Summary of Contents for Vivitek D7180
- Page 1 D7180 & H7080HD...
- Page 2 Copyright This publication, including all photographs, illustrations and software, is protected under international copy- right laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the author. © Copyright 2012 Disclaimer The information in this document is subject to change without notice.
-
Page 3: Important Safety Information
DLP Projector – User’s Manual Important Safety Information Important: It is strongly recommended that you read this section carefully before using the projector. These safety and usage instructions will ensure that you enjoy many years of safe use of the projector. Keep this manual for future reference. -
Page 4: Projector Installation Notice
Preface Projector Installation Notice Place the projector in a horizontal position The tilt angle of the projector should not exceed 15 degrees, nor should the projector be in- stalled in any way other than the desktop and ceiling mount, otherwise lamp life could decrease dramatically, and may lead to other unpredictable damages. - Page 5 DLP Projector – User’s Manual Cooling notes Air outlet Make sure the air outlet is 50cm clear of any obstruction to ensure proper cooling. Air outlet location should not be in front of the lens of other projector to avoid causing illusions. Keep the outlet at least 100cm away from the inlets of other projectors The projector generates a massive amount of heat during use.
- Page 6 Preface Power Safety Only use the supplied power cord. Do not place anything on the power cord. Place the power cord where it will not be in the way of foot traffic. Remove the batteries from the remote control when storing or not in use for a prolonged period. Replacing the Lamp Replacing the lamp can be hazardous if done incorrectly.
- Page 7 DLP Projector – User’s Manual Symbol Explanations DISPOSAL: Do not use household or municipal waste collection services for disposal of electrical and electronic equipment. EU countries require the use of separate recycling collection services. Main Features • A high brightness rating allows for presentations in daylight or in lit rooms. •...
-
Page 8: Table Of Contents
Preface Table of Contents GETTING STARTED ................................1 ................................1 ACKING HECKLIST ............................... 2 IEWS OF ROJECTOR ARTS Front-right View ................................2 Rear view ..................................3 Bottom view..................................4 ..............................5 EMOTE ONTROL ARTS ..........................7 EMOTE ONTROL PERATING ANGE ........................ - Page 9 DLP Projector – User’s Manual LED E ..............................46 RROR ESSAGES ................................46 MAGE ROBLEMS ................................47 ROBLEMS ............................47 EMOTE ONTROL ROBLEMS ................................48 UDIO ROBLEMS ..........................48 AVING THE ROJECTOR ERVICED HDMI Q & A ..................................49 SPECIFICATIONS................................50 .................................
-
Page 10: Getting Started
DLP Projector – User’s Manual ETTING TARTED Packing Checklist Carefully unpack the projector and check that the following items are included: DLP P ROJECTOR EMOTE CONTROL VGA CABLE OWER CORD (WITH TWO AAA BATTERIES) CD-ROM UICK TART UIDE ARRANTY ’ S MANUAL Contact your dealer immediately if any items are missing, appear damaged, or if the unit does not work. -
Page 11: Views Of Projector Parts
DLP Projector – User’s Manual Views of Projector Parts Front-right View ABEL ESCRIPTION EE PAGE Lamp cover Removes cover to replace lamp Secure to permanent object with a Kensington® Kensington lock Lock system Security bar For security and authorized usage Lens Projection Lens Aspheric mirror... -
Page 12: Rear View
DLP Projector – User’s Manual Rear view 3 4 5 ABEL ESCRIPTION EE PAGE Connect the RGB cable to a display VGA OUT (Loop Thru only for VGA IN) VGA IN Connect the RGB cable from a computer and components. Connect the DVI cable from a device. -
Page 13: Bottom View
DLP Projector – User’s Manual Bottom view ABEL ESCRIPTION EE PAGE Security bar Helps protect the projector from unauthorized use Tilt adjustors Rotate adjusters lever to adjust angle position Ceiling support holes Contact your dealer for information on mounting the projector on a ceiling Note: When installing, ensure that you use only UL Listed ceiling mounts. -
Page 14: Remote Control Parts
DLP Projector – User’s Manual Remote Control Parts Important: 1. Avoid using the projector with bright fluorescent lighting turned on. Certain high-frequency fluo- rescent lights can disrupt remote control operation. 2. Be sure nothing obstructs the path between the remote control and the projector. If the path be- tween the remote control and the projector is obstructed, you can bounce the signal off certain reflective surfaces such as projector screens. - Page 15 DLP Projector – User’s Manual ABEL ESCRIPTION EE PAGE IR transmitter Transmits signals to projector Status LED Lights when the remote control is used Laser Press to operate the on-screen pointer Up arrow when connected through USB to a PC Right Right arrow when connected through USB to a PC Down...
