Appendix; Specifications - Pioneer MCS-333 Operating Instructions Manual

Chapter 10

Appendix

Specifications

General
Power requirements
Power consumption
Dimensions (W x H x D)
Net Weight (Approx.)
Operating temperature
Operating humidity
Inputs/Outputs
HDMI IN/OUT (video/audio)
ANALOG AUDIO IN
DIGITAL IN (OPTICAL)
PORTABLE IN
MIC
USB
Tuner
FM Tuning Range
Antenna input
Amplifier
Power output (RMS) THD 30 % (AUX)
Total
Front
Center
Rear
Sub-Woofer
System
Laser
Signal system
LAN port
Bus Power Supply (USB)
AC 220 V to 240 V, 50 Hz/60 Hz
145 W (In Standby mode: Less than 0.5 W)
Approx. 430 mm x 63 mm x 349 mm
3.1 kg
5 °C to 35 °C
5 % to 85 %
®
19 pin (HDMI /™ Connector)
2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R) x 1
3 V (p-p), Optical jack x 1 (48 kHz, 96 kHz sampling)
0.5 Vrms (3.5 mm stereo jack)
Mic jack x 2
4 pin A Type x 2
87.5 MHz to 108.0 MHz
75 Ω unbalanced
1000 W
170 W × 2 (4 Ω)
170 W (4 Ω)
170 W × 2 (4 Ω)
170 W (4 Ω)
Semiconductor laser
Standard PAL/NTSC colour TV system
Ethernet jack x 1, 10BASE-T / 100BASE-TX
Front: DC 5 V 500 mA
Rear: DC 5 V 500 mA
Appendix 69
