Carlton 2015 Owner's Manual

Drum style brush chippers
Hide thumbs
Table of Contents

Advertisement

Quick Links

Drum Style Brush Chippers
Machine Serial #
Engine Model & Spec #
Engine Serial #
PTO/Clutch Model & Spec #
Clutch Serial #
Purchase Date
Dealer
Carlton
J.P.Carlton Company
Div. D.A.F. Inc.
121 John Dodd Road
Spartanburg, SC 29303
Ph. (864) 578-9335
Fax (864) 578-0210
www.stumpcutters.com
Model 2015
_____________
_____________
_____________
_____________
_____________
_____________
_____________

Advertisement

Table of Contents
loading

Related Manuals for Carlton 2015

Summary of Contents for Carlton 2015

  • Page 1 Drum Style Brush Chippers Model 2015 Machine Serial # _____________ Engine Model & Spec # _____________ Engine Serial # _____________ PTO/Clutch Model & Spec # _____________ Clutch Serial # _____________ Purchase Date _____________ Dealer _____________ Carlton J.P.Carlton Company Div. D.A.F. Inc.
  • Page 3 DIESEL ENGINE EXHAUST WARNING CALIFORNIA Proposition 65 Warning Diesel engine exhaust and some of its constituents are known to the State of California to cause cancer, birth defects, and other reproduction harm.
  • Page 5 CHIPPER SAFETY ALERT...
  • Page 7 CHIPPER SAFETY ALERT...
  • Page 9 CHIPPER SAFETY ALERT...
  • Page 11 CHIPPER SAFETY ALERT...
  • Page 13 CHIPPER SAFETY ALERT...
  • Page 15 CHIPPER LIMITED WARRANTY J. P. Carlton Co. Inc., hereafter referred to as the “Manufacturer”, warrants each new Carlton Chipper to be free of defects in workmanship and material for a period of one year. This warranty takes effect upon delivery to the original retail purchaser. The manufacturer at its option will replace or repair at a point designated by the manufacturer, any parts which appear to have been defective in material or workmanship.
  • Page 17 The manufacturer will provide replacement parts at no cost to the customer for defective parts during the warranty period. Defective parts must be returned to J. P. Carlton Company. It will be the customer’s responsibility to install the replacement parts unless arrangements are made with the selling dealer.
  • Page 19 11. _______ Customer has been advised that maintenance and adjustment on the clutch are critical. Customer has been advised that J. P. Carlton Co. does not warrant the clutch and the only warranty that applies is in the clutch manufacturer’s manual. Contact the clutch manufacturer with warranty issues.

  • Page 21: Table Of Contents

    CHIPPER TABLE OF CONTENTS INTRODUCTION FOREWORD GENERAL INFORMATION MACHINE FEATURES MACHINE SPECIFICATIONS OPERATION SAFETY PRECAUTIONS DAILY CHECKLIST MACHINE CONTROLS TOWING GUIDE MACHINE OPERATION MAINTENANCE MACHINE MAINTENANCE LUBRICATION TROUBLESHOOTING GUIDE SERVICING HYDRAULICS SERVICING PTO/CLUTCH SERVICING CUTTER SYSTEM SERVICING BELTS SERVICING FEED WHEEL MOTOR MACHINE WIRING PARTS DECAL ASSEMBLY...

  • Page 23: Foreword

    15” DRUM FOREWORD Congratulations on your purchase of a new Carlton Professional Chipper! Carlton has built ® ® its reputation on the superior performance and reliability of their stump grinders and you can be assured your new chipper has the same performance and reliability. A machine is not profitable if it’s broken-down and we do our absolute best to help you avoid costly downtime.

  • Page 24: General Information

    Any reference made to the right, left, front, or rear in relationship to the chipper is illustrated in the following pictures. Please refer to these any time you call your dealer or J. P. Carlton for parts or assistance.

  • Page 25: Machine Features

    15” DRUM MACHINE FEATURES Available Machine Features: • Turbo charged diesel • Tapered roller bearings • Axle 90000# cap • AR400 anvil • Tires - Rated 4805 engine • Auto-Feed • 2 knives ® Plus system pounds @ 125 PSI •...
  • Page 26 3 1/2” x 20” x ½” AR400 Radiator Guards: Drum Fans: 12 ¼” x 2 1/2” x 6.75” Light Brackets: 3/16” with hidden wiring Hitch Plate: ¾” Plate adjustable 5” Up/Down Cutting Dimensions: Throat Opening: 15” x 20” F:\data\John\Docs\Machine Docs\Machine Specs\2015 Apache SPECS 140 Deere.DOC...
  • Page 27 15” DRUM SAFETY PRECAUTIONS Before operating the chipper, read this manual, the engine manual, and all the safety decals on the machine. Know all parts of the machine and their functions, especially the shut down procedures in case of emergency. No inexperienced person may operate the chipper. Inexperience may cause injury.

  • Page 28: Operation

    (prescription, over the counter, or • Never position, adjust, or move the otherwise). discharge chute while the chipper or • DO NOT modify or change any part the cutter drum are running without written approval from J. P. Carlton Company.
  • Page 29 15” DRUM SAFETY PRECAUTIONS • Always have at least 2 operators at the job site running the chipper. One to load the brush into the feed wheels and the other to maintain the feed control bar in case of an accident. •...
  • Page 30 15” DRUM SAFETY PRECAUTIONS DO NOT PERFORM MAINTENANCE OF ANY KIND ON THIS MACHINE UNLESS: The engine is turned off The ignition key is removed Positive battery cable is disconnected The clutch is disengaged • YOKE LOCK PIN MUST BE IN Feed control bar is in neutral POSITION before performing All machine parts have come to a...
  • Page 31 Decals may be purchased from J. • Keep unauthorized persons away from P. Carlton or an authorized dealer. • the chipper operation area. Remove all foreign objects from the chipper...
  • Page 32 15” DRUM DAILY CHECKLIST It is vital that the owner and operators inspect the chipper each day before operation. This inspection will help identify potential problems that may arise during the workday. The operators must get in the habit of performing this inspection each and every day. By performing this inspection each day, the operators will help minimize downtime and costly repairs.