-
Page 16: Remote Control Operating Range
DLP Projector – User’s Manual Remote Control Operating Range The remote control uses infrared transmission to control the projector. It is not necessary to point the remote directly at the projector. Provided you are not holding the remote perpendicular to the sides or the rear of the projector, the remote will function well within a radius of about 7 meters (23 feet) and 15 degrees above or below the projector level. -
Page 17: Setup And Operation
DLP Projector – User’s Manual ETUP AND PERATION Inserting the Remote Control Batteries Remove the battery compartment cover by sliding the cover in the direction of the arrow. Insert the battery with the positive side facing up. Replace the cover. Caution: 1. -
Page 18: Starting And Shutting Down The Projector
DLP Projector – User’s Manual Starting and Shutting down the Projector Connect the power cord to the projector. Connect the other end to a wall outlet. The POWER LED will be on. Turn on the connected devices. Ensure the POWER LED displays a solid amber and not a flashing amber. -
Page 19: Adjusting The Projector Level
DLP Projector – User’s Manual Adjusting the Projector Level Take note of the following when setting up the projector: • The projector table or stand should be level and sturdy. • Position the projector so that it is perpendicular to the screen. •... -
Page 20: Adjusting The Keystone
DLP Projector – User’s Manual Adjusting the Keystone Use the KEYSTONE buttons on the remote control to correct image- trapezoid (wider top or bottom) effect. The keystone control appears on the display. Adjusting the Volume Press the Volume +/- buttons on the remote control. -
Page 21: On-Screen Display (Osd) Menu Settings
DLP Projector – User’s Manual (OSD) M CREEN ISPLAY ETTINGS OSD Menu Controls The projector has an OSD that lets you make image adjustments and change various settings. Navigating the OSD You can use the remote control cursor buttons or the buttons on the top of the projector to navigate and make changes to the OSD. -
Page 22: Setting The Osd Language
DLP Projector – User’s Manual Setting the OSD Language Set the OSD language to your preference before continuing. 1. Press the MENU button. Press the cursor ◄► button to navigate to SETUP>>Basic. 2. Press the cursor ▲▼ button until Language is highlighted. 3. -
Page 23: Osd Menu Overview
American)/ Russian/ Simplified Chinese/ Traditional Chinese/ Spanish/ Swedish/ Czech/ Greek/ Turkish/ SETUP >> Basic Language Hungarian/ Vietnamese/ Arabic/ Thai Splash Logo Vivitek/Blue/Black Projection Front Table/Front Ceiling/Rear Table/Rear Ceiling Blank Timer Disable / 5 Min / 10 Min / 15 Min / 20 Min / 25 Min / 30 Min... -
Page 24: Picture>>Basic Menu
DLP Projector – User’s Manual PICTURE>>Basic Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the PICTURE>>Basic menu. Press the cursor ▲▼ button to move up and down in the PICTURE>>Basic menu. Press ◄► to change values for settings. Note: Customizing the settings in PICTURE>>Basic menu is only available in User 1/ 2/ 3 mode. -
Page 25: Picture>>Advanced Menu
DLP Projector – User’s Manual PICTURE>>Advanced Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the PICTURE>>Advanced menu. Press the cursor ▲▼ button to move up and down in the PICTURE>>Advanced menu. Press ◄► to change values for settings. ESCRIPTION Noise Reduction Press the cursor ◄►... -
Page 26: Hsg Adjustment
DLP Projector – User’s Manual HSG Adjustment Press the ENTER button to enter the HSG Adjustment sub menu. ESCRIPTION Press the ◄► buttons to set the Primary Color. Primary Color Notes: There are six sets (R/ G/ B/ C/ M/ Y) of colors to be customized. Press the ◄►... -
Page 27: User Color Temp
DLP Projector – User’s Manual User Color Temp Press the ENTER button to enter the User Color Temp sub menu. ESCRIPTION White Gain Red Press the ◄► buttons to adjust the White Gain Red. White Gain Green Press the ◄► buttons to adjust the White Gain Green. White Gain Blue Press the ◄►... -
Page 28: Display Menu
DLP Projector – User’s Manual DISPLAY Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the DISPLAY menu. Press the cursor ▲▼ button to move up and down in the DISPLAY menu. Press ◄►... -
Page 29: Pc Detail Adjustment
