  • Page 1 Owner's Operator And Maintenance Manual POWER 9000...
  • Page 2 WARNING DO NOT OPERATE THIS EQUIPMENT WITHOUT FIRST READING AND UNDERSTANDING THIS MANUAL. IF YOU ARE UNABLE TO UNDERSTAND THE WARNINGS AND INSTRUCTIONS, CONTACT A HEALTHCARE PROFESSIONAL (DOCTOR - THERAPIST) BEFORE ATTEMPTING TO USE THIS EQUIPMENT - OTHERWISE INJURY OR DAMAGE MAY RESULT.

  • Page 3: Table Of Contents

    CHARGING THE BATTERIES ......................27 WHEEL LOCKS ........................... 28 INSTALLING ANTI-TIPPERS ......................29 DISASSEMBLY OF THE ACTION POWER 9000 FOR FOLDING AND TRANSPORTATION ... 29 ADJUSTABLE QUAD RELEASE LEVER .................... 30 BACK CANE WITH TWO (2) SCREW MOUNTING ADJUSTMENT ..........31...

  • Page 4: Special Notes

    OUT NOTICE. WHEELCHAIR USER As a manufacturer of wheelchairs, Invacare endeavors to supply a wide variety of wheel- chairs to meet many needs of the end user. However, final selection of the type of wheel- chair to be used by an individual rests solely with the user and his/her health care profes- sional capable of making such a selection.

  • Page 5: Safety Summary

    Set-up and performance adjustments of the Electronic Control Unit are to be performed ONLY by individu- als certified by Action by Invacare and also fully conversant with this process as well as the driver's capa- bilities. After the wheelchair has been set-up, check to make sure that the wheelchair performs to the speci- fications entered during the set-up procedure.
  • Page 6 Action by Invacare DOES NOT recommend the use of its wheelchairs as a weight training apparatus. Action by Invacare wheelchairs have NOT been designed or tested as a seat for any kind of weight training. If occupant uses said wheelchair as a weight training apparatus, Action by Invacare shall NOT be liable for bodily injury and the warranty will be voided immediately.
  • Page 7 SAFETY SUMMARY (continued) WARNING CAUTION: IT IS VERY IMPORTANT THAT YOU READ THIS INFORMATION REGARDING THE POS- SIBLE EFFECTS OF ELECTROMAGNETIC INTERFERENCE ON YOUR POWERED WHEELCHAIR. Electromagnetic Interference (EMI) From Radio Wave sources Powered wheelchairs and motorized scooters (in this text, both will be referred to as powered wheelchairs) may be susceptible to electromagnetic interference (EMI), which is interfering elec- tromagnetic energy (EM) emitted from sources such as radio stations, TV stations, amateur radio (HAM) transmitters, two way radios, and cellular phones.
  • Page 8 SAFETY SUMMARY (continued) WARNINGS Electromagnetic interference (EMI) from sources such as radio and TV stations, amateur radio (HAM) transmitters, two-way radios, and cellular phones can affect powered wheelchairs and motorized scooters. Following the warnings listed should reduce the chance of unintended brake release or powered wheelchair movement which could result in serious injury.

  • Page 9: Safety/Handling Of Wheelchairs

    When tilting the wheelchair, an assistant should described in this manual. Action by Invacare recog- grasp the back of the wheelchair on a non-remov- nizes and encourages each individual to try what works able (non-detachable) part.
  • Page 10 WARNING sary to move an UNOCCUPIED power wheel- BEFORE attempting to transfer in or out of the chair up or down the stairs. Action by Invacare wheelchair, every precaution should be taken recommends using two (2) assistants and mak- to reduce the gap distance. Turn both casters ing thorough preparations.
  • Page 11 PERCENTAGE OF WEIGHT DISTRIBUTION REACHING, LEANING, BENDING and BENDING - FORWARD WARNING DO NOT attempt to reach objects if you have to Position the front casters move forward in the seat or pick them up from so that they are extended the floor by reaching down between your knees.

  • Page 12: Specifications

    SPECIFICATIONS PHYSICAL DIMENSIONS POWER 9000 Seat Width Range: 14 to 20-inches - In 2-inch increments Seat Depth Range: 16 to 18-inches - In 1-inch increments Back Height Range: 14 to 18-inches - In 1-inch increments Seat-to-Floor (approximate): 18-1/2-inches- HEMI 20-1/2-inches- ADULT...

  • Page 13: Packaging/Handling

    HANDLING UNPACKING INSPECTION 1. Check for any obvious damage to the carton or 1. Examine exterior of the Action Power 9000 for its contents. If damage is evident, notify your nicks, dents, scratches or other damages. In- Dealer/Carrier. spect all components. If damage is evident, no- tify your Dealer/Carrier.

  • Page 14: Safety Inspection Checklist

    SAFETY INSPECTION CHECKLIST Initial adjustments should be made to suit your personal body structure and preference. Thereafter follow these maintenance procedures. ITEM INITIALLY INSPECT/ INSPECT/ INSPECT/ ADJUST ADJUST ADJUST WEEKLY MONTHLY PERIODICALLY GENERAL Wheelchair rolls straight (no excessive drag or pull to one side). CLOTHING GUARDS Ensure all fasteners are secure.

  • Page 15: Troubleshooting

    Eliminate mechanical cause. Trips. wheel locks engaged. Reset circuit breaker. Circuit Breaker Trips repeatedly; Electrical malfunction. Contact Dealer/Action by Invacare for Service. wheels turn freely. Batteries draw excessive current Battery failure. Check batteries for shorted cell. when charging. Replace if necessary.

