Summary of Contents for Vivitek DW771USTIE

  • Page 1 D77 Series...
  • Page 2 Copyright This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the author. © Copyright 2018 Disclaimer The information in this document is subject to change without notice.
  • Page 3 Important Safety Information Important: It is strongly recommended that you read this section carefully before using the projector. These safety and usage instructions will ensure that you enjoy many years of safe use of the projector. Keep this manual for future reference. Symbols Used Warning symbols are used on the unit and in this manual to alert you of hazardous situations.
  • Page 4 Projector Installation Notice  Place the projector in a horizontal position The tilt angle of the projector should not exceed 15 degrees, nor should the projector be installed in any way other than the desktop and ceiling mount, otherwise lamp life could decrease dramatically, and may lead to other unpredictable damages.
  • Page 5 Cooling notes Air outlet  Make sure the air outlet is 50cm clear of any obstruction to ensure proper cooling.  Air outlet location should not be in front of the lens of other projector to avoid causing illusions.  Keep the outlet at least 100cm away from the inlets of other projectors ...
  • Page 6 Power Safety  Only use the supplied power cord.  Do not place anything on the power cord. Place the power cord where it will not be in the way of foot traffic.  Remove the batteries from the remote control when storing or not in use for a prolonged period. Replacing the Lamp Replacing the lamp can be hazardous if done incorrectly.

  • Page 7: Table Of Contents

    Table of Contents GETTING STARTED ..............................1 Packing Checklist ..............................1 Views of Projector Parts ............................2 Front-right View ...............................2 Limited lens shift ..............................3 Top view—On-screen Display (OSD) buttons and LEDs ................4 Rear view .................................5 Bottom view ..............................7 Remote Control Parts ............................8 Remote Control Operating Range ........................10 Projector and Remote Control Buttons ......................
  • Page 8 Projection Distance and Size Table ......................62 Timing Mode Table ............................63 Projector Dimensions (DW771USTi/DH773USTi) ................... 65 Projector Dimensions (DW770UST/DH772UST) ..................... 66 Projector Dimensions (DW771USTie/DH773USTie) ..................67 REGULATORY COMPLIANCE .......................... 68 FCC Warning ..............................68 Canada ................................68 Safety Certifications ............................68 APPENDIX I.................................

  • Page 9: Getting Started

    ETTING TARTED Packing Checklist Carefully unpack the projector and check that the following items are included: DLP P NTERACTIVE ROJECTOR NTERACTIVE ROJECTOR ROJECTOR (DW771UST /DH773UST (DW771UST /DH773UST (DW770UST/DH772UST) EMOTE CONTROL VGA C OWER CORD ABLE AAA B ATTERIES UICK TART ARRANTY THE FOLLOWING ITEMS ONLY FOR DW771UST /DH773UST...

  • Page 10: Views Of Projector Parts

    Function keys buttons and LEDs. Interactive function use Interactive Camera Note: Only available in DW771USTi/DH773USTi/DW771USTie/DH773USTie Aspheric mirror Reflects images Important: Ventilation openings on the projector allow for good air circulation, which keeps the projector lamp cool. Do not obstruct any of the ventilation openings.

  • Page 11: Limited Lens Shift

    Limited lens shift (Only available in DW770UST and DW771USTi/DW771USTie) To shift up the projection image, twist the To shift down the projection image , twist the adjusters counter clockwise adjusters clockwise — 3—...

  • Page 12: Top View-On-Screen Display (Osd) Buttons And Leds

    Top view—On-screen Display (OSD) buttons and LEDs ABEL ESCRIPTION PAGE MENU Opens and exits OSD menus Navigates in the OSD Quick Menu – For Keystone SOURCE Enter the Source menu Navigates and changes settings in the OSD Enter or confirm highlighted OSD menu item AUTO Optimizes image size, position, and resolution Navigates and changes settings in the OSD...

  • Page 13: Rear View

    USB (1.5A) Connect the USB cable for power supply. RJ – 45 Connect a LAN cable from Ethernet Connect the USB cable to PC (for Interactive function) INTERACTIVE Note: Only available in DW771USTi / DH773USTi / DW771USTie / DH773USTie — 5—...
  • Page 14 Note: If your video equipment has various input sources, it is recommended to connect in priority of HDMI/DVI, component (thru VGA), Composite for better picture quality. Note: User should install driver before used Interactive function. For more detail see driver disc. Warning: As a safety precaution, disconnect all power to the projector and connecting devices before making connections.