DLP Projector – User’s Manual PC Detail Adjustment Press the ENTER button to enter the PC Detail Adjustment sub menu. Note: Customizing the settings in PC Detail Adjustment menu is only available when PC input source (analog RGB) is selected. ESCRIPTION Press the ENTER/AUTO button on the control panel or the ENTER/AUTO button on the Auto... -
Page 30: Setup>>Basic Menu
Swedish/ Czech/ Greek/ Turkish/ Hungarian/ Vietnamese/ Arabic/ Thai) Press the cursor ◄► buttons to select a different startup screen. Splash Logo (Range: Vivitek/ Blue/ Black) Press the cursor ◄► buttons to choose from four projection methods: Projection Front Table/ Front Ceiling/ Rear Table/ Rear Ceiling. -
Page 31: Menu Settings
DLP Projector – User’s Manual Menu Settings Press the ENTER button to enter the Menu Settings sub menu. ESCRIPTION Press the ◄► buttons to select from five OSD locations: Menu Position Top-Left/ Top-Right/ Center/ Bottom-Left/ Bottom-Right. Press the ◄► buttons to set the Menu Display timer before the OSD times out. Menu Display Time (Range: 5sec/ 10sec/ 15sec/ 20sec/ 25sec/ 30sec) Source... -
Page 32: Command Control Settings
DLP Projector – User’s Manual Command Control Settings Press the ENTER button to enter the Command Control Settings sub menu. ESCRIPTION Control By Press the ◄► buttons to select projector remote command control. (Range: RS232/ RJ45) Press the ENTER button to enter the Network State sub menu. Network State See Network State on page 23. - Page 33 DLP Projector – User’s Manual For simplicity and ease of operation, the projector provides diverse networking and remote manage- ment features. The LAN/RJ45 function of the projector through a network, such as remotely manage: Power On/Off, Brightness and Contrast settings. Also, projector status information, such as: Video-Source, Sound- Mute, etc.
- Page 34 DLP Projector – User’s Manual 3. Right-click on Local Area Connection, and select Properties. 4. In the Properties window, select the General tab, and select Internet Protocol (TCP/IP). 5. Click Properties. – 25 –...
- Page 35 DLP Projector – User’s Manual 6. Click Use the following IP address and fill in the IP address and Subnet mask, then click OK. 7. Press the Menu button on the projector. 8. Select OSD SETUP>>Basic Menu →Command Control Settings→Network State. 9.
- Page 36 DLP Projector – User’s Manual 13. Press (Enter) / ►. The projector is setup for remote management. The LAN/RJ45 function displays as follows. Based on network web-page for the input-string in tools tab, the limitation for Input-Length is in the below list (“space” and the other punctuation key included): ATEGORY NPUT ENGTH...
- Page 37 DLP Projector – User’s Manual For more information, please visit http://www.crestron.com/. — 28 —...
- Page 38 DLP Projector – User’s Manual RS232 by Telnet Function Besides projector connected to RS232 interface with “Hyper-Terminal” communication by dedicated RS232 command control, there is alternative RS232 command control way, so called “RS232 by TELNET” for LAN/RJ45 interface. Quick Start-Guide for “RS232 by TELNET” Check and get the IP-Address on OSD of the projector.
- Page 39 DLP Projector – User’s Manual Input the command format like the below: telnet ttt.xxx.yyy.zzz 23 (“Enter” key pressed) (ttt.xxx.yyy.zzz: IP-Address of the projector) If Telnet-Connection ready, and user can have RS232 command input, then “Enter” key pressed, the RS232 command will be workable. How to have TELNET enabled in Windows VISTA / 7 By default installation for Windows VISTA, “TELNET”...
- Page 40 DLP Projector – User’s Manual Select “Turn Windows features on or off” to open Have “Telnet Client” option checked, then press “OK” button. – 31 –...
- Page 41 DLP Projector – User’s Manual Specsheet for “RS232 by TELNET” 1. Telnet: TCP 2. Telnet port: 8000 3. Telnet utility: Windows “TELNET.exe” (console mode) 4. Disconnection for RS232-by-Telnet control normally: Close Windows Telnet utility directly after TELNET connection ready 5. Limitation 1 for Telnet-Control: there is only one connection for Telnet-Control in one projector Limitation 2 for Telnet-Control: there is less than 50 bytes for successive network payload for Telnet-Control application.