  • Page 16: Checking Battery Charge Level

    CHECKING BATTERY CHARGE LEVEL (FIGURE 1) NOTE: Action by Invacare recommends that the following procedures be performed by an Autho- rized Dealer or Qualified Service Technician. The following “Do’s” and “Don’ts” are provided for your convenience and safety. DON’T Don’t perform any installation or...

  • Page 17: Using Hydrometer To Check Battery Cells

    AVAILABLE) (LEAD ACID) (FIGURE 2) discharged battery will exhibit the same symp- toms as a bad one. NOTE: Action by Invacare recommends that 3. Remove the footrests from the chair and place ONLY qualified service personnel perform the the front of the chair against a wall, workbench hydrometer test.

  • Page 18: Motor Testing

    There are two (2) contact brushes on ACTION far as possible. Do this several times to guard POWER 9000 motors located under the brush caps against burn damage. on the motor housing. If these caps are hard to re- 10.

  • Page 19: Electro-Mechanical Parking Brake Testing

    If either condition exists, it is recommended and run the chair. A motor with only one brush that the motor be sent to Action by Invacare replaced will only carry a small percentage of its Technical Service for inspection/repair.

  • Page 20: Installing The Int-P9 Controller Onto The Wheelchair

    INSTALLING THE INT-P9 CONTROLLER 6. Connect the controller left/right motor and bat- tery leads to the motors and batteries. ONTO THE WHEELCHAIR (FIGURE 1) NOTE: The controller mounting tube is factory set REPOSITIONING THE CONTROLLER for installation onto the right side of the wheel- MOUNTING TUBE (FIGURE 2) chair.

  • Page 21: Installing The Mkiv Rii Controller And Bracket Onto The Wheelchair

    5. Reposition the tube on the right side of the con- CAUTION troller. Make sure that the mounting holes in the Make sure the draw latches of the controller controller and tube are aligned. bracket are securely fastened to the mounting 6.

  • Page 22: Adjusting The Mounting Bracket Width

    3. Line up the mounting holes of the controller 4. Install the long two (2) hex screws through the mounting bracket with the mounting holes in the controller mounting bracket, spacers, plate and two (2) half clamps. controller mounting bracket and securely tighten with the two (2) locknuts.

  • Page 23: Battery Tray Installation

    BATTERY TRAY INSTALLATION (FIGURE 6) 5. Secure the hanger bracket with button socket screws and locknut. 1. Unfold the wheelchair. 6. Repeat STEPS 3-5 for the opposite hanger 2. Remove the battery tray from the packaged con- bracket. tainer. 7. Refer to the following chart or FIGURE 6 and NOTE: The button socket screws will be posi- determine the required mounting holes for the tioned in the correct mounting holes of the bat-...

  • Page 24: Recommended Battery Types

    Failure to use the correct size and/or voltage TOOL QUANTITY COMMENTS may cause damage to the wheelchair and re- sult in unsatisfactory performance. Battery Supplied For: Lifting Strap Group 22 Only Power 9000 Power 9000 Wrenches: 18/20-inch 14/16-inch 1/2-inch box hex Not Supplied wide chair wide chair...
  • Page 25 The positive (+) terminal MUST connect to the 7. Replace the battery box(es) under the seat of positive (+) terminal/post, otherwise serious the Action Power 9000. Secure the battery damage will occur to the electrical system. box(es) using the mounting straps supplied.

  • Page 26: Wiring Harness Connections

    WIRING HARNESS CONNECTIONS b. Attach the right and left motor connectors to the (FIGURE 10) controller connectors. c. Connect the wiring harness connector (BLUE) NOTE: Thread the connectors through the small to the controller connector (BLUE). opening in the connector boot. After all connec- tions have been made, close the boot by attach- d.

  • Page 27: Charging The Batteries

    Required Items: CHARGING THE BATTERIES (FIGURE 11) TOOL QUANTITY COMMENTS NOTE: New batteries MUST be fully charged prior to initial use of the chair. Battery Charger Supplied Extension Cord Not Supplied WARNING (3-prong plug, 15 ampere current rating; Always charge new batteries before initial use industrial type).

  • Page 28: Wheel Locks

    NOTE: Allow eight (8) hours for normal charg- ing. Larger batteries (greater than 55 ampere- hours) or severly discharged batteries may re- quire up to sixteen (16) hours to be properly charged and equalized. If the charger operates for sixteen (16) hours and is unable to fully charge the batteries, an internal timer turns the charger off and begins to fast blink the green light.

  • Page 29: Installing Anti-Tippers

    3. Remove the battery boxes from the wheelchair. INSTALLING ANTI-TIPPERS (FIGURE 13) 4. Lift up on the battery tray to disengage the key WARNING slot from the crossbrace and remove from the Anti-tippers MUST be attached and pointing rear of the wheelchair (FIGURE 15). DOWN towards the ground/floor BEFORE us- ing the wheelchair.

  • Page 30: Adjustable Quad Release Lever

    ADJUSTABLE QUAD RELEASE LEVER (FIGURE 20) Invacare's patented swingaway footrest and legrests are now provided with an adjustment screw and locknut to custom fit the snugness of the swingaway quad release lever to your pref- erence. To Adjust: 1. Loosen the locknut (item 1) with a wrench and back out the screw (item 2) with a phillips screw- driver.

  • Page 31: Back Cane With Two (2) Screw Mounting Adjustment

    BACK CANE WITH TWO (2) SCREW MOUNITNG ADJUSTMENT (FIGURE 21) FIGURE 21 - BACK CANE WITH TWO (2) SCREW MOUNITNG ADJUSTMENT...

  • Page 32: Limited Warranty

    This warranty gives you specific legal rights and you may also have other legal rights which vary from state to state. Invacare warrants the side frames and crossbraces to be free from defects in materials and work- manship for a period of three (3) years from date of purchase; electronics, motors and gearboxes for a period of one (1) year from the date of purchase.
