- Page 1 A s s e m b l y G u i d e R2250HRT STEP-THRU SEMI-RECUMBENT FITNESS BIKE...
- Page 2 A s s e m b l y G u i d e R2250HRT STEP-THRU SEMI-RECUMBENT FITNESS BIKE To avoid possible damage to this Fitness Bike, please follow these assembly steps in the correct order. Before proceeding, find your new Fitness Bike’s serial number located on the front axle tube, and enter...
- Page 3 TOOLS & PARTS INCLUDED 15mm Pedal Wrench 5mm T-Shaped Wrench 6mm L-Shaped Wrench 4mm L-Shaped Wrench Screwdriver PARTS BOX 5mm L-Shaped Wrench Console Mast Cover, Qty: 1 Pedals, Qty: 2 Power Supply, Qty: 1 Water Bottle & Cage, Qty: 1 Heart Rate Chest Strap Color-coded Hardware Bags Owner’s Guide...
- Page 4 HARDWARE INCLUDED ORANGE BAG BLUE BAG M8 x 65L Screw M6 x 55L Screws Quantity: 2 Quantity: 8 SW8 Lockwashers M8 x 20L Screws SW6 Lockwashers Quantity: 4 Quantity: 2 M8 x 20L Quantity: 8 Socket-head Cap Screw Quantity: 4 PINK BAG SW8 Lockwashers M8 x 15L Screws...
- Page 5 ORANGE BAG STEP • Slide the rear foot into place on the frame. Secure the foot in place with two screws (M8x20L) and two lock washers (SW8) to the outside holes and with two screws (M8x65L) and two lock washers (SW8) to the inside holes.
- Page 6 BLUE BAG STEP • Place the seat bracket on the seat frame. Secure in place with four (M8x20L) socket-head cap screws. Tighten with the 6mm L-shaped wrench. • Remove the socket-head cap screw in front of the seat lever, located on the right side of the seat frame, with the 4mm L-shaped wrench.
- Page 7 PINK BAG STEP • Slide the console mast cover onto the console mast. • Use the wire tie coming from the bot- tom of the console mast to wrap around the wire harness and heart rate wires that are sitting in the frame bracket. •...
- Page 8 Tighten with the 15mm pedal wrench. STEP 500 South CP Avenue • P.O. Box 280 • Lake Mills. WI 53551 toll free 1.800.335.4348 • phone 1.920.648.4090 • fax 1.920.648.3373 www.visionfitness.com ©2005 Vision Fitness. All Rights Reserved. 5.05 Part #Z22RB102-AG AG18.35PRD REV1...
