Features:
•
Porcelain Coated Cast Iron
•
Stainless Steel Thermometers
•
Chrome Plated Warming Racks
Gas Grill Features:
•
40,800 BTU
•
Stainless Steel Tube Burners
•
12,000 BTU Side Burner
•
Cast Brass Side Burner
•
Electronic Igniters
Charcoal Grill Features:
•
Start charcoal with gas burner
•
Adjustable Height Charcoal
Grate
•
Side Fire Box Optional for Texas
Style Smoking
LOW
!
SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE. IF YOU ARE ASSEMBLING
THIS UNIT FOR SOMEONE ELSE, GIVE THIS
MANUAL TO HIM OR HER TO SAVE FOR
FUTURE REFERENCE.
OWNER'S MANUAL
MODEL#DC50
Gas & Charcoal Grill
LP
WARNING:
Improper installation, adjustment, alteration,
service or maintenance could cause injury
or property damage Read the installation,
operation and maintenance instructions
thoroughly before assembling or servicing
this equipment.
Failure to follow these instructions could
result in fire or explosion that could cause
property damage, personal injury or death.
DANGER:
DO NOT use gas grill for indoor cooking or
heating. TOXIC fumes can accumulate and
cause asphyxiation. Do not use in or on
boats or recreational vehicles.
PROP 65 WARNING:
Chemicals known to the state of California
to cause cancer, birth defects or other
reproductive harm are created by the
combustion of propane.
A propane gas cylinder is required for
operation.
for commercial use.
This gas grill is not intended

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DC50 and is the answer not in the manual?

Questions and answers

Related Manuals for Char-Griller DC50

Summary of Contents for Char-Griller DC50

  • Page 1 OWNER’S MANUAL MODEL#DC50 Gas & Charcoal Grill Features: • Porcelain Coated Cast Iron • Stainless Steel Thermometers • Chrome Plated Warming Racks Gas Grill Features: • 40,800 BTU • Stainless Steel Tube Burners • 12,000 BTU Side Burner • Cast Brass Side Burner •...