  • Page 15: Bottom View

    Bottom view 43.3 149.3 206.3 255.3 ABEL ESCRIPTION EE PAGE Tilt adjustor Rotate adjuster lever to adjust angle position Contact your dealer for information on mounting the projector on a Ceiling support holes ceiling Note: When installing, ensure that you use only UL Listed ceiling mounts. For ceiling installations, use approved mounting hardware and M4 screws with a maximum screw depth of 12 mm (0.47 inch).

  • Page 16: Remote Control Parts

    Remote Control Parts Important: 1. Avoid using the projector with bright fluorescent lighting turned on. Certain high-frequency fluorescent lights can disrupt remote control operation. 2. Be sure nothing obstructs the path between the remote control and the projector. If the path between the remote control and the projector is obstructed, you can bounce the signal off certain reflective surfaces such as projector screens.
  • Page 17 ABEL ESCRIPTION EE PAGE IR transmitter Transmits signals to projector Status LED Lights when the remote control is used Laser Press to operate the on-screen pointer Up arrow when connected through USB to a PC Right Right arrow when connected through USB to a PC Down Down arrow when connected through USB to a PC Page Down...

  • Page 18: Remote Control Operating Range

    Remote Control Operating Range The remote control uses infrared transmission to control the projector. It is not necessary to point the remote directly at the projector. Provided you are not holding the remote perpendicular to the sides or the rear of the projector, the remote will function well within a radius of about 7 meters (23 feet) and 15 degrees above or below the projector level.

  • Page 19: Setup And Operation

    ETUP AND PERATION Inserting the Remote Control Batteries Remove the battery compartment cover by sliding the cover in the direction of the arrow. Insert the battery with the positive side facing up. Replace the cover. Caution: 1. Only use AAA batteries (Alkaline batteries are recommended). 2.

  • Page 20: Starting And Shutting Down The Projector

    Starting and Shutting down the Projector Connect the power cord to the projector. Connect the other end to a wall outlet. Turn on the connected devices. Ensure the POWER LED displays a solid green. Then press the POWER button to turn on the of the remote projector.

  • Page 21: Setting An Access Password (Security Lock)

    Setting an Access Password (Security Lock) You can use the four (arrow) buttons to set a password and prevent unauthorized use of the projector. When enabled, the password must be entered after you power on the projector. (See Navigating the OSD on page Setting the OSD Language on page...
  • Page 22 You can use the cursor buttons ▲▼◄► either on keypad or IR remote control for password entry. You can use any combination including the same arrow five times, but not less than five. Press the cursor buttons in any order to set the password.

  • Page 23: Adjusting The Projector Level

    Adjusting the Projector Level Take note of the following when setting up the projector:  The projector table or stand should be level and sturdy.  Position the projector so that it is perpendicular to the screen.  Ensure the cables are in a safe location. You could trip over them. To adjust the angle of the picture, turn the tilt-adjuster right or left until the desired angle has been achieved.

  • Page 24: Adjusting The Focus And Keystone

    Adjusting the Focus and Keystone Use the Image-focus control (on the projector only) to sharpen the projected image Use the KEYSTONE buttons on the remote control to correct image-trapezoid (wider top or bottom) effect. The keystone control appears on the display. Adjusting the Volume Press the Volume +/- buttons on the remote...

  • Page 25: On-Screen Display (Osd) Menu Settings

    (OSD) M CREEN ISPLAY ETTINGS OSD Menu Controls The projector has an OSD that lets you make image adjustments and change various settings. Navigating the OSD You can use the remote control cursor buttons to navigate and make changes to the OSD. 1.

  • Page 26: Setting The Osd Language

    Setting the OSD Language Set the OSD language to your preference before continuing. 1. Press the MENU button. Press the cursor ◄► button to navigate to Settings 1. Press the cursor ▲▼ button to move to the Advanced 1 menu. (Enter) / ►...

  • Page 27: Osd Menu Overview

    OSD Menu Overview Use the following illustration to quickly find a setting or determine the range for a setting. Main Menu Sub Menu Settings Image Display Mode Presentation, Bright, Game, Movie, TV, sRGB, Blackboard, User Brightness 0~100 Contrast 0~100 Computer Horizontal Position -5~5 (depend on Autolock) Vertical Position...
  • Page 28 Main Menu Sub Menu Settings Settings 1 Source Source reference Input Source Select (IR/Keypad) Projection Normal, Rear, Ceiling, Rear+Ceiling Aspect Ratio Fill, 4:3, 16:9, Letter Box, Native, 2.35:1 Keystone -40~40 Digital Zoom -10~10 Audio Volume 0~10 Mute Off, On Advanced 1 Language English, Français, Deutsch, Español, Português, 簡体中文, 繁體中文, Italiano,...
  • Page 29 Main Menu Sub Menu Settings Settings 2 Auto Source Off, On No Signal 0~180 Power Off Auto Power Off, On Lamp Mode ECO, Normal, Dynamic Eco Reset All Status Active Source Video Information Lamp Hours (ECO, Normal, Dynamic Eco) Serial Number Software Version Advanced 1 Menu Position...

