implies reduced battery charge. Left RED LED is flashing. Battery charge is low. The batteries should be charged as soon as possi- ble.

  • Page 31: Operating The Wheelchair

    SECTION 5—WHEELCHAIR OPERATION Operating the Wheelchair NOTE: For this procedure, refer to FIGURE 5.2 on page 32. Turning the Power On/Off 1. To turn the power ON, press the on/off button. NOTE: After turning power on, all indicators will light briefly and the display gauge will indicate one of the following: A.
  • Page 32 SECTION 5—WHEELCHAIR OPERATION 3. Move the joystick in the following manner: MOVEMENT ACTION FORWARD Push forward on the joystick. REVERSE Pull back on the joystick. Turn RIGHT Move the joystick RIGHT. Turn LEFT Move the joystick LEFT. STOP Release the joystick and the wheelchair will quickly slow down. NOTE: The joystick MUST be in the NEUTRAL position for an accurate reading of battery charge.

  • Page 33: Section 6-Front Riggings

    SECTION 6—FRONT RIGGINGS SECTION 6—FRONT RIGGINGS WARNING After ANY adjustments, repair or service and BEFORE use, make sure that all attaching hardware is tightened securely - otherwise injury or damage may result. While the wheelchair is moving, minimum ground clearance for the front rigging is three inches.

  • Page 34: Adjusting The Footrest Height

    SECTION 6—FRONT RIGGINGS Footrest Release Lever Swingaway Footrest Assembly Hinge Pins Footplate Hinge Plates FIGURE 6.1 Installing/Removing/Using the Footrest/Legrest NOTE: The footplate will be on the inside of the wheelchair when locked in place. Adjusting the Footrest Height NOTE: For this procedure, refer to FIGURE 6.2. NOTE: This procedure applies to the swingaway footrest and elevating legrest.

  • Page 35: Replacing The Heel Loop

    SECTION 6—FRONT RIGGINGS Replacing the Heel Loop NOTE: For this procedure, refer to FIGURE 6.3. 1. Pull the cam lock lever up to the unlocked position. 2. Push in the release buttons and remove the lower footrest assembly. 3. Remove the mounting screw, spacer and locknut that secure the heel loop to the footrest.
  • Page 36 SECTION 6—FRONT RIGGINGS 1. To raise the elevating legrest, the assistant should hold the support tube and raise elevating legrests until the desired height is obtained. 2. To lower the elevating legrest, perform the following: A. Support user leg with one hand. B.

  • Page 37: Section 7-Arms

    SECTION 7—ARMS SECTION 7—ARMS WARNING After ANY adjustments, repair or service and BEFORE use, make sure that all attaching hardware is tightened securely - otherwise injury or damage may result. Before performing any maintenance, adjustment or service verify that on/off switch on the joystick is in the off position.

  • Page 38: Swing-Back Arms

    SECTION 7—ARMS Swing-Back Arms WARNING Make sure the armrest release lever is in the locked position before using the wheel- chair. NOTE: For this procedure, refer to FIGURE 7.2. 1. Unlock the swing-back arms by rotating the armrest release lever towards the outside of the wheelchair.

  • Page 39: Section 8-Seat And Back

    SECTION 8—SEAT AND BACK SECTION 8—SEAT AND BACK WARNING After ANY adjustments, repair or service and BEFORE use, make sure that all attaching hardware is tightened securely - otherwise injury or damage may result. Before performing any maintenance, adjustment or service verify that on/off switch on the joystick is in the off position.

  • Page 40: Replacing The Back Upholstery

    SECTION 8—SEAT AND BACK Replacing the Back Upholstery NOTE: For the following procedure, refer to FIGURE 8.2. 1. Flip swing back arms up and out of the way. Refer to Swing-Back Arms on page 38. 2. Remove the six mounting screws and washers that secure the existing back upholstery to the back canes.

  • Page 41: Adjusting The Back Height

    SECTION 8—SEAT AND BACK Adjusting the Back Height NOTE: For this procedure, refer to FIGURE 8.3. NOTE: Back canes must be adjusted to the same height. 1. Remove the two mounting screws and locknuts that secure the two back canes to the wheelchair frame.

  • Page 42: Replacing Seat Positioning Strap

    SECTION 8—SEAT AND BACK Replacing Seat Positioning Strap NOTE: For this procedure, refer to FIGURE 8.4. 1. If necessary, remove the seat cushion from the seat upholstery. 2. Remove the two rear phillips screws and washers that secure the seat upholstery and seat positioning strap to the crossbraces.

  • Page 43: Section 9-Joystick

    SECTION 9—JOYSTICK SECTION 9—JOYSTICK WARNING After ANY adjustments, repair or service and BEFORE use, make sure that all attaching hardware is tightened securely - otherwise injury or damage may result. Before performing any maintenance, adjustment or service verify that On/Off switch on the joystick is in the OFF position.

