Canon Pixma iP5200 Quick Start Manual page 10

• To view the On-screen Manual, double-click the iP5200 On-screen Manual shortcut icon on the
desktop, or click Start and select All Programs (or Programs), Canon iP5200 Manual and
iP5200 On-screen Manual.
• Microsoft Internet Explorer
8
11
Read the message and click Print Head
Alignment.
It takes about six minutes to finish printing. Do not open
the Top Cover while printing.
12
Ensure that the pattern shown on the
left is printed.
The Print Head is aligned automatically. The printer is
now ready to use.
• If the pattern is not printed successfully, refer to
"Eleven flashes" in "The ALARM Lamp Flashes
Orange" of the User's Guide.
• The pattern is printed in black and blue.
13
After print head alignment is completed,
click Next.
14
When the Installation Results screen
appears, click Next.
15
When the screen shown on the left
appears, click Exit.
If the screen shows a check box for restarting your
system, you can restart the system instead of just exiting
the program. To restart the system, ensure that the check
box is selected, and then click Restart.
®
5.0 or later must be installed to view the On-screen Manuals.