  • Page 30: Image Menu

    Image Menu Attention ! All of display mode parameters when changed will be saved to user mode. Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Image Menu. Press the cursor ▲▼ button to move up and down in the Image menu. Press ◄► to enter and change values for settings.

  • Page 31: Computer Menu

    Computer Menu Press the MENU button to open the OSD menu. Press ◄► to move to the Image menu. Press ▲▼ to move to the Computer menu and then press Enter or ►. Press ▲▼ to move up and down in the Computer menu. ESCRIPTION Press the cursor ◄►...

  • Page 32: Advanced Feature

    Advanced Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Image menu. Press ▼▲ to move to the Advanced menu and then press Enter or ►. Press ▼▲ to move up and down in the Advanced menu. ESCRIPTION Press the cursor ◄►...

  • Page 33: White Balance

    White Balance Press the ENTER button to enter the White Balance sub menu. ESCRIPTION Press the ◄► buttons to adjust the Red Gain. R Gain Press the ◄► buttons to adjust the Green Gain. G Gain Press the ◄► buttons to adjust the Blue Gain. B Gain Press the ◄►...

  • Page 34: Color Manager

    Color Manager Press the Menu button to open the OSD menu. Press ◄► to move to the Image menu. Press ▼▲ to move to the Color Manager menu and then press Enter or ►. Press ▼▲ to move up and down in the Color Manager menu.

  • Page 35: Settings 1 Menu

    Settings 1 Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Settings 1 menu. Press the cursor ▲▼ button to move up and down in the Settings 1 menu. Press ◄► to enter and change values for settings. ESCRIPTION (Enter) / ►...

  • Page 36: Audio

    Audio Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 1 menu. Press ▼▲ to move to the Audio menu and then press Enter or ►. Press ▼▲ to move up and down in the Audio menu. ESCRIPTION Press the ◄►...

  • Page 37: Advanced 1 Feature

    Advanced 1 Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 1 menu. Press ▲▼ to move to the Advanced 1 menu and then press Enter or ►. Press ▲▼ to move up and down in the Advanced 1 menu.
  • Page 38 3D Setting ESCRIPTION Press the cursor ◄► button to enter and select different 3D mode. Press the cursor ◄► button to enter and enable or disable 3D Sync Invert. 3D Sync Invert Press the cursor ◄► button to enter and enable or disable different 3D Format. 3D Format Note: 1.

  • Page 39: Advanced 2 Feature

    Advanced 2 Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 1 menu. Press ▲▼ to move to the Advanced 2 menu and then press Enter or ►. Press ▲▼ to move up and down in the Advanced 2 menu.

  • Page 40: Settings 2 Menu

    Settings 2 Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Settings 2 menu. Press the cursor ▲▼ button to move up and down in the Settings 2 menu. ESCRIPTION Press the cursor ◄►...

  • Page 41: Status

    Status Press the cursor ▲▼ button to move up and down in the Settings 2 menu. Select the Status menu and press Enter or ► to enter. ESCRIPTION Active Source Display the activated source. Displays resolution/video information for RGB source and color standard for Video Video Information source.

