User's Manual
Enterprise OID: 1.3.6.1.4.1.21728.2.4.1
Definition
systemModel
systemName
powerOutletNum
serialPortNum
systemUpTime
swVersion
Outlet Sequence
outletIndex
outletName
outletStatus
outletAction
Envro/Current Sequence
enviroIndex
currentAlarmThreshold
currentDrawStatus1
CurrentDrawStatus2
currentDrawMax1
CurrentDrawMax2
temperatureThreshold
temperatureReading
Synaccess Networks, Inc.
Figure 12 - Implemented MIB Description
OID Returned message
.1.1 System Model number. Read only.
.1.2 The system name or site name. Read only.
.1.3 Number of power outlets on the system. Read only.
.1.4 Number of console ports on the system. Read only.
.1.5 Seconds since the system in operation.
.1.6 Firmware version
.2.1.1.1 Index for the outlet table
.2.1.1.2 Outlet socket name. Read/Write.
.2.1.1.3 Outlet socket ON/OFF status. Read only.
.2.1.1.4 Change outlet state to ON, OFF or Reboot. Write only.
.3.1.1.1 Index for the table
.3.1.1.2 Aggregated AC current draw threshold for each power inlet (or power
cord).
.3.1.1.3 First AC current monitoring reading. For a system equipped with single
power cord, this the valid current reading. For dual power corded
system, this is the first part of the AC current reading.
.3.1.1.4 For dual power corded system, this is the AC current reading for the
second power inlet (or power cord).
.3.1.1.5 Maximum aggregated AC current draw value was captured for the first
power inlet (or power cord). For a system equipped with single power
cord, this is the valid current reading. For dual power corded system, this
is the first part of the AC current reading.
.3.1.1.6 Maximum aggregated AC current draw value was captured for the 2nd
power inlet (or power cord).
.3.1.1.7 Environment temperature threshold in F.
.3.1.1.8 Temperature reading in F. Value is zero when the temperature probe is
not installed.
