Kärcher K 2300 G Operator's Manual

Karcher high pressure washer operator manual
Hide thumbs

Advertisement

Table of Contents

Model K 2300 G
High Pressure Washer Operator Manual
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2
Assembly Instructions . . . . . . . . . . . . . . . . . . . . . . . . .3
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . .4
Using the Accessories . . . . . . . . . . . . . . . . . . . . . . . . .5
Working with Detergents . . . . . . . . . . . . . . . . . . . . . . .6
Shut Down and Clean-Up . . . . . . . . . . . . . . . . . . . . . .7
Taking a Break . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Winterizing and Long-Term Storage . . . . . . . . . . . . . .7
Cleaning Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-9
Optional Cleaning Accessories . . . . . . . . . . . . . . . . . .9
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . .10-11

Specifications

Operating pressure
Water volume
Engine
 800- 537- 4129
2300 PSI
2.5 GPM
5.0 HP Honda
Part No. 1.194-110.0

Advertisement

Table of Contents
loading

Related Manuals for Kärcher K 2300 G

Summary of Contents for Kärcher K 2300 G

  • Page 1: Table Of Contents

    Model K 2300 G High Pressure Washer Operator Manual Overview ........1 Precautions .

  • Page 2: Overview

    MODEL K 2300 G OVERVIEW Item Description 1. Triple jet nozzle 2. Water inlet 3. Spray wand 4. Oil fill cap not pictured 5. Gas tank 6. Trigger gun 7. Trigger gun safety lock 8. Handle 9. High Pressure Hose 10.
  • Page 3 5-gallon container. • The water supply temperature must not exceed 104°F/40°C. • Never use the pressure washer to draw in water contaminated with solvents, e.g. paint thinners, gasoline, oil, etc. • Always prevent debris from being drawn into the unit by using a clean water source.

  • Page 4: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Required tools: adjustable pliers. Step 1 Attach the front guard to the frame. Align holes, insert bolt and tighten with lock nut. Step 4 Attach the triple jet nozzle to the spray wand. Step 6 Check oil level. Oil level should be to the oil filler neck.

  • Page 5: Operating Instructions

    OPERATING INSTRUCTIONS Step 1 Connect the high pressure hose to the unit’s high pressure outlet. Step 3 Connect garden hose to the cold water source and turn water on completely. Step 5 Slide the throttle control to the fast position. Move the choke lever to the “CHOKE”...

  • Page 6: Using The Accessories

    USING THE ACCESSORIES The triple jet nozzle must be positioned to one of the two settings for high pressure cleaning by turning the the nozzle tip. The pencil jet spray (0º) should be used for stubborn dirt. The High pressure flat spray (25º) should be used for cleaning over a large surface area. The third setting on the triple jet nozzle is used for the application of detergents.

  • Page 7: Working With Detergents

    Special formula won’t clog the suction tube filter and will pro- tect the internal parts of the pressure washer for a longer life. For Karcher Detergents, check your retailer or call: 1-800-537-4129 The following Karcher detergents are available: •...

  • Page 8: Shut Down And Clean-Up

    SHUTTING DOWN & CLEAN-UP Step 1 Remove detergent suction tube from container and insert into one gallon of fresh water. Siphon water at low pressure for one minute. Step 5 Disconnect the garden hose from the water inlet on the unit. TAKING A BREAK...

  • Page 9: Cleaning Tips

    (for best results, limit your work area to sections of approximately 6 feet and always apply detergent from bottom to top). Allow Karcher House Wash to remain on surface 1-3 minutes. Do not allow detergent to dry on surface, if surface appears to be drying, simply wet down surface with fresh water.

  • Page 10: Optional Cleaning Accessories

    • If painted surfaces are pealing or chipping, use extreme caution as pressure washer may remove the loose paint from the surface. Use extreme caution when cleaning decks,...

  • Page 11: Troubleshooting

    Engine throttle is not in correct position. For additional engine problems Pressure built up in the refer to the engine high pressure washer. owners manual. Unit does not reach Diameter of garden hose high pressure. is too small. Water supply is restricted.

  • Page 12: Troubleshooting

    Check that all fittings are tight. Thermal protection device will automatically reset. Call service center. Call service center. If you encounter any additional difficulties not listed, please call our service center for help. Karcher Customer Support USA 1-800- 537-4129...