  • Page 42: Advanced 1 Feature

    Advanced 1 Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 2 menu. Press ▲▼ to move to the Advanced 1 menu and then press Enter or ►. Press ▲▼ to move up and down in the Advanced 1 menu.
  • Page 43 Lamp Hour Reset Please refer to Resetting the Lamp on page to reset the lamp hour counter. Network ESCRIPTION Network State Displays the network connection status. Press ◄► to turn DHCP On or Off. DHCP Note: If you select DHCP Off, complete the IP Address, Subnet Mask, Gateway, and DNS fields.
  • Page 44 Wired LAN Terminal functionalites Remote control and monitoring of a projector from a PC (or Laptop) via wired LAN is also possible. Compatibility with Crestron / AMX (Device Discovery) / Extron control boxes enables not only collective projector management on a network but also management from a control panel on a PC (or Laptop) browser screen.
  • Page 45 LAN RJ45 1. Connect an RJ45 cable to RJ45 ports on the projector and the PC (Laptop). → → 2. On the PC (Laptop), select Start Control Panel Network and Internet. — 37—...
  • Page 46 3. Right-click on Local Area Connection, and select Properties. 4. In the Properties window, select the Networking tab, and select Internet Protocol (TCP/IP). 5. Click Properties. — 38—...
  • Page 47 6. Click Use the following IP address and fill in the IP address and Subnet mask, then click OK. 7. Press the Menu button on the projector. 8. Select Settings 2 → Advanced 1 → RS232 → Network Option 9. After getting into Network, input the following: ...
  • Page 48 12. In the Address bar, input the IP address: 10. 10. 10. 10. (Enter) / ►. 13. Press The projector is setup for remote management. The LAN/RJ45 function displays as follows. — 40—...
  • Page 49 ATEGORY NPUT ENGTH IP Address Crestron Control IP ID Port Projector Name Projector Location Assigned To DHCP (Enabled) (N/A) IP Address Network Configuration Subnet Mask Default Gateway DNS Server Enabled (N/A) User Password New Password Confirm Enabled (N/A) Admin Password New Password Confirm For more information, please visit http://www.crestron.com/.
  • Page 50 RS232 by Telnet Function Besides projector connected to RS232 interface with “Hyper-Terminal” communication by dedicated RS232 command control, there is alternative RS232 command control way, so called “RS232 by TELNET” for LAN/RJ45 interface. Quick Start-Guide for “RS232 by TELNET” Check and get the IP-Address on OSD of the projector. Make sure that laptop/PC can access the web-page of the projector.
  • Page 51 Input the command format like the below: telnet ttt.xxx.yyy.zzz 23 (“Enter” key pressed) (ttt.xxx.yyy.zzz: IP-Address of the projector) If Telnet-Connection ready, and user can have RS232 command input, then “Enter” key pressed, the RS232 command will be workable. How to have TELNET enabled in Windows 7 / 8 / 10 By default installation for Windows, “TELNET”...
  • Page 52 Select “Turn Windows features on or off” to open Have “Telnet Client” option checked, then press “OK” button. Specsheet for “RS232 by TELNET” Telnet: TCP Telnet port: 23 (for more detail, kindly please get contact with the service agent or team) Telnet utility: Windows “TELNET.exe”...

  • Page 53: Advanced 2 Feature

    Advanced 2 Feature Press the Menu button to open the OSD menu. Press ◄► to move to the Settings 2 menu. Press ▲▼ to move to the Advanced 2 menu and then press Enter or ►. Press ▲▼ to move up and down in the Advanced 2 menu.
  • Page 54 Source Filter Press the ENTER button to enter the Source Filter sub menu. ESCRIPTION Press the ◄► buttons to enter and enable or disable the HDMI source. HDMI1 Press the ◄► buttons to enter and enable or disable the HDMI source. HDMI2 Press the ◄►...

  • Page 55: Maintenance And Security

    AINTENANCE AND ECURITY Replacing the Projection Lamp The projection lamp should be replaced when it burns out. It should only be replaced with a certified replacement part, which you can order from your local dealer. Important: a. The projection lamp used in this product contains a small amount of mercury. b.
  • Page 56 Remove the lamp compartment cover. Remove the two screws from the lamp module. Lift the module handle up. Pull firmly on the module handle to remove the lamp module. Reverse steps 1 to 5 to install the new lamp module. While installing, align the lamp module with the connector and ensure it is...

  • Page 57: Resetting The Lamp

    Resetting the Lamp After replacing the lamp, you should reset the lamp hour counter to zero. Refer to the following: Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the Settings 2 menu. Press the cursor button to move down to Advanced 1 and press enter.

  • Page 58: Cleaning The Filter (Filter: Optional Parts)

    Cleaning the filter (filter: optional parts) The air filter prevents dust from accumulating on the surface of the optical elements inside the projector. If the filter is dirty or clogged, your projector may overheat or degrading the projected image quality. Turn off the projector, and unplug the AC power cord from the AC outlet.

  • Page 59: Replacing The Filter

    Replacing the Filter Turn off the projector, and unplug the AC power cord from the AC outlet. Clean up the dust on the projector and around the air vents. Pull out the filter cover and remove from the projector Use soft brush gently to clean the filter dust both side.

  • Page 60: Cleaning The Projector

    Cleaning the Projector Cleaning the projector to remove dust and grime will help ensure trouble-free operation. Cleaning the Projector Mirror: Remove dust with a “Bellows/Lens Blower” readily available from Camera shops to prevent scratching the mirror when subsequently wiped. Cautions: 1.

