- Page 1 Rack/Tower Extended Runtime Battery Packs User's Manual Para Systems, Inc. 1455 Lemay Dr. Carrollton, TX 75007 Phone: 1-972-446-7363 Fax: 1-972-446-9011 Internet: minutemanups.com UPS Sizing: sizemyups.com P/N 34000424...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction Controls and Indicators Installation Replacing the Battery Obtaining Service Specifications Limited Product Warranty © Copyright 2011... -
Page 3: Introduction
Please read this manual before installing your Endeavor and Enterprise Plus no user serviceable parts. Repairs and Battery replacement must be Series Battery Pack, models BP24RTEXL, BP48RTEXL, BP36RTEXL, performed by QUALIFIED SERVICE PERSONNEL ONLY. BP72RTEXL as it provides important information that should be followed during... - Page 4 If this equipment does cause interference to radio or television reception, which Model BP24RTEXL BP48RTEXL BP36RTEXL BP72RTEXL...
-
Page 5: Controls And Indicators
2. CONTROLS AND INDICATORS 3. INSTALLATION REAR PANEL INSTALLATION PLACEMENT These Battery Packs are only intended to be install in an indoor temperature controlled environment that is free of conductive contaminants. DO NOT oper- ate the Battery Pack in: extremely dusty and/or unclean areas, locations near heating devices, water or excessive humidity, or where the Battery Pack is exposed to direct sunlight. - Page 6 RACKMOUNT CONFIGURATION FIG. 3 The Battery Pack comes with mounting brackets and rails for the standard 19" (46.5cm) 4-post rack. The screws for mounting the Battery Pack to the rack are not included (screw size varies with rack size). 1. Mount the rails to the 4-post rack. (FIG. 1) 2.
- Page 7 SentryPlus software and/or the SNMP card breaker is in the On position, the battery voltage will be present at the open end of the Battery Pack's external battery cable and external battery con- BP24RTEXL nector. BP48RTEXL 3. Turn the UPS off and disconnect the UPS's input power cord from the AC BP36RTEXL wall outlet.
-
Page 8: Replacing The Battery
BP24RTEXL Model # BP36RTEXL 4. REPLACING THE BATTERY BP48RTEXL BP72RTEXL 18 - 12V9.0Ah Battery Qty/Rating 20 - 12V9.0Ah (QUALIFIED SERVICE PERSONNEL ONLY) CSB Part # HR 1234W F2 These Battery Packs have an easy to replace hot-swappable batteries. Please read all of the WARNINGS and CAUTIONS before attempting to service the... - Page 9 21. Remove the old batteries from the bottom half of the plastic battery tray. FIG. 3 22. Install the new batteries into the bottom half of the plastic battery tray in the same position as the original batteries. 23. Verify proper polarity. Re-install the battery jumper wires on the new batteries.
-
Page 10: Obtaining Service
5. Mark the RMA # on the outside of all packages. The factory cannot accept any package without the RMA # marked on the outside. 6. Return the Battery Pack by insured, prepaid carrier to: Para Systems Inc. MINUTEMAN UPS 1455 LeMay Drive... -
Page 11: Limited Product Warranty
For equipment sites within the United States and Canada, this warranty covers repair or replacement of defective equipment at the discretion of Para Systems. Repair will be from the nearest autho- rized service center. Replacement parts and warranty labor will be borne by Para Systems.