  • Page 44: Repositioning The Joystick

    SECTION 9—JOYSTICK Repositioning the Joystick NOTE: For this procedure, refer to FIGURE 9.2. NOTE: Before starting this procedure, it may be necessary to snip the tie-wraps (not shown in FIGURE 9.2) securing the joystick control cord to the wheelchair. Before snipping the tie-wraps, note the way the cord is secured to the chair so that it can be re-secured in the same way at the end of the procedure.

  • Page 45: Section 10-Caster

    SECTION 10—CASTER SECTION 10—CASTER WARNING After ANY adjustments, repair or service and BEFORE use, make sure that all attaching hardware is tightened securely - otherwise injury or damage may result. Before performing any maintenance, adjustment or service verify that ON/OFF switch on the joystick is in the OFF position.

  • Page 46: Section 11-Batteries

    SECTION 11—BATTERIES SECTION 11—BATTERIES WARNING After ANY adjustments, repair or service and BEFORE use, make sure that all attaching hardware is tightened securely - otherwise injury or damage may result. Before performing any maintenance, adjustment or service verify that on/off switch on the joystick is in the off position.

  • Page 47: Charging Batteries

    SECTION 11—BATTERIES Charging Batteries WARNING Never attempt to recharge the batteries by attaching cables directly to the battery terminals or clamps. Use the recharging plug located on the front of the joystick. DO NOT attempt to recharge the batteries and operate the power wheelchair at the same time.

  • Page 48: Connecting The Battery Charger

    Recommended Battery Types WARNING The warranty and performance specifications contained in this manual are based on the use of deep cycle gel cell or sealed lead acid batteries. Invacare strongly recommends their use as the power source for this unit. CAUTION Failure to use the correct battery size and/or voltage may cause damage to your wheelchair and give you unsatisfactory performance.

  • Page 49: Cleaning Battery Terminals

    SECTION 11—BATTERIES 2. Remove the existing batteries from the battery boxes. Refer to Installing/Removing Batteries Into/From Battery Boxes on page 51. 3. Clean the new battery terminals. 4. Install the new batteries into the battery boxes. Refer to Installing/Removing Batteries Into/From Battery Boxes on page 51.

  • Page 50: Installing/Removing Battery Tray

    SECTION 11—BATTERIES 4. Place rear battery box onto the battery To Controller tray and connect the rear battery box to Front Battery the front battery box. Battery Box Connectors 5. Connect the front battery box to the Tray Rear Battery controller.

  • Page 51: Installing/Removing Batteries Into/From Battery Boxes

    The use of rubber gloves and chemical goggles or face shields is recommended when working with batteries. Invacare strongly recommends that battery installation and battery replacement ALWAYS be done by a qualified technician. After ANY adjustments, repair or service and BEFORE use, make sure all attaching hardware is tightened securely - otherwise injury or damage may result.

  • Page 52: Connecting Battery Cables

    SECTION 11—BATTERIES 1. If necessary, remove the battery boxes from the wheelchair. Refer to Removing/Installing the Battery Boxes on page 49. 2. Secure the battery lifting strap to battery terminal(s)/post(s). CAUTION Some battery manufacturers mold a carrying strap and/or hold down flanges directly into the battery case.

  • Page 53: Direct Mount Method

    SECTION 11—BATTERIES DO NOT USE NEGATIVE (-) POSITIVE (+) Terminal/Post Terminal/Post POSITIVE (+) Terminal/Post NEGATIVE (-) Terminal/Post U1 Batteries NEGATIVE (-) DO NOT USE POSITIVE (+) Terminal/Post Terminal/Post and Clamp (Note position of clamp) NEGATIVE (-) Terminal/Post and Clamp Group 22NF Batteries POSITIVE (+) Terminal/Post (Note position of clamp) FIGURE 11.6 Connecting Battery Cables...
  • Page 54 SECTION 11—BATTERIES CAUTION When connecting the battery cables to the battery(ies), the battery cable(s) MUST be connected to the battery terminal(s)/post(s) as shown in Detail “A” or Detail “B” of FIGURE 11.7 (depending on battery type). Otherwise, damage to the battery cable may result when installing battery terminal caps.
  • Page 55 SECTION 11—BATTERIES Detail “A” - Dual UI Batteries 1/4-20 x 7/8-Inch NEGATIVE (-) NEGATIVE (-) Hex Flange Screw Terminal/Post POSITIVE (+) Terminal/Post GREY Terminal/Post Terminal POSITIVE (+) 1/4-20 Terminal/Post Flange Locknut CONNECT CABLE RING ORANGE TERMINAL TO Tie-Wraps Terminal Cap THIS SIDE OF TERMINAL/POST Detail “B”...

