To avoid excessive condensation occurring within
the boiler flue the boiler should wherever possible, be
sited to ensure the shortest possible flue run is
utilised.
6.8 For compartment installation the requirements of
BS6798 and BS5440: Part 2 must be met.
The compartment must be of sufficient size to
permit access for inspection and servicing or the
removal of the boiler and any ancillary equipment.
Any space used for airing clothes or storage must be
separated from the appliance by a non-combustible
partition. Where the partition is formed from
perforated material, then the major dimension of the
apertures shall not exceed 13mm.
No combustible surface must be within 50mm of the
boiler casing without protection.
There must be 50 mm clearance between the
compartment door and boiler case.
Where the boiler's flue pipe passes through the
airing space, it must be protected by a non-
combustible sleeve or fire stop which has a
minimum clearance of 25 mm from the flue pipe. In
addition, if the flue pipe passes through the partition
then the clearance gap of the flue pipe or its guard
with the partition must not exceed 13 mm.
6.9 When the boiler is intended for use with LPG it must
10
not be installed in a room or internal space below
ground level.
7. Flue Terminal Location
7.1 The flue terminal must be sited with minimum
clearances as specified in
becomes problematic or causes a nuisance a plume
management kit is available from your stockist.
7.2 Current regulations and standards require a terminal
guard to be fitted where the terminal is accessible to
touch or at risk of being damaged. All wall mounted
terminals sited within 2m of the level which people have
normal access, should be adequately protected with a
suitably sited guard.
7.3 Where the flue terminates within 1m of a plastic or
painted gutter or within 500mm of painted eaves then
protection should be provided in the form of an
aluminium shield at least 1m in length, fitted to the
underside of the gutter or painted surface.
Figure 7.1
. Note if pluming