  • Page 33: Daily Checklist

    15” DRUM DAILY CHECKLIST • Make sure all personnel are equipped with all applicable safety equipment: − Eye protection − Hearing protection − Hard hat − Short, fitted gloves − Long sleeve shirt − Long pants − Over the ankle work boots with skid resistant soles PERSONAL PROTECTION: All personnel must wear eye and...
  • Page 34 15” DRUM DAILY CHECKLIST • Check tires air pressure. Inflate to tire manufacturers recommended maximum inflation pressure. Inspect tires for wear. Inspect axle caps. Replace tires and other parts when needed. Grease axles as suggested by manufacturer. HITCH & HITCH BOLTS •...
  • Page 35 15” DRUM DAILY CHECKLIST • Inspect knife bolts and nuts for tightness daily. It is very important to check knife bolts and nuts after first hour of operation for new bolts and nuts. It is not uncommon for bolts to loosen slightly during this time.
  • Page 36 • Check the feed control bar operation daily for correct operation of Forward, Reverse, and Off positions. Contact your local dealer or J. P. Carlton if operation is not correct. • Inspect and clean radiator screen daily. This screen along with the radiator fins must be kept clean.
  • Page 37 15” DRUM DAILY CHECKLIST REMOVE ENGINE COVER AND CHECK OIL DIPSTICK • Check and maintain proper engine oil OIL LEVEL (see warning decal), fuel, radiator coolant, and hydraulic oil levels. Make sure engine is cool before checking. Replenish engine oil, fuel, radiator coolant, and hydraulic oil every morning before starting the machine so there is no danger of fire from hot machine parts or...
  • Page 38 15” DRUM DAILY CHECKLIST WINCH (OPTIONAL EQUIPMENT – LEVER STYLE SHOWN) • Inspect winch rope daily. Replace rope if there is any wear, fraying, or cuts. See Machine Controls section for more information. • Check rollers for burrs or sharp edges if rope is damaged in any way.
  • Page 39 15” DRUM MACHINE CONTROLS It is imperative that all operators are familiar with all controls of the chipper. This will make for a much more productive and safer work period. (The actual controls may differ depending on the engine supplied with your chipper.) ENGINE CONTROLS: •...
  • Page 40 15” DRUM MACHINE CONTROLS • Also in the control box is a diagnostic gauge/hour meter. The configuration at the right is typical for this engine; but may vary depending on the make and model of the engine supplied with your chipper.
  • Page 41 15” DRUM MACHINE CONTROLS CLUTCH ENGAGEMENT HANDLE • The clutch is to be engaged and disengaged at low engine speeds only. NEVER ENGAGE OR DISENGAGE THE PTO/CLUTCH AT ENGINE SPEEDS IN EXCESS OF 1200 RPM. Engagement or disengagement of the clutch at elevated engine speeds can cause severe clutch damage.
  • Page 42 FLAP WHILE THE CHIPPER IS IN OPERATION OR WHILE THE CHIPPER DRUM IS SPINNING! HEIGHT ADJUSTABLE DISCHARGE • Carlton Chippers are equipped with a height adjustable discharge chute. This allows the discharge chute to be adjusted for different truck heights and discharge angles.

  • Page 43: Machine Controls

    15” DRUM MACHINE CONTROLS FEED CONTROL BAR • The feed control bar is located on three sides of the infeed chute; across the top and down each side. • The feed control bar has three distinct positions − In the out position pulled towards the FEED CONTROL BAR rear of the machine the bar is now in the feed position.
  • Page 44 LIFT CYLINDER CONTROL VALVE • The Carlton drum chipper is equipped with a hydraulic yoke lift, which allows the operator to hydraulically lift the top feed wheel. This can be of assistance...
  • Page 45 15” DRUM MACHINE CONTROLS SLIDE AIR VENTS • The drum chipper is equipped with two slide air vents, one on each side of the cutter drum. Open these vents to allow air to circulate if you are chipping AIR VENT CLOSED material that is very fine.
  • Page 46 15” DRUM MACHINE CONTROLS FEED WHEEL CLEAN OUT DOOR • There is a drop-down door to clean excess debris out from under the bottom feed wheel. This will help to keep the chipper from getting clogged or stopped up. Use the handles, located on both sides behind the infeed chute, and drop the door down to remove debris, then close and secure the door.
  • Page 47 15” DRUM MACHINE CONTROLS WINCH CONTROL VALVE (OPTIONAL EQUIPMENT) • Carlton Chippers may be equipped with a hydraulic winch. The winch is used to pull trees and brush that are too large to carry to the chipper and to assist in lifting the tree into the infeed tray.
  • Page 48 15” DRUM MACHINE CONTROLS • Two hydraulic valves control the winch on this chipper. The hydraulic selector valve diverts hydraulic fluid from the feed roller circuit and enables the hydraulic winch circuit. Once the hydraulic winch circuit is enabled the winch control valve controls the hydraulic winch motor.
  • Page 49 15” DRUM MACHINE CONTROLS • The winch drum rotates counter- clockwise when pulling in loads. If the rope needs to be replaced make sure it is started under the drum. • Winding the rope over the top (clockwise) could cause the rope to rub on the encasement and wear the rope causing fraying and breakage.
  • Page 50 15” DRUM MACHINE CONTROLS • The winch drum rotates counter- clockwise when pulling in loads. If the rope needs to be replaced make sure it is started under the drum. • Winding the rope over the top (clockwise) could cause the rope to rub on the encasement and wear the rope causing fraying and breakage.

  • Page 51: Towing Guide

    15” DRUM TOWING GUIDE SAFETY: • NEVER ALLOW INEXPERIENCED DRIVERS TO TOW MACHINERY. • ALWAYS MAKE SURE THE TRUCK HITCH AND THE CHIPPER HITCH ARE OF MATCHING STYLE AND SIZE. • ALWAYS MAKE SURE THE TOW VEHICLE AND THE CHIPPER ARE ON LEVEL GROUND AND THE WHEELS ARE CHOCKED BEFORE CONNECTING OR DISCONNECTING THE CHIPPER.
  • Page 52 15” DRUM TOWING GUIDE CONNECT LIGHTS • Connect chipper lights to the tow vehicle. Observe light operation to insure correct electrical connections. • Attach the breakaway switch to the tow vehicle so that it will engage the switch and slow the chipper if the chipper should become uncoupled from the tow vehicle.
  • Page 53 15” DRUM TOWING GUIDE • Make sure the discharge chute is over the chipper for towing. Use the swivel handle to turn the discharge chute over the chipper with the end of the chute facing the front of the chipper. Use the height adjustment handle to return the discharge chute back to the lowest height for towing;...