-
Page 42: Setup>>Advanced Menu
DLP Projector – User’s Manual SETUP>>Advanced Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the SETUP>>Advanced menu. Press the cursor ▲▼ button to move up and down in the SETUP>>Advanced menu. ESCRIPTION Press the ENTER button to enter the Audio sub menu. -
Page 43: Audio
DLP Projector – User’s Manual Audio Press the ENTER button to enter the Audio sub menu. ESCRIPTION Volume Press the ◄► buttons to adjust the audio Volume. Treble Press the ◄► buttons to adjust the audio Treble. Bass Press the ◄► buttons to adjust the audio Bass. Mute Press the ◄►... -
Page 44: Hdmi
DLP Projector – User’s Manual HDMI Press the ENTER button to enter the HDMI sub menu. ESCRIPTION Press the ◄► buttons to select from three HDMI display formats: HDMI Format Auto/ PC signal/ Video signal. HDMI Amplifier Gain Press the ◄► buttons to adjust HDMI Amplifier Gain. Closed Caption Press the ENTER button to enter the Closed Caption sub menu. -
Page 45: Presentation Timer
DLP Projector – User’s Manual Presentation Timer The Presentation Timer function can indicate the presentation time on the screen to help you achieve better time management when giving presentations. ESCRIPTION Timer Press the cursor ◄► button to enable or disable presentation timer. Timer Period Press the cursor ◄►... -
Page 46: Status Menu
DLP Projector – User’s Manual STATUS Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the STATUS Menu. ESCRIPTION Source Displays the activated input source. Resolution Displays the native resolution of input source. Lamp Hour Displays the number of hours the lamp has been in use. -
Page 47: Maintenance And Security
DLP Projector – User’s Manual AINTENANCE AND ECURITY Replacing the Projection Lamp The projection lamp should be replaced when it burns out. It should only be replaced with a certified replacement part, which you can order from your local dealer. Important: a. - Page 48 DLP Projector – User’s Manual Remove the lamp compart- ment cover. Remove the two screws from the lamp module. Lift the module handle up. Pull firmly on the module handle to remove the lamp module. Reverse steps 1 to 5 to install the new lamp module.
-
Page 49: Cleaning The Projector
DLP Projector – User’s Manual Cleaning the Projector Cleaning the projector to remove dust and grime will help ensure trouble-free operation. Warning: 1. Be sure to turn off and unplug the projector at least 30 minutes before cleaning. Failure to do so could result in a severe burn. -
Page 50: Cleaning The Lens
DLP Projector – User’s Manual Cleaning the Lens You can purchase optic lens cleaner from most camera stores. Refer to the following to clean the pro- jector lens. 1. Apply a little optic lens cleaner to a clean soft cloth. (Do not apply the cleaner directly to the lens.) 2. -
Page 51: Using The Physical Lock
DLP Projector – User’s Manual Using the Physical Lock ® Using the Kensington Lock If you are concerned about security, attach the projector to a permanent object with the Kensington slot and a security cable. Note: Contact your vendor for details on purchasing a suitable Kensington security cable. The security lock corresponds to Kensington’s MicroSaver Security System. -
Page 52: Adjusting The Focus
DLP Projector – User’s Manual Adjusting the Focus Open the Focus Cover in the direction as shown. Focusing Procedure ( I ) When alignment lines are clearly marked on the focus rings the following presets are available: For 88.5” ActivBoard, adjust the focus rings until the white lines align –... -
Page 53: Focusing Procedure ( Ii )
DLP Projector – User’s Manual Focusing Procedure ( II ) 1. With the projector mounted and op- erator facing ActivBoard, turn the Front Focus Ring all the way to the left. 2. Adjust the Rear Focus Ring to ob- tain the best overall focus of the image. -
Page 54: Troubleshooting
DLP Projector – User’s Manual ROUBLESHOOTING Common problems and solutions These guidelines provide tips to deal with problems you may encounter while using the projector. If the problem remains unsolved, contact your dealer for assistance. Often after time spent troubleshooting, the problem is traced to something as simple as a loose con- nection. -
