1. Specification

Dimensions
Acoustic
Acoustic Properties
Operating frequency
Angular resolution
Beamwidth
Number of beams
Range
Scan rate
Range resolution
Electrical and Communications
Power consumption
Supply voltage
Communication protocols
Document: 0690-SOM-00001, Issue: 01
58 202
face
342
240kHz
1.5° acoustic, 0.5° effective
120°
256
120m, 2D forward looking
60m, 2D search
40m, 3D
100Hz at 5m, 7Hz at 100m
2.5cm
60W
20-28V DC
Ethernet (100BaseT)
7
Eclipse 3D Imaging Sonar
115
Not to scale, dimensions in mm.