  • Page 54: Machine Operation

    15” DRUM MACHINE OPERATION STARTING – READ THIS MANUAL, THE ENGINE OWNERS’ MANUAL, THE CLUTCH MANUAL, AND ALL SAFETY DECALS ON CHIPPER BEFORE STARTING. SAFETY: • DO NOT ALLOW CHILDREN OR OTHER SPECTATORS TO STAND AND WATCH THE CHIPPER IN OPERATION. ALL OPERATORS MUST WEAR RECOMMENDED PROTECTIVE EQUIPMENT.
  • Page 55 15” DRUM MACHINE OPERATION AIM DISCHARGE CHUTE • Carlton Chippers are equipped with a rotating discharge chute. To rotate the chute to the desired position 1. Pull down and unlock the rotation lock pin 2. Turn the crank handle to rotate the discharge chute to desired position 3.
  • Page 56 15” DRUM MACHINE OPERATION • Carlton Chippers are equipped with a height adjustable discharge chute. This allows the discharge chute to be adjusted for different truck heights and discharge angles. • To adjust discharge chute height: − Flip retainer up out of the way of the crank handle −...
  • Page 57 15” DRUM MACHINE OPERATION • Start engine at idle and allow sufficient THROTTLE SWITCH -HIGH time for oil to circulate before proceeding. A two-position switch is located next to the key switch in the control panel. The lower (idle) position is for starting the engine, low speed engine operation during warm up, clutch engagement/disengagement, and engine...
  • Page 58 15” DRUM MACHINE OPERATION TURN AUTO-FEED PLUS ON CONTROLS MAY VARY DEPENDING ON AUTOFEED OPTION) • The Auto-Feed Plus® monitors the engine RPM and controls the feed system based on this information. The Auto-Feed® is calibrated when installed in the chipper with a high and low RPM setting for the feed wheels to operate.
  • Page 59 SECTIONS IN THIS MANUAL. NEVER ENGAGE OR DISENGAGE ∗ J. P. CARLTON CO. DOES NOT THE PTO/CLUTCH AT ENGINE WARRANT THE CHIPPER CLUTCH. SPEEDS IN EXCESS OF 1200 RPM. READ THE CLUTCH MANUAL FOR Engagement or disengagement of the THE MANUFACTURER’S...
  • Page 60 15” DRUM MACHINE OPERATION THROTTLE SWITCH -HIGH INCREASE THROTTLE • Once the clutch has been fully engaged the engine can be run at full speed. Push the throttle switch up to increase speed. • The engine should always be run at high RPM while material is being chipped or the Auto-Feed Plus will stop the feed wheels until the RPM is above the...
  • Page 61 15” DRUM MACHINE OPERATION • Always feed trees and brush walking to the right side of the chipper, material being fed should be to the operators’ left side. When the material is being fed into the feed wheels it tends to kick to the left and an operator could be injured if loading the material from the left side.

  • Page 62: Machine Operation

    15” DRUM MACHINE OPERATION LIFT CONTROL • The Carlton drum chipper comes equipped with a hydraulic yoke lift, which allows the operator to hydraulically lift the top feed wheel. This can be of assistance when feeding large square cut butt ends, which the feed wheels cannot ride up easily.
  • Page 63 DO NOT operate the winch if the feed wheels still turn. Contact J. P. Carlton or the local dealer for service. 2. Put the winch in free spool by putting both levers on the winch drum in FREE.
  • Page 64 15” DRUM MACHINE OPERATION 3. Pull the winch rope to the tree. Always wear leather gloves when handling winch rope. Broken wires will cause injuries. 4. Attach the winch rope to the tree. 5. Secure the winch rope through the loop never on the rope itself.
  • Page 65 15” DRUM MACHINE OPERATION NEVER ALLOW ANYONE TO OPERATE THE WINCH CONTROL VALVE WHILE AN OPERATOR IS IN THE VICINITY OF THE WINCH ROPE!!! ROPE BURNS OR OTHER INJURIES COULD OCCUR IF THE PERSON BECAME ENTANGLED OR TRIPPED BY THE ROPE. ROPE COULD BREAK OR COME LOOSE AND WHIP AROUND AND CAUSE SEVERE INJURY.
  • Page 66 15” DRUM MACHINE OPERATION SHUT DOWN PROCEDURES • With engine RPM still high, push the feed control bar to the middle (off) position. Feed wheels should not be turning. THROTTLE SWITCH -HIGH • Push the throttle down into the low position so that the engine can slow down (idle) and the clutch can be disengaged.
  • Page 67 15” DRUM MACHINE OPERATION • Secure the discharge chute. Rotate the discharge chute back over the chipper and lock the swivel releasing the lock pin into one of the lock grooves. Make sure the height adjustment is at the lowest position so that the chute will not be high enough to hit any overhead obstructions and secure the handle.

  • Page 68: Machine Maintenance

    15” DRUM MACHINE MAINTENANCE DO NOT PERFORM MAINTENANCE OF ANY KIND ON THIS MACHINE UNLESS: The engine is turned off The ignition key has been removed The positive battery cable has been disconnected The clutch is disengaged Feed control bar is in neutral All machine parts have come to a complete stop –...
  • Page 69 Refer to engine manual supplied with your chipper. DIESEL FUEL • Check fuel level daily and replenish as necessary. Carlton chippers are equipped with fuel level indicators and lockable cap covers.
  • Page 70 15” DRUM MACHINE MAINTENANCE FUEL FILTER & FUEL/WATER SEPARATOR Replace the fuel filter every 500 hours of operation or 6 months. Follow the engine owner’s manual on how to remove the filters and to drain the fuel/water separator. Only use engine manufacturer approved fuel filters.
  • Page 71 • Before starting to chip any wood, always test the feed control bar. Make sure the reverse, stop, and forward feed positions work properly. • Contact Carlton or an authorized dealer immediately if the control bar doesn’t work properly in any of the three positions.
  • Page 72 15” DRUM MACHINE MAINTENANCE FEED WHEEL TENSION SPRINGS • The upper feed wheel has two tension springs. These springs should only be tight enough to keep the feed wheel teeth from slipping on the material. DO NOT OVER TIGHTEN! If the springs are overly tight, it will over work the hydraulic system and make it difficult to feed large material.
  • Page 73 15” DRUM MACHINE MAINTENANCE LIGHTS WIRING • Check lighting wire connections for damage, and loose or broken wires. • Make sure the lights are working properly at all times when towing. • See the Machine Wiring section of this manual for wiring diagram. BREAKAWAY SWITCH •...
  • Page 74 15” DRUM MACHINE MAINTENANCE JACK STAND – FRONT • Check the lock pins to make sure they are fitting properly and in good shape. Replace any pins that are worn, bent or damaged in any way. Make sure holes GREASE for lock pins are not worn or stretched.
  • Page 75 15” DRUM MACHINE MAINTENANCE GENERAL INSPECTION • Check all screws, bolts, and nuts on the chipper at least once a month unless otherwise specified. Check for tightness and wear. Replace any that won’t stay tightened or that have missing or chipped threads.

