1.1
Features
The Toshiba 710CDT/720CDT uses extensive Large Scale Integration (LSI) and Complemen-
tary Metal-Oxide Semiconductor (CMOS) technology to provide minimum size and weight,
low power usage and a high degree of reliability. The computer is fully optimized for Win-
®
dows
95 and supports plug and play technology. The computer incorporates the following
features and benefits:
Microprocessor
This computer uses an Intel
Technology (VRT) operating at 2.9/3.3 volts.
Cache memory
The CPU contains a 16 KB cache and a 256 KB level-2 cache with pipe-line burst
SRAM.
Disk storage
This computer has a 1.2 billion byte (1.13 GB) removable HDD pack.
Selectable Bay
The Selectable Bay allows connection to either a Floppy Disk Drive (FDD) or a CD-
ROM drive.
The FDD supports 3.5-inch 2HD (1.44 MB) disks and 2DD (720 KB) disks. The FDD
drive can be connected to an external FDD port with an attachment when the CD-ROM
drive is installed in the Selectable Bay.
A full-size, six-speed CD-ROM drive contains an AT Attachment Packet Interface
(ATAPI) controller, and supports the following formats: Red-Book, Yellow-Book,
CD-ROM XA, Photo CD, CD-Bridge, CD-I, and CD Plus.
Memory
This computer comes standard with 16 MB of Extend Data Out (EDO) DRAM. This
includes 640 KB of conventional memory and 15488 KB of extended memory.
Display
The 710CDT has a 12.1-inch, Thin Film Transistor (TFT) color LCD displaying 800 x
600 pixels.
710CDT/720CDT
®
®
Pentium
133 MHz processor with Voltage Reduction
1-1
