Comtrend Corporation CT-5365 Installation Manual page 10

B. Connection using Ethernet cable
Connect the yellow Ethernet cable (6) to
the Ethernet card on the PC and to one of
the router's connectors labelled as 1X to
4X
Switch the PC on. The corresponding LAN
indicator will light up in green after a few
seconds. This LED will blink when transfe-
rring data.
WPS
WPS
For further information please refer to sections 3.5 of the user's manual on the
Advanced Settings CD
10
WLAN LAN 1X LAN 2X LAN 3X LAN 4X ADSL ALARMA