  • Page 76: Lubrication

    • Always clean tip of grease gun fitting and grease fitting on machine before attaching hose to prevent dirt from being forced into machine parts. IF THE BEARINGS ON YOUR CHIPPER DON’T LOOK LIKE THE ONES SHOWN IN THE FOLLOWING PICTURES, PLEASE CONTACT J. P. CARLTON OR A LOCAL DEALER FOR LUBRICATION INFORMATION.
  • Page 77 15” DRUM LUBRICATION CHIPPER – LEFT SIDE YOKE LIFT ARM CUTTER DRUM BEARING BEARING GREASE FITTING GREASE FITTING GREASE DAILY * 1-2 PUMPS OF GREASE WEEKLY ON EACH BEARING EQUIPPED WITH DEXTER AXLES, EITHER E-Z LUBE® FEED CONTROL BAR OR NEV-R-LUBE® – GREASE FITTING SEE DEXTER * GREASE AS...
  • Page 78 15” DRUM LUBRICATION CHIPPER – RIGHT SIDE YOKE LIFT ARM CUTTER DRUM DOOR BEARING HINGES GREASE FITTING GREASE FITTING * 1-2 PUMPS OF GREASE (2 PLACES) WEEKLY ON EACH * 1-2 PUMPS OF GREASE BEARING WEEKLY ON EACH EQUIPPED WITH DEXTER AXLES, EITHER E-Z LUBE®...
  • Page 79 15” DRUM LUBRICATION CHIPPER – RIGHT SIDE CLOSE-UP DISCHARGE SWIVEL DISCHARGE HEIGHT PLATE (3 PLACES) ADJUSTMENT GREASE FITTING GREASE FITTING * GREASE EVERY 3 * GREASE AS MONTHS, APPROX. 300 NECESSARY EVERY 100 HOURS OF OPERATION HOURS OF OPERATION DISCHARGE SWIVEL HANDLE GREASE FITTING * GREASE AS...
  • Page 80 15” DRUM LUBRICATION CHIPPER – WINCH (OPTIONAL EQUIPMENT) GREASE FITTINGS (4 PLACES) * EVERY 30-40 HOURS OF OPERATION GREASE AS NECESSARY (SAME FOR BOTH STYLES) WINCH PLUNGERS LEVER STYLE * SPRAY LUBRICANT ON PLUNGERS EVERY 30-40 HOURS OF OPERATION FREEWHEEL STYLE WINCH DRUM GREASE FITTING...

  • Page 81: Troubleshooting Guide

    15” DRUM TROUBLESHOOTING GUIDE DO NOT PERFORM ANY INSPECTION OR SERVICE ON THE CHIPPER WITHOUT MAKING SURE: THE CUTTER DRUM IS DISENGAGED AND HAS COME TO A COMPLETE STOP; THE CUTTER DRUM LOCK PIN IS INSTALLED; THE ENGINE HAS BEEN TURNED OFF, THE IGNITION KEY HAS BEEN REMOVED AND THE BATTERY CABLE HAS BEEN DISCONNECTED;...
  • Page 82 15” DRUM TROUBLESHOOTING GUIDE COMPLAINT CAUSE CORRECTION • • Auto-Feed not working Faulty or broken wiring Repair or replace wires – properly or at all wiring diagram enclosed in this manual • • Settings not correct Reset following Auto- Feed/Houston street manual instructions enclosed in this manual •...

  • Page 83: Servicing Hydraulics

    Allow system to warm up too low • • Pump has excessive wear Replace pump Any other problems, please contact your local dealer or J. P. Carlton Co. ONLY USE QUALIFIED PERSONNEL TO WORK ON HYDRAULIC SYSTEMS FOR REPAIRS OR REPLACEMENT OF PARTS!!
  • Page 84 CARDBOARD; DO NOT USE HAND OR FINGER. ALWAYS WEAR EYE PROTECTION. HYDRAULIC OIL & FILTER • This Carlton chipper has an in-tank hydraulic filter and a level/temp gauge. Check hydraulic oil daily, before and during use. Refill with AW-32 hydraulic oil, same as supplied by the manufacturer.
  • Page 85 SERVICE HYDRAULICS Check hydraulic oil level daily. This Carlton chipper is equipped with a gauge that shows the level of oil and the temperature of the oil. When filling the tank with oil, the window of the gauge will also fill with oil as the level gets higher in the tank.
  • Page 86 15” DRUM SERVICE HYDRAULICS HOSES AND FITTINGS • Inspect hoses and fittings for leaks, tightness, wear, or damage. Replace any hoses and fittings that need replacing. • FLUID UNDER PRESSURE CAN PENETRATE THE SKIN AND CAUSE SEVERE INJURY. CHECK HOSES AND FITTINGS USING A BOARD OR CARDBOARD;...
  • Page 87 Adjust pressure only if necessary and after testing with a pressure gage. To increase pressure turn clockwise until it bottoms out. Recheck pressure. Contact J. P. Carlton or your dealer for more information. ADJUSTMENT VALVE FOR THE TOP FEED WHEEL (G1)
  • Page 88 15” DRUM TWIN DISC, INC. PTO/CLUTCH DO NOT PERFORM MAINTENANCE OF ANY KIND ON THIS MACHINE UNLESS: The engine is turned off The ignition key has been removed The positive battery cable has been disconnected The clutch is disengaged Feed control bar is in neutral All machine parts have come to a complete stop –...
  • Page 89 EP (extreme pressure) additive recommended for use in high-speed roller bearings operating at 200°F (93.3°C). ® Carlton uses TEXACO STARPLEX II grease. Listed below are the manufacturer’s suggested guidelines for lubrication: 1. Release Bearing – using a hand-operated...
  • Page 90 15” DRUM TWIN DISC, INC. PTO/CLUTCH CLUTCH ADJUSTMENT The clutch in this machine does not automatically adjust to compensate for wear of the clutch facing(s) and therefore must be manually adjusted. Maintaining the correct engagement pressure is the responsibility of the owner/operator. The owner/operator must periodically adjust the clutch to ensure correct clutch operation.
  • Page 91 15” DRUM TWIN DISC, INC. PTO/CLUTCH The preferred method of checking the force CHECK ENGAGEMENT FORCE AT EITHER required to engage the clutch is using a END OF THE CROSS-SHAFT torque wrench to check the foot-pounds required to engage the clutch. The torque wrench should be used at the cross shaft to measure engagement force.
  • Page 92 15” DRUM SERVICE CUTTER SYSTEM DO NOT PERFORM MAINTENANCE OF ANY KIND ON THIS MACHINE UNLESS: The engine is turned off The ignition key has been removed The positive battery cable has been disconnected The clutch is disengaged Feed control bar is in neutral All machine parts have come to a complete stop –...
  • Page 93 • Do not remove and replace knife bolts and nuts more than 3 times before replacing with new bolts and nuts. • Nuts are security lock nuts. DO NOT USE ANY OTHER STYLE OF NUTS. You must purchase these nuts from Carlton or an authorized dealer.
  • Page 94 • If knives are too narrow to grind, replace SHARP EDGE NEW KNIFE SHARP EDGE with a complete set of new knives. • Knives are hardened steel made to Carton’s specifications. Use only Carlton chipper knives as replacements.
  • Page 95 15” DRUM SERVICE CUTTER SYSTEM • Reassemble knives in the pocket making sure they seat flat. • Tighten knife bolts (3/4”-10) and nuts. Torque to 235 ft. lbs. • Do not over tighten knife bolts. Torque only to the recommended amount. Knives that are overly tight can crack or bow around the hole.
  • Page 96 15” DRUM SERVICE CUTTER SYSTEM • Check the clearance between the knives and the anvil. The clearance for the knife to anvil should be between .070” and .090” (1.78 – 2.29 mm). Use a feeler gage that measures within that range.
  • Page 97 15” DRUM SERVICE CUTTER SYSTEM • Checking and setting the clearance by ANVIL ADJUSTMENT BOLTS the knife that is the closest to the anvil will be the best place to start. • If clearance needs to be adjusted, loosen the six anvil bolts; just loose enough to be able to move the anvil with the adjuster bolts.
  • Page 98 15” DRUM SERVICE CUTTER SYSTEM • After the clearance has been set, tighten the anvil bolts (1/2”-13) and torque to 75 ft. lbs. • Retighten the nuts on the adjustment bolts that were loosened earlier. • Recheck the anvil/knife clearance to make sure nothing changed when tightening the bolts.
  • Page 99 KNIVES PART NO DESCRIPTION 0900144 Knife – 5/8” x 5 1/2” x 10-1/2” 12A-1222ZI HEX C/S 3/4”-10 X 2 3/4” UNC GR8 Z&Y 3/4” Security Lock Nuts – Purchase from JP 0900131 Carlton or Dealer...
  • Page 100 • The anvil is hardened steel made to Carton’s specifications. Use only Carlton anvils as replacements or damage may occur. Purchase the new anvil from Carlton or an authorized dealer. • To rotate or replace the anvil, remove the anvil bolts and washers. There are six anvil bolts, each with a flat washer and a lock washer.
  • Page 101 • The anvil is hardened steel made to Carton’s specifications. Use only Carlton anvils as replacements or damage may occur. Purchase the new anvil from Carlton or an authorized dealer. • When the anvil has been replaced, replace the angle and the bolts that were removed earlier.
  • Page 102 15” DRUM SERVICE CUTTER SYSTEM • Replace the two eyebolts on each end of the anvil. Put the eyebolts on the two long bolts after the washers are on. • The adjuster eyebolts must be inserted through the slot provided to make clearance adjustments.
  • Page 103 Check pin for distortion and cracks. • If any problems are discovered, contact Carlton or your local dealer for repair or replacement. THE CUTTER DRUM DOOR IS ONE OF THE MOST IMPORTANT PIECES OF SAFETY EQUIPMENT ON THIS CHIPPER.