Page 55: Led Error Messages
DLP Projector – User’s Manual LED Error Messages ARNING OWER RROR ESSAGES MBER Lamp Ready － － － Start flashing － － － Cooling flashing － － － Over Temperature － － － Thermal Break Sensor error 7 blinks － －... -
Page 56: Lamp Problems
DLP Projector – User’s Manual Problem: The image is streaked 1. Set the Frequency and Phase settings on the Display menu of the OSD to the default settings. 2. To ensure the problem is not caused by a connected PC’s video card, connect to another computer. -
Page 57: Audio Problems
DLP Projector – User’s Manual Audio Problems Problem: There is no sound 1. Adjust the volume on the remote control. 2. Adjust the volume of the audio source. 3. Check the audio cable connection. 4. Test the source audio output with other speakers. 5. -
Page 58: Hdmi Q & A
DLP Projector – User’s Manual HDMI Q & A Q. What is the difference between a “Standard” HDMI cable and a “High-Speed” HDMI cable? Recently, HDMI Licensing, LLC announced that cables would be tested as Standard or High- Speed cables. ․Standard (or “category 1”) HDMI cables have been tested to perform at speeds of 75Mhz or up to 2.25Gbps, which is the equivalent of a 720p/1080i signal. -
Page 59: Specifications
DLP Projector – User’s Manual PECIFICATIONS Specifications For questions regarding product specifications, please contact your local distributor. Note: Model D7180 H7080HD Display type TI DMD 0.65" 1080P Resolution 1080P 1920 x 1080 Native Projection distance 22.4 mm ~ 62.3 mm(+/-10mm) Projection screen size 88.5 to 99 inches... -
Page 60: Projection Distance Vs. Projection Size
DLP Projector – User’s Manual Projection Distance vs. Projection Size Image Width Image Height Projection Distance and Size Table 1080 16:9 Distance (D) 62.3+/-10mm 22.4+/-10mm Diagonal 99" 88.5" Image Width (W) 2193mm 1961mm Image height (L) 1233mm 1103mm 404.3+/-50mm 373.8+/-50mm –... -
Page 61: Timing Mode Table
DLP Projector – User’s Manual Timing Mode Table The projector can display several resolutions. The following table outlines the resolutions that can be displayed by the projector. IGNAL ESOLUTION GBHV IGITAL 720 x 400 37.9 85.0 — 640 x 480 31.5 60.0 —... - Page 62 DLP Projector – User’s Manual IGNAL ESOLUTION GBHV IGITAL — 720p 37.5 50.0 — 720p 45.0 60.0 — 1080i 33.8 60.0 HDTV — 1080i 28.1 50.0 — 1080p 67.5 60.0 — 1080p 56.3 50.0 O: Frequency supported —: Frequency not supported The native resolution of the panel is1920 x 1080 Resolution other than native resolution may display with uneven size of text or lines.
-
Page 63: Projector Dimensions (Mm)
DLP Projector – User’s Manual Projector Dimensions (mm) 354.00 — 54 —... -
Page 64: Regulatory Compliance
DLP Projector – User’s Manual EGULATORY OMPLIANCE FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device pur- suant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 65: Rs-232C Protocol
DLP Projector – User’s Manual PPENDIX RS-232C Protocol RS232 Setting Baud rate: 9600 Parity check: None Data bit: Stop bit: Flow Control None Control Command Structure Header code Command code Data code End code Command Data ASCII ‘V’ Command Data Operation Command Note: XX=00-98, projector's ID, XX=99 is for all projectors... - Page 66 DLP Projector – User’s Manual Command Group 01 ASCII Function Description Return Value VXXS0103n 56h Xh Xh 53h 30h 31h 30h 33h nh 0Dh Set Color n=0~100 VXXG0104 56h Xh Xh 47h 30h 31h 30h 34h 0Dh Get Tint n=0~100 Pn/F VXXS0104n 56h Xh Xh 53h 30h 31h 30h 34h nh 0Dh Set Tint n=0~100...
- Page 67 DLP Projector – User’s Manual Command Group 03 ASCII Function Description Return Value 0: Fill 1: 4:3 2: 16:9 VXXG0301 56h Xh Xh 47h 30h 33h 30h 31h 0Dh Get Scaling 3 :Letter Box Pn/F 4 :Native 5:Auto 6:16:10 0: Fill 1: 4:3 2: 16:9 VXXS0301n 56h Xh Xh 53h 30h 33h 30h 31h nh 0Dh...
- Page 68 DLP Projector – User’s Manual Command Group 04 (Remote Control) ASCII Function Description Return Value VXXS0401 56h Xh Xh 53h 30h 34h 30h 31h 0Dh UP arrow VXXS0402 56h Xh Xh 53h 30h 34h 30h 32h 0Dh DOWN arrow VXXS0403 56h Xh Xh 53h 30h 34h 30h 33h 0Dh LEFT arrow VXXS0404...
