2. iNTrODUCTiON & SPECiFiCATiONS
Infrared heater suitable for well ventilated indoor applications. clean burning unit operates on paraffin, kerosene or diesel.
unit produces an impressive 70,000 Btu/hr. 12ltr tank allows approximately 6hrs running time, making this unit extremely economical. complies
with rigorous standards and is fitted with a safety cut-out.
Model
rating Btu/hr
fuel
running time Per filling
(Approx)
fuel tank capacity (litres)
Voltage/Hz
Amps
Phase
Power cable
size (cm)
net Weight (Kg)
Heated Area
min. clearance from
combustables

3. ASSEMBLY

unpack the heater and check contents. should there be any damaged or
missing parts contact your sealey dealer immediately.
3.1 Attach handle by lining up the holes in the handle with the holes in the
upper shell of the heater (fig.1).
3.2 Insert screws and tighten.
3.3 remove heater and packaging material from the carton.
Note! Retain the box and packaging material for future storage.
ir20.v2
70,000
Paraffin / Kerosene / Diesel
7hr
15
230/50
5
single
2.1m
58 x 39 x 55
15
396m 3
top 1.2m
sides 1.2m
front 2.4m
Original Language Version
Fig.1
Ir20.V2 Issue: 1 - 10/06/10