  • Page 104: Belt Tension

    15” DRUM SERVICE V-BELT DO NOT PERFORM MAINTENANCE OF ANY KIND ON THIS MACHINE UNLESS: The engine is turned off The ignition key has been removed The positive battery cable has been disconnected The clutch is disengaged Feed control bar is in neutral All machine parts have come to a complete stop –...
  • Page 105 15” DRUM SERVICE V-BELT ENGINE MUST BE OFF AND IGNITION KEY REMOVED BEFORE CHECKING BELT TENSION. ALL PARTS MUST BE COMPLETELY STOPPED. ALLOW ALL PARTS TO COOL COMPLETELY TO PREVENT BURNS. CLUTCH MUST BE DISENGAGED. • Insert a screwdriver or metal bar (a metal ruler would be good) through the slot to check belt tension.
  • Page 106 15” DRUM SERVICE V-BELT LOOSEN INSIDE JAM • Loosen the inside jam nuts on the NUTS ON ADJUSTMENT EYEBOLTS adjustment eyebolts. • Turn the outside jam nuts clockwise, moving the engine closer to the front of the machine and tightening the belt. Make only slight adjustments at a time and recheck tension.
  • Page 107 15” DRUM SERVICE V-BELT CHECK BELT GUARDS • Check and retighten bolts daily. • Check condition of bolt threads when belt guards are removed or if a bolt won’t tighten or won’t stay tightened. • Replace any bolts that are worn or damaged.
  • Page 108 15” DRUM SERVICE V-BELT • Install the new belt using the same procedure only in reverse. Put the belt on the cutter drum sheave first and then the engine sheave. • Never pry the new belt onto the sheave! Move the engine back further if needed. •...
  • Page 109 15” DRUM SERVICE V-BELT • Replace the belt guard cover and tighten bolts. • NEVER RUN MACHINE WITHOUT ALL GUARDS IN PLACE AND SECURED. ROTATING PARTS ARE DANGEROUS AND COULD CAUSE SEVERE INJURY. REPLACING SHEAVE OR BUSHING • If it becomes necessary to replace a sheave or bushing, replace only one at a time.
  • Page 110 15” DRUM SERVICE V-BELT • When the sheave is loose on the bushing, remove the setscrew in the bushing. • Remove the bushing from the shaft and from the sheave. • Remove the sheave and replace with new sheave. • Insert old or new bushing, lining up keyway with the keyway on the shaft.
  • Page 111 There is a special tool required to separate the motor and coupling once it is off the machine, contact J. P. Carlton or your local dealer to purchase the puller. CHANGE MOTORS ONE AT A TIME. • The following instructions are for the...
  • Page 112 15” DRUM SERVICE FEED WHEEL MOTOR WARNING: RELEASE HYDRAULIC PRESSURE BEFORE PERFORMING ANY SERVICE TO HYDRAULIC LINES OR OTHER COMPONENTS. FLUID UNDER PRESSURE CAN PENETRATE THE SKIN AND CAUSE SEVERE INJURY. SEEK IMMEDIATE MEDICAL ATTENTION IF SKIN IS PENETRATED. CHECK HOSES AND FITTINGS USING A BOARD OR CARDBOARD;...
  • Page 113 • There is a special tool required to separate the motor and coupling once it is off the machine, contact J. P. Carlton or your local dealer to purchase the puller. • Attach the separating tool to the coupler as shown and screw the three bolts from the bushing into the tool in the outside holes.
  • Page 114 15” DRUM SERVICE FEED WHEEL MOTOR • Replace with new motor. Clean the threads on the motor, the 1” nut, and the coupling with degreaser before beginning to replace all the parts. LINE UP KEY WITH KEYWAY ON COUPLING • Attach the torque arm to the new motor using the 1/2”...
  • Page 115 15” DRUM SERVICE FEED WHEEL MOTOR • Return the feed wheel motor assembly to the machine and tighten the bolts in the bushing. Tighten each bolt a little at a time to pull the coupling into place as straight as possible. Try not to pull one side on faster than the other or damage may occur to the bushing and the coupling.

