  • Page 1 Real time Pump/ Hydro-Turbine/ Blower Performance Monitoring with Censeo User Manual BGX501-806-R02...
  • Page 2 Copyright © 2013, SIHPL Page 2 of 20 BGX501-806-R02, Censeo User Manual Public...
  • Page 3: Table Of Contents

    5.10 Alarms and Events ............................18 5.11 Relays ................................18 5.12 Data Storage ............................... 18 5.13 Time Management............................18 5.14 Security ................................ 18 5.15 Transactions ..............................18 Frequentlty Asked Questions (FAQs) ..................19 Public BGX501-806-R02, Censeo User Manual Page 3 of 20...
  • Page 4: Important

    8. We conduct rigorous testing during the design and manufacture of our products to ensure that they comply with appropriate standards. 9. Secure Meters Ltd. assumes no responsibility for damage arising from misuse of our products such as, but not limited to, the following: •...
  • Page 5: Introduction

    3 Introduction Censeo product family is the latest offering from Secure Meters aimed towards measuring and monitoring critical pump/ hydro-turbine/ blower performance parameters with high accuracy in commercial and industrial pump/ hydro-turbine/ blower installations. Censeo – • Monitors and displays pump/ hydro-turbine/ blower operating parameters in real time with the help of temperature and pressure sensors and a power meter.
  • Page 6: Pump/ Hydro-Turbine Flow Measurement (Variant Dependent)

    Operating temperature 0 ºC to 70 ºC Storage temperature -10 ºC to 70 ºC Ingress protection IP54 Max. tolerable humidity Up to 95% non-condensing 4.1.7 Compliances Electrical IEC61326-1, CISPR22, BS:EN 61010-1 Page 6 of 20 BGX501-806-R02, Censeo User Manual Public...
  • Page 7: Basic System Block Diagram For Pump Flow Measurement

    5 V DC supply to Tsi Phase/ Positive -5 V - 5 V DC supply to Tdi Note: Pin details may vary with variants. Interpret the diagram and table above for the right variant. Public BGX501-806-R02, Censeo User Manual Page 7 of 20...
  • Page 8: Parts Description

    3. Front plate: Made of fire resistant poly carbonate material, the front plate is opaque and is covered with an additional transparent plate. It accommodates a four button keypad and a PACT port. The front plate also accommodates the rating plate as shown here. Page 8 of 20 BGX501-806-R02, Censeo User Manual Public...
  • Page 9: Firmware Features

    Through highly precise electronic probes and transducers, it is possible to measure such differential changes in temperature and pressure. Once accurate numerical data is available, actual losses in the system can be calculated using thermodynamic equations. When input/ output electrical power to/ from the motor/ generator Public BGX501-806-R02, Censeo User Manual Page 9 of 20...
  • Page 10: Benefits

    (mA) MegaPascal (MPa) Watt (W) Power kiloWatt (kW) millibar Frequency Hertz (Hz) pounds per square inch Pressure Vibration Hertz (Hz) (psi) centimetre Speed inch Efficiency percentage metre Absolute humidity Percentage Page 10 of 20 BGX501-806-R02, Censeo User Manual Public...
  • Page 11: Keys

    When pressed once, the display scrolls to the previous Short display page available in the sequence. Reset When these buttons are pressed simultaneously for 5 Long (5 sec) display seconds, Censeo reset the display page to show first-page, first-display. Public BGX501-806-R02, Censeo User Manual Page 11 of 20...
  • Page 12: Display

    RS485 communication port and baud rate of the optical port. Page 12 of 20 BGX501-806-R02, Censeo User Manual Public...
  • Page 13: Displays

    (for pump) hydro-turbine/ blower) Suction temperature Inlet temperature (for pump) (for hydro-turbine/ blower) Discharge Outlet temperature temperature (for (for hydro-turbine/ pump) blower) Differential Differential temperature (for temperature (for pump/ hydro-turbine) blower) Public BGX501-806-R02, Censeo User Manual Page 13 of 20...
  • Page 14 Current R-Phase Voltage Y-Phase Current Y-Phase Voltage B-Phase Current B-Phase Frequency Average Power Factor Motor Efficiency (for Generator Efficiency pump/ blower) (for hydro-turbine) Drive Efficiency (for Mass Flow Rate (for blower) blower) Page 14 of 20 BGX501-806-R02, Censeo User Manual Public...
  • Page 15: Display - Pump/ Hydro-Turbine/ Blower Parameters

    Discharge Temperature Table 5: Available Pump Parameters for Page 2 display in Censeo The available hydro-turbine parameters for Page 2 display are as follows: Hydro-Turbine Parameter Name Display Efficiency Flow Rate Public BGX501-806-R02, Censeo User Manual Page 15 of 20...
  • Page 16: Display - Motor/ Generator Parameters

    The available parameters for Page 3 display are as follows: Parameter Name Display Voltage R phase Voltage Y phase Voltage B phase Current R phase Current Y phase Current B phase Drive Power/ Generated Power Average Power Factor Page 16 of 20 BGX501-806-R02, Censeo User Manual Public...
  • Page 17: Displays - Alarm Parameters

    Censeo reads the cumulative energy for pump/ hydro-turbine/ blower from the power meter connected over Modbus, which can be read and displayed (in kWh) on page 1 display as shown below. The refresh rate of cumulative energy value is 1 minute. Public BGX501-806-R02, Censeo User Manual Page 17 of 20...
  • Page 18: Communication

    Censeo maintains a record of last 100 transactions with time stamp in a rollover manner. Page 18 of 20 BGX501-806-R02, Censeo User Manual Public...
  • Page 19: Frequentlty Asked Questions (Faqs)

    Ans. To verify the firmware version, press the Up ( ) and Down ( ) buttons simultaneously for 5 seconds. The firmware version is shown on the first page of meter information displays. Public BGX501-806-R02, Censeo User Manual Page 19 of 20...
  • Page 20 Secure Meters Ltd Secure Meters (UK) Ltd Pratapnagar Industrial Area Secure House, Moorside Road Udaipur 313 003 Winchester, Hampshire SO23 7RX India United Kingdom p: + 91 294 2492300 p: +44 1962 840048 f: +91 294 2492310 f: +44 1962 841046...
