User's Manual
Power outlets for user applications.
7. Local Master Port (DCE, 9 pin DB, female, or RJ-45 socket):
This is also a service port for the user to configure and change system operation settings.
8. Ethernet Port (RJ45, 10 base-T):
10 based-T Ethernet port for connection to LAN.
9. Manual Switch:
Outlet power output switch. Momentarily pressing down the button to index to the desired
outlet. Pressing down for 3 seconds to toggle the outlet power state. This switch is
equipped on NP08 and NP-16 systems.
10. Audio Alarm Off Switch:
To temporarily turn off the audio alarm when aggregated AC current draw crosses over the
defined threshold. This control switch is equipped on NPB-20 system.
Synaccess Networks, Inc.
www.synaccess-net.com
(760) 930 – 0473
Page 10 of 46