  • Page 116: Machine Wiring

    WIRING MAY BE DIFFERENT DEPENDING ON ENGINE SUPPLIED WITH THE CHIPPER. IF YOU HAVE A CHIPPER WITH AN ENGINE OTHER THAN CATERPILLAR OR JOHN DEERE, CONTACT J. P. CARLTON, FOR THE WIRING DIAGRAM. SEE THE ENGINE OWNER’S MANUAL FOR THE ENGINE WIRING DIAGRAM...
  • Page 117 WIRING MAY BE DIFFERENT DEPENDING ON ENGINE SUPPLIED WITH THE CHIPPER. IF YOU HAVE A CHIPPER WITH AN ENGINE OTHER THAN CATERPILLAR OR JOHN DEERE, CONTACT J. P. CARLTON, FOR THE WIRING DIAGRAM. SEE THE ENGINE OWNER’S MANUAL FOR THE ENGINE WIRING DIAGRAM...

  • Page 118: Decal Assembly

    15” DRUM DECAL ASSEMBLY CHIPPER – LEFT SIDE ITEM # PART # DESCRIPTION 0700313A NOTICE – CHIPPER KNIFE 0700327 DANGER – FEED HOPPER 0700317 WARNING – PRESSURE LEAKS 0700301 DANGER – MOVING PARTS 0700323-1 DISK/DRUM LOCK TUBE 0700326 MOTOR COUPLER GUARD 0700328 NOTICE –...
  • Page 119 15” DRUM DECAL ASSEMBLY CHIPPER – RIGHT SIDE ITEM # PART # DESCRIPTION 0700060 CARLTON OX DECAL 0700304 DANGER – AIRBORNE CHIPS 0700306 DANGER – VINE TYPE MATERIAL 0700307 DANGER – INJURY/DEATH 0700308 NOTICE – ADJUST PTO/CLUTCH 0700309 NOTICE – DECAL MAINTENANCE 0700310 NOTICE –...
  • Page 120 15” DRUM DECAL ASSEMBLY CHIPPER – RIGHT SIDE AUXILIARY VIEWS ITEM # PART # DESCRIPTION 0700324-1 YOKE LOCK PIN 0700332 CONTINUOUS FEED 0700324-3 YOKE LIFT 0700329-3 WINCH CONTROL – IN/OUT 0700329-1 WINCH SELECTOR – FEED WHEELS ON/WINCH ON 0700316 WARNING – DIESEL FUEL 0700314 WARNING –...
  • Page 121 15” DRUM DECAL ASSEMBLY CHIPPER – REAR ITEM # PART # DESCRIPTION 0700318 PUSH - REVERSE 0700307 DANGER – INJURY/DEATH DANGER – KEEP CLEAR...
  • Page 122 15” DRUM DECAL ASSEMBLY CHIPPER – WINCH (OPTIONAL) LEVER STYLE WINCH ITEM # PART # DESCRIPTION 0700330 WINCH OPERATION (for lever style only)
  • Page 123 2015 Carlton J.P.Carlton Company Div. D.A.F. Inc. 121 John Dodd Road Spartanburg, SC 29303 Ph. (864) 578-9335 Fax (864) 578-0210 www.stumpcutters.com...
  • Page 124 21610053 WELDMENT,FENDER,WIDE,RH BUINESS LINE 21610054 WELDMENT,FENDER,WIDE,LH CHIPPERS OWNER DOMAIN 21840064 SPRING,FEED CONTROL LINKAGE J.P. CARLTON COMPANY DIV. DAF INC. SERIAL NUMBERS 1J9XF011X81167139 29A-08 NUT,STOVER LOCK, 1/2-13 UNC GR8 DESCRIPTION ISSUE 31A-08ZI FLAT WASHER 1/2 USS GR 8 Z&Y AXLE, TIRES AND RIMS Revised 3.15.05...
  • Page 125 1 FRAME AND TANKS 0300266A HYDRAULIC SITE GAUGE W/TEMP BUINESS LINE 12D-0612 SHCS 3/8 X 1-1/2 NC GR 8 CHIPPERS OWNER DOMAIN 21210154 BRACKET,VANDADLISM,HYRDRUALI J.P. CARLTON COMPANY DIV. DAF INC. C TANK SERIAL NUMBERS 1J9XF011X81167139 DESCRIPTION ISSUE 21510005 WELDMENT,HYDRAULIC TANK HYDRAULIC TANK Revised 3.15.05...
  • Page 126 PART ITEM DESCRIPTION 0200009 Fuel Gauge - 25 Gallon BUINESS LINE CHIPPERS 0200007 TANK,FUEL OWNER DOMAIN J.P. CARLTON COMPANY DIV. DAF INC. 0200008 Fuel Cap - Plastic Tank SERIAL NUMBERS 1J9XF011X81167139 DESCRIPTION ISSUE 17510003 WELDMENT,FUEL TANK STRAP FUEL TANK Revised 3.15.05...
  • Page 127 HEX C/S 3/8-16 x 1" UNC GR 8 21530002 WELDMENT,BASE BUINESS LINE CHIPPERS 21530012 WELDMENT,LOCK PIN,DOOR OWNER DOMAIN J.P. CARLTON COMPANY DIV. DAF INC. 30A-06 LOCKWASHER, 3/8" USS GR8 SERIAL NUMBERS 1J9XF011X81167139 DESCRIPTION ISSUE 31B-06 FLAT WASHER 3/8 USS GR 8 Z&Y INST, HYDRAULIC COOLER Revised 3.15.05...
  • Page 128 2 ENGINE /ELECTRICAL 21220041 BATTERY,12V/950 CCA BUINESS LINE CHIPPERS 21220045 WELDMENT,BATTERYBOX/FRONT OWNER DOMAIN MOUNT J.P. CARLTON COMPANY DIV. DAF INC. SERIAL NUMBERS 1J9XF011X81167139 29A-06 NUT,STOVER LOCK, 3/8-16 UNC DESCRIPTION ISSUE BATTERY INSTALLATION Revised 3.15.05 DUE TO CONTINUOUS DESIGN IMPROVEMENTS CONSULT FACTORY PRIOR TO ORDERING 1-800-243-9335.
  • Page 129 WELDMENT,JD 140HP ADJUST BUINESS LINE 21520005 PLATE,ENGINE MNT CHIPPERS OWNER DOMAIN 30A-10 LOCKWASHER 5/8" USS GR8 ZINC J.P. CARLTON COMPANY DIV. DAF INC. SERIAL NUMBERS 1J9XF011X81167139 31A-12ZI FLAT WASHER 3/4" USS GR 8 Z&YL DESCRIPTION ISSUE 31B-10ZI FLAT WASHER 5/8 USS NARROW GR 8 Z&Y ENGINE MOUNTING Revised 3.15.05...
  • Page 130 2 ENGINE/ELECTRICAL PART ITEM DESCRIPTION BUINESS LINE 0150414 RIVET-ALUMINUM W STEEL CHIPPERS MANDREL OWNER DOMAIN J.P. CARLTON COMPANY DIV. DAF INC. 0350054 MARKER LIGHT- 4" AMBER OVAL SERIAL NUMBERS 1J9XF011X81167139 DESCRIPTION ISSUE 0350057 REFLECTOR- AMBER 2 3/8" INSTALL MARKER LIGHTS AND REFLECTORS Revised 3.15.05...
