TRENDnet TEW-635BRM Quick Installation Manual

TRENDnet TEW-635BRM Quick Installation Manual

Hide thumbs Also See for TEW-635BRM:

Advertisement

Quick Links

Download this manual See also: User Manual
Quick Installation Guide
TEW-635BRM
2.01

Advertisement

loading

Related Manuals for TRENDnet TEW-635BRM

Summary of Contents for TRENDnet TEW-635BRM

  • Page 1 Quick Installation Guide TEW-635BRM 2.01...

  • Page 2: Table Of Contents

    Table of Contents English 1. Before You Start 2. Hardware Installation 3. Configure The Modem 4. Setting up Encryption Tõrkeotsing Wireless Tips Version 01.04.2010...

  • Page 3: English

    1. Before You Start Package Contents TEW-635BRM CD-ROM (User’s Guide) Multi-Language Quick Installation Guide 2 x 2dBi Detachable Antenna 1 x RJ-45 Ethernet Cable 1 x RJ-11 Telephone Cable Power Adapter (12V DC, 1A) System Requirements A working ADSL Internet Connection A computer with a wired or wireless network adapter properly installed Web Browser: Internet Explorer (5.0 or above)
  • Page 4 Collect Internet Service Provider (ISP) Information During the installation of your Wireless ADSL Modem Router, the Setup Wizard will automatically detect your ISP connection type. If the router cannot detect your ISP connection type, you can manually specify the connection type. Please verify your DSL Internet broadband connection type with your ISP and ensure you have all the information for one of the following connection types: A.

  • Page 5: Hardware Installation

    2. Hardware Installation 1. Connect the detachable antennas to the TEW-635BRM. 2. Connect one end of the RJ-45 cable to one of the TEW-635BRM's LAN ports. Connect the other end of cable to the computer's Ethernet port. ADSL Terminator 3. Connect one end of the RJ-11 cable to the...

  • Page 6: Configure The Modem

    3. Configure the Modem Note: It is recommended that you configure the Modem from a wired computer. 1. Open your web browser, type http://192.168.10.1 in the Address bar, and then press Enter. 2. Enter the User Name and password and then click OK. By default: User name: admin Password: admin Note: User name and Password is case...
  • Page 7 4. Click Next. 5. Select Auto-detect and then click Next. Note: 1. The example below is for Auto-detect. If the Setup Wizard could not automatically detect your Internet connection, select Manual Selection and input the information using the information provided by your ISP. 2.
  • Page 8 Next. Note: For other connection methods, follow the on screen instructions after you select auto-detect. 9. Please wait while the TEW-635BRM reboots. 10. Check the LEDs and then click OK. 11. Check Test Internet Connection, and then click Finish.

  • Page 9: Setting Up Encryption

    4. Setting up Encryption Note: To protect your network from any unauthorized access it is recommended to enable wireless encryption. 1. Click Wireless 2. Select the Region, enter the desired SSID and then click Save. 3. Click Configure SSID1 to set up Wireless Security.

  • Page 10: Register Your Product

    Your Configuration is complete For detailed information regarding the TEW-635BRM’s configuration and advanced settings, please refer to the Troubleshooting section, User's Guide CD-ROM, or TRENDnet's website at http://www.trendnet.com. Register Your Product To ensure the highest level of customer service and support, please take a moment to www.trendnet.com/register...

  • Page 11: Tõrkeotsing

    Tõrkeotsing I typed http://192.168.10.1 in my Internet Browser's Address Bar, but an error message says “The page cannot be displayed.” How can I get into the TEW-635BRM's web configuration page? Kontrollige veelkord üle riistvara seaded, järgides osa 2 juhiseid. 2. Veenduge, et Power, LAN ja WLAN tuled põlevad.
  • Page 12 Wireless Modem for 15 seconds. 2. Power cycle the Modem. Unplug the power to the Modem. Wait 15 seconds, then plug the power back in. If you still encounter problems or have any questions regarding the TEW-635BRM, please contact TRENDnet's Technical Support Department.

  • Page 13: Wireless Tips

    Wireless Tips The following are some general wireless tips to help minimize the impact of interference within an environment. Assign your network a unique SSID Do not use anything that would be identifying like “Smith Family Network”. Choose something that you would easily identify when searching for available wireless networks. Do not turn off the SSID broadcast The SSID broadcast is intended to be on and turning it off can cause connectivity issues.
  • Page 14 2. Keep the number of obstructions to a minimum. Each obstruction can reduce the range of a wireless device. Position the wireless devices in a manner that will minimize the amount of obstructions between them. 3. Building materials can have a large impact on your wireless signal. In an indoor environment, try to position the wireless devices so that the signal passes through less dense material such as dry wall.
  • Page 16 Informations générales GPL/LGPL Ce produit TRENDnet comprend un logiciel libre écrit par des programmeurs tiers. Ces codes sont sujet à la GNU General Public License ("GPL" Licence publique générale GNU) ou à la GNU Lesser General Public License ("LGPL" Licence publique générale limitée GNU).
  • Page 17 General Public License) ou ao LGPL (GNU Lesser General Public License). Estes códigos são distribuídos SEM GARANTIA e estão sujeitos aos direitos autorais dos desenvolvedores. TRENDnet não presta suporte técnico a estes códigos. Os detalhes do GNU GPL e do LGPL estão no CD-ROM do produto.
  • Page 18 Copyright © 2010. All Rights Reserved. TRENDnet.
