- Page 1 ShoreTel Mobility Router 4000 Series Hardware Installation Guide...
-
Page 2: Version Information
ShoreGear, ShorePhone, and ShoreWare are registered trademarks of ShoreTel, Inc. in the United States and/or other countries. The ShoreTel logo is a trademark of ShoreTel, Inc. in the United States and/or other countries.. All other copyrights and trademarks herein are the property of their respective owners. -
Page 3: Table Of Contents
“Connecting to the Network” on page 7 “Connecting to the Console Port” on page 8 “Connecting Power” on page 9 “Using the Initial Configuration Wizard” on page 10 ShoreTel Mobility Router 4000 Series Hardware Installation Guide... -
Page 4: Specifications
Specifications The Mobility Router is one rack unit (RU) high and installed in a standard 19-inch (48.26-cm) rack. Figure 1-1. Front View of RoamAnywhere Mobility Router 4000 Series Figure 1-2. Rear View of RoamAnywhere Mobility Router 4000 Series Table 1-1... - Page 5 Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11) Safety: CSA/EN/IEC/UL 60950-1 Compliant, UL or CSA Listed (USA and Canada), CE Marking (Europe) ShoreTel Mobility Router 4000 Series Hardware Installation Guide...
-
Page 6: Unpacking A Mobility Router
A copy of this document Before starting the installation: Open the carton and remove the contents. If any contents are missing or damaged, contact ShoreTel Technical Support at +1.408.331.3300 or http://support.shoretel.com. Keep the packing materials and save the carton. -
Page 7: Installation Requirements And Recommendations
Mounting screws to rack mount the Mobility Router (not provided) Screwdriver (not provided) 1.4.4 Uninterruptible Power Supply We recommend installing the Mobility Router in an existing Uninterruptible Power Supply (UPS) infrastructure. ShoreTel Mobility Router 4000 Series Hardware Installation Guide... -
Page 8: Installing The Mobility Router
Install each Pan Head screw through the Mobility Router’ s mounting ears into the mounting nuts. Figure 1-4. Fastening the Mobility Router to the Rack tbd screws being inserted (with arrows) into ears Tighten to 30 inch-lbs. Do not over-tighten. ShoreTel Mobility Router 4000 Series Hardware Installation Guide... -
Page 9: Connecting To The Network
Insert the other end of the Ethernet cable to the left Ethernet port (ETH0) on the rear of the Mobility Router. NOTE If using the Secure Remote Voice feature, connect the second Ethernet port (ETH1) to the external network. Figure 1-5. Connecting the Ethernet Cable to the Mobility Router ShoreTel Mobility Router 4000 Series Hardware Installation Guide... -
Page 10: Connecting To The Console Port
HyperTerminal) and select the appropriate COM port. Configure the port using the following settings: Baud rate: 9600 bps Data bits: 8 Parity: None Stop bits: 1 Flow control: None ShoreTel Mobility Router 4000 Series Hardware Installation Guide... -
Page 11: Connecting Power
The Mobility Router automatically powers on. As the Mobility Router starts up, messages display in the terminal emulation software window. Use the initial configuration wizard to initially configure the Mobility Router with “Using the Initial Configuration Wizard” on page ShoreTel Mobility Router 4000 Series Hardware Installation Guide... -
Page 12: Using The Initial Configuration Wizard
Enter the subnet mask in the format of a 32-bit mask or classless interdomain routing (CIDR) notation. Enter the IP address of the default gateway for the Mobility Router. Enter the IP address of the primary DNS server. ShoreTel Mobility Router 4000 Series Hardware Installation Guide... - Page 13 After verifying access to the Administration Portal, disconnect the serial cable. (Console access is no longer required.) The ShoreTel Mobility Router is now ready to be configured using the Administration Portal. For more information, see the RoamAnywhere Mobility Router Administrator’ s Guide.
- Page 14 ShoreTel Mobility Router 4000 Installation Using the Initial Configuration Wizard ShoreTel Mobility Router 4000 Series Hardware Installation Guide...