  • Page 131 2. TORQUE 60FTLBS AND APPLY BLUE LOCTITE 262 3. TORQUE 250FTLBS 4. TORQUE 75 FT LBS FUCTION GROUP 3 BASE/DRUM/TRANSITION BUINESS LINE CHIPPERS OWNER DOMAIN J.P. CARLTON COMPANY DIV. DAF INC. SEE NOTE 4 SERIAL NUMBERS 1J9XF011X81167139 DESCRIPTION ISSUE BASE TRANSITION Revised 3.15.05...
  • Page 132 LOCTITE 262 2. TORQUE 235FTLBS. FUCTION GROUP 3 BASE/DRUM/TRANSITION BUINESS LINE CHIPPERS OWNER DOMAIN J.P. CARLTON COMPANY DIV. DAF INC. SERIAL NUMBERS 1J9XF011X81167139 DESCRIPTION ISSUE BASE TRANSITION Revised 3.15.05 DUE TO CONTINUOUS DESIGN IMPROVEMENTS CONSULT FACTORY PRIOR TO ORDERING 1-800-243-9335.
  • Page 133 21230116 WELDMENT,DISCHARGE ADJUST,HANDLE 21230127 SPROCKET, DISCHARGE ADJUST BUINESS LINE CHIPPERS 21230138 WELDMENT,DISCHARGE ADJUST COVER OWNER DOMAIN 21260043 WELDMENT,DISCHARGE ADJUST SPROCKET J.P. CARLTON COMPANY DIV. DAF INC. SERIAL NUMBERS 21530002 WELDMENT,BASE 1J9XF011X81167139 21530004 WELDMENT,DOOR MOUNT DESCRIPTION ISSUE BASE TRANSITION Revised 3.15.05...
  • Page 134 0900110C SPRING,LIFT BUINESS LINE 21540001 ASSEMBLY,FEED SYSTEM,BOTTOM CHIPPERS OWNER DOMAIN 21540002 ASSEMBLY,TOP FEED SYSTEM J.P. CARLTON COMPANY DIV. DAF INC. SERIAL NUMBERS 1J9XF011X81167139 29A-06 NUT,STOVER LOCK, 3/8-16 UNC DESCRIPTION ISSUE ASSY,FEED SYSTEM Revised 3.15.05 DUE TO CONTINUOUS DESIGN IMPROVEMENTS CONSULT FACTORY PRIOR TO ORDERING 1-800-243-9335.
  • Page 135 NOTES: CHIPPERS 1. APPLY BLUE LOCTITE 242 TYP FOR ITEM #8 (12A-0812ZI) . OWNER DOMAIN 2. ITEM(S) #7 (12A-0616) TO BE TORQUED @ 47 FT/LBS. J.P. CARLTON COMPANY DIV. DAF INC. SERIAL NUMBERS 1J9XF011X81167139 DESCRIPTION ISSUE ASSY BTM FEED ENCLOSURE Revised 3.15.05...
  • Page 136 31A-08ZI FLAT WASHER 1/2 USS GR 8 Z&Y FUCTION GROUP 4 FEED SYSTEM BUINESS LINE CHIPPERS OWNER DOMAIN J.P. CARLTON COMPANY DIV. DAF INC. SERIAL NUMBERS 1J9XF011X81167139 DESCRIPTION ISSUE ASSY BTM FEED ENCLOSURE Revised 3.15.05 DUE TO CONTINUOUS DESIGN IMPROVEMENTS CONSULT FACTORY PRIOR TO ORDERING 1-800-243-9335.
  • Page 137 21540005 WELDMENT,FEED WHEEL/TOP BUINESS LINE CHIPPERS 21540010 WELDMENT,FEED WHEEL MOTOR STOP,RH OWNER DOMAIN 21540011 WELDMENT,FEED WHEEL MOTOR STOP,LH J.P. CARLTON COMPANY DIV. DAF INC. SERIAL NUMBERS 1J9XF011X81167139 30A-06 LOCKWASHER, 3/8" USS GR8 DESCRIPTION ISSUE 30A-08 LOCKWASHER 1/2" ASSY TOP FEED ENCLOSURE Revised 3.15.05...
  • Page 138 ITEM DESCRIPTION 0300121A SOLENOID VALVE- REV. DMDA-XAN BUINESS LINE CHIPPERS 0300121D PISTON RELIEF VALVE- RPCC-LAN OWNER DOMAIN J.P. CARLTON COMPANY DIV. DAF INC. 0300153 18" CHIPPER MANIFOLD ASSEMBLY SERIAL NUMBERS 1J9XF011X81167139 DESCRIPTION ISSUE 0300158 VICKERS SOLENOID VALVE D05 ASSY,FEED CONTROL VALVE BLOCK Revised 3.15.05...
  • Page 139 Carlton PROFESSIONAL TREE EQUIPMENT FUCTION GROUP 5 INFEED SYSTEM BUINESS LINE CHIPPERS OWNER DOMAIN J.P. CARLTON COMPANY DIV. DAF INC. SERIAL NUMBERS 1J9XF011X81167139 DESCRIPTION ISSUE INFEED CHUTE ELECTRONIC FEED CONTROLS Revised 3.15.05 DUE TO CONTINUOUS DESIGN IMPROVEMENTS CONSULT FACTORY PRIOR TO ORDERING 1-800-243-9335.
  • Page 140 5 INFEED SYSTEM 21650012 FLATBAR,ELECTRONIC ENGAGE LINKAGE BUINESS LINE CHIPPERS 21840075 ASSY,ELECTRONIC CONTROL OWNER DOMAIN LINKAGE J.P. CARLTON COMPANY DIV. DAF INC. SERIAL NUMBERS 1J9XF011X81167139 21850029 PLATE,VALVE BOX,FRONT DESCRIPTION ISSUE INFEED CHUTE ELECTRONIC FEED CONTROLS Revised 3.15.05 DUE TO CONTINUOUS DESIGN IMPROVEMENTS CONSULT FACTORY PRIOR TO ORDERING 1-800-243-9335.
  • Page 141 BUSHING,SCHA BEARING A3248,ELECTRONIC LINKAGE BUINESS LINE CHIPPERS 21840093 PLATE,ELECTRONIC LINKAGE COVER,TOP OWNER DOMAIN 29A-08 NUT,STOVER LOCK, 1/2-13 UNC GR8 J.P. CARLTON COMPANY DIV. DAF INC. SERIAL NUMBERS 30A-06 LOCKWASHER, 3/8" USS GR8 1J9XF011X81167139 31A-06 FLAT WASHER, 3/8 USS GRD 5 DESCRIPTION...
  • Page 142 21560002 WELDMENT,DISCHARGE ELBOW 6 DISCHARGE SYSTEM 21660003 WELDMENT,DISCHARGE NECK 21660004 WELDMENT,DISCHARGE CHIP BUINESS LINE CHIPPERS REFLECTOR OWNER DOMAIN J.P. CARLTON COMPANY DIV. DAF INC. 21660006 WELDMENT,DISCHARGE ADJUST SERIAL NUMBERS HANDLE 1J9XF011X81167139 DESCRIPTION ISSUE 21860020 STOP,DISCHARGE JACK DISCHARGE SYSTEM Revised 3.15.05...
  • Page 143 1. Panel description and electrical pinout R e v e A u t o - Ref. Description Signal type Pinout INput/OUTput 4-way Delphi connector Back-lit display for visualizing: Heat engine RPM IN (PNP NO, can be set to NPN) max. input frequency: 10KHz Working hours “auto-feed”...