  • Page 56: Battery Clamp Method

    SECTION 11—BATTERIES 8. Install the battery box(es) into the wheelchair. Refer to Removing/Installing the Battery Boxes on page 49. NOTE: New battery(ies) MUST be fully charged before using, otherwise the life of the battery(ies) will be reduced. 9. If necessary, charge the battery(ies). Refer to Charging Batteries on page 47. Battery Clamp Method CAUTION The battery clamp of the POSITIVE (+) battery terminal/post MUST be mounted in...
  • Page 57 SECTION 11—BATTERIES 2. Install battery clamp covers onto battery cables (Detail “C” of FIGURE 11.9): A. RED battery clamp cover onto RED battery cable. B. BLACK battery clamp cover onto BLACK battery cable. CAUTION When connecting the battery cable/ring terminal(s) to the battery(ies) clamp(s), the battery cable(s) MUST be connected in the position shown in Detail “A”...
  • Page 58 SECTION 11—BATTERIES Exploded View POSITIVE (+) Hex Screw RED Cable Mounting Plate Clamp NEGATIVE (-) POSITIVE (+) BLACK Cable Terminal/Post NEGATIVE (-) Terminal/Post Group 22NF Battery Detail “A” - Top View Detail “B” - Tie-Wraps Fuse box placement when POSITIVE (+) NEGATIVE (-) POSITIVE (+) box top is installed...

  • Page 59: Replacing Battery Box Retaining Strap

    SECTION 11—BATTERIES Replacing Battery Box Retaining Strap WARNING The battery box retaining strap MUST be fastened securely and adjusted properly to hold battery boxes in place before using the wheelchair. NOTE: For this procedure, refer to FIGURE 11.10. 1. Remove the battery boxes from the wheelchair. Refer to Removing/Installing the Battery Boxes on page 49.

  • Page 60: Section 12-Clutch/Motor Lock

    SECTION 12—CLUTCH/MOTOR LOCK SECTION 12—CLUTCH/MOTOR LOCK WARNING After ANY adjustments, repair or service and BEFORE use, make sure all attaching hardware is tightened securely - otherwise injury or damage may result. Engaging/Disengaging the Clutches WARNING DO NOT engage or disengage the clutches until the power is off. NOTE: For this procedure, refer to FIGURE 12.1.

  • Page 61: Section 13-Wheel Locks

    SECTION 13—WHEEL LOCKS SECTION 13—WHEEL LOCKS WARNING After ANY adjustments, repair or service and BEFORE use, make sure all attaching hardware is tightened securely - otherwise injury or damage may result. Installing/Adjusting/Using the Wheel Locks NOTE: For this procedure, refer to FIGURE 13.1 on page 62. Installing/Adjusting NOTE: Before adjusting or replacing the wheel lock assemblies, ensure that the tires are inflated to the recommended psi on the side wall of tire.

  • Page 62: Using

    SECTION 13—WHEEL LOCKS Wheel Lock Handle Wheel Lock Shoe Distance between = 5/32 to 5/16-inch FIGURE 13.1 Installing/Adjusting/Using the Wheel Locks Using The wheelchair is equipped with a pair of independently operated wheel locks located just in front of the rear wheels. 1.

  • Page 63: Section 14-Anti-Tippers

    SECTION 14—ANTI-TIPPERS SECTION 14—ANTI-TIPPERS WARNING After ANY adjustments, repair or service and BEFORE use, make sure all attaching hardware is tightened securely - otherwise injury or damage may result. Installing/Removing/Adjusting Anti-Tippers NOTE: For this procedure, refer to FIGURE 14.1 on page 64. Installing WARNING Anti-tippers MUST be fully engaged and spring buttons fully protruding out of...
  • Page 64 SECTION 14—ANTI-TIPPERS Wheelchair Frame Release Button Anti-tipper 1½ to 2-inch Release Button Clearance Anti-tipper Adjustment Holes FIGURE 14.1 Installing/Removing/Adjusting Anti-Tippers ™ P9000 Part No. 1118386...

  • Page 65: Section 15-Transporting

    The weight of the wheelchair without the user and batteries is approximately 82 lbs. Use proper lifting techniques (lift with your legs) to avoid injury. Extreme caution is advised when it is necessary to move an unoccupied power wheelchair. Invacare recommends using two assistants and making thorough preparations. Make sure to use ONLY secure, non-detachable parts for hand-hold supports.
  • Page 66 Refer to Removing/Installing the Battery Boxes on page 49 and Installing/Removing Battery Tray on page 50. Refer to Installing/Removing/Adjusting Anti-Tippers on page 63. Refer to Installing/Removing/Using the Footrest/Legrest on page 33. FIGURE 15.1 Transporting the P9000 XDT ™ P9000 Part No. 1118386...
  • Page 67 SECTION 15—TRANSPORTING NOTES ™ Part No. 1118386 P9000...

  • Page 68: Limited Warranty

    Invacare warrants all remaining components (excluding all upholstered materials, padded materials, tires and wheels) for a period of one (1) year from the date of purchase from Invacare or a dealer, with a copy of the seller’s invoice required for coverage under this warranty. If within such warranty periods any such product component shall be proven to be defective, the product component shall be repaired or replaced, at Invacare's option.
  • Page 69 ® Invacare Australia 1 Lenton Place North Rocks NSW 2151 Australia. www.invacare.com.au email: sales@invacare.com.au Phone 1800 460 460 Fax: (02) 8839 5311...

Table of Contents