  • Page 144 Ground input – monitor power IN (GND) supply 9 4 .5 R P M R e v e rse A u to -F e e d P R O G 5 7 .5 8 9 .5 A Silk-screened front panel in polyester B Front frame in black ABS C Housing in black ABS D Black metal supporting bracket...
  • Page 145 2. Operating After turning on the monitor, a 2 seconds test is automatically carried out: all display segments are on; after such a test, working hours are displayed for about 3 seconds, then engine RPMs are displayed and the other display indicators show the working status: Reverse Auto-Feed...
  • Page 146 3. Emergency procedure “type 0” This procedure is applied on those machines only where the ACTIVATION of the solenoid valves allows to protect the engine against excessive stress. "BACK" = reverse time 12 V 12 V RPM MAX RPM MIN DISPLAY Auto-Feed Auto-Feed...
  • Page 147 4. Emergency procedure “type 1” This procedure is applied on those machines only where the DE-ACTIVATION of the solenoid valves allows to protect the engine against excessive stress. "BACK" = reverse time 12 V 12 V RPM MAX RPM MIN DISPLAY Auto-Feed Auto-Feed...
  • Page 148 In case RPMs exceed the RPM maximum value during the reverse interval (back), the activation sequence shall be as shown below: "BACK" = reverse time type 0 12 V 12 V RPM MAX RPM MIN DISPLAY Auto-Feed Auto-Feed Auto-Feed INDICATIONS Reverse Reverse Reverse...
  • Page 149 During operation, working hours can always be displayed by switching for a BRIEF INTERVAL key (+) or (-). The display shows now the ref. indicator “b” on page 7 and working hours are displayed for 3 seconds. During this interval the EVS solenoid valve is energized or de-energized by the monitor (according to what programmed in “type”...
  • Page 150 7. “User” setting To enter the “user” programming phase, with the monitor ON keep key PROG pressed for at least 2 seconds and until the first parameter "HI" (i.e. RPMs minimum permitted value) is displayed. After an interval of 1 second the current programmed value is displayed (es.
  • Page 151 Reverse Auto-Feed Reverse Auto-Feed 1 sec. press both "+" and "-" Reverse Auto-Feed 1 sec. The parameter is changed by using key “+” or “-“; switching key “PROG” allows to go to next parameter “BACK” (i.e. activation time of the reverse solenoid valve, in ms).
  • Page 152 How to activate and de-activate the “auto-feed” function The device has a further programming phase, meant for activating and de-activating the “auto-feed” function. This function includes the emergency procedures previously described. NOTE: when the “auto-feed” function is de-activated, the monitor features exclusively revolution counter function and hours counter function;...
  • Page 153 -20 / +70 °C Storage temperature range -25 / +85 °C Mechanical vibrations resistance 2 g random Reference standards for the project MC14982 Autofeed Settings for Carlton Chippers Engine Make Engine Model HP Rating High Setting Low Setting Vanguard Big Block V Twin...
  • Page 176 Axles equipped with Dexter's E-Z Lube feature can be periodically lubricated without removing the hubs from the axle. This feature consists of axle spindles that have been specially drilled and assembled with grease fittings in their ends. When grease is pumped into the fitting, it is channeled to the inner bearing and then flows back to the outer bearing and eventually back out the grease cap hole.
  • Page 177 CAUTION Do not mix Lithium, calcium, sodium or barium complex greases due to possible compatibility problems. When changing from one type of grease to another, it is necessary to insure all the old grease has been removed. If your axles are equipped with oil-lubricated hubs, then your lubrication procedure is to periodically fill the hub with high quality hypoid gear oil to the level indicated on the clear plastic oil cap.
  • Page 179 Product Features • No need to pull the hubs to repack the bearings OR replace the seals when checking the brakes. • Pre-set adjustment means installation is easy and human error is virtually eliminated in bearing adjustment. • Pre-lubricated at the bearing factory providing resistance to contamination. •...
  • Page 180 WINCH INFORMATION...
  • Page 181 WINCH INFORMATION...
  • Page 182 WINCH INFORMATION...
  • Page 183 Tow- 7500 Deutz Turbo Diesel 24" 46" 92" arc 31" 1.5" 60" 4,400 Behind Call and ask about Carlton’s line of Chippers or visit our website: www.stumpcutters.com CARLTON—QUALITY PRODUCTS AND EXCEPTIONAL SERVICE Carlton Owner’s Manual 15” Drum Chipper Revised: 05/2008...

Table of Contents