  • Page 61: Cleaning The Case

    Cleaning the Case Refer to the following to clean the projector case. 1. Wipe off dust with a clean dampened cloth. 2. Moisten the cloth with warm water and mild detergent (such as used to wash dishes), and then wipe the case. 3.

  • Page 62: Using The Physical Lock

    Using the Physical Lock Using the Kensington Security Slot If you are concerned about security, attach the projector to a permanent object with the Kensington slot and a security cable. Note: Contact your vendor for details on purchasing a suitable Kensington security cable. The security lock corresponds to Kensington’s MicroSaver Security System.

  • Page 63: Troubleshooting

    ROUBLESHOOTING Common problems and solutions These guidelines provide tips to deal with problems you may encounter while using the projector. If the problem remains unsolved, contact your dealer for assistance. Often after time spent troubleshooting, the problem is traced to something as simple as a loose connection.

  • Page 64: Led Error Messages

    LED Error Messages OWER RROR ESSAGES REEN Lamp Ready Green Start Flashing(Green) Cooling Flashing(Green) Thermal Break Sensor error 4 blinks Lamp fail 5 blinks Ballast temp over 5 blinks 1 blinks Ballast circuit short 5 blinks 2 blinks Lamp End of lamp life detected 5 blinks 3 blinks Lamp did not ignite...

  • Page 65: Lamp Problems

    3. Ensure the projector-to-screen distance is within the specified range. 4. Check that the projector lens is clean. Problem: The image is wider at the top or bottom (trapezoid effect) 1. Position the projector so it is as perpendicular to the screen as possible. 2.

  • Page 66: Having The Projector Serviced

    2. Adjust the volume of the audio source. 3. Check the audio cable connection. 4. Test the source audio output with other speakers. 5. Have the projector serviced. Problem: The sound is distorted 1. Check the audio cable connection. 2. Test the source audio output with other speakers. 3.

  • Page 67: Hdmi Q & A

    HDMI Q & A Q. What is the difference between a “Standard” HDMI cable and a “High-Speed” HDMI cable? Recently, HDMI Licensing, LLC announced that cables would be tested as Standard or High-Speed cables. 2. ˙Standard (or “category 1”) HDMI cables have been tested to perform at speeds of 75Mhz or up to 2.25Gbps, which is the equivalent of a 720p/1080i signal.

  • Page 68: Specifications

    PECIFICATIONS Specifications Model DW771USTi DW771USTie DW770UST Display type DMD 0.65" WXGA Resolution WXGA 1280 x 800 Native Projection distance 605mm - 755mm 16:10 (80”~100”) Projection screen size Projection lens Throw ratio 0.35 : 1 Vertical keystone correction +/- 40 degrees...
  • Page 69 Model DH773USTi DH773USTie DH772UST Display type DMD 0.65" 1080P Resolution 1080P 1920x1080 Native Projection distance 663mm - 833mm Projection screen size 16:9 (88"~110") Projection lens Throw ratio 0.33:1 Vertical keystone correction +/- 40 degrees Projection methods Front, Rear, Desktop/Ceiling (Rear, Front) Data compatibility VGA, SVGA, XGA, SXGA, UXGA, Mac SDTV/EDTV/ HDTV...

  • Page 70: Projection Distance Vs. Projection Size

    Projection Distance vs. Projection Size Projection Distance and Size Table DW771USTi / DW770UST / DW771USTie WXGA 16:10 Diagonal 80" 87" 97" 100" Distance 282.3+/-20mm 340.3+/-20mm 421.4+/-20mm 445.8+/-20mm Image Width 1723mm 1874mm 2088mm 2154mm Image height 1077mm 1171mm 1305mm 1346mm 280+/-50mm 300.2+/-50mm...

  • Page 71: Timing Mode Table

    Timing Mode Table The projector can display several resolutions. The following table outlines the resolutions that can be displayed by the projector. VGA/BNC HDMI IGNAL ESOLUTION OMPOSITE OMPONENT ( KH NALOG IGITAL － ○ － － － NTSC 15.734 － ○...
  • Page 72 VGA/BNC HDMI IGNAL ESOLUTION OMPOSITE OMPONENT ( KH NALOG IGITAL 65.3 60.0 － － ○(3D:TB,SBS) ○(3D:TB,SBS) 1680 x1050 67.5 60.0 － － ○ ○ 1920 x 1080 1920 x 1200 74.0 60.0 － － ○(3D:TB,SBS) ○(3D:TB,SBS) (Reduce Blanking) 54.0 24.0 －...

  • Page 73: Projector Dimensions (Dw771Usti/Dh773Usti)

    Projector Dimensions (DW771USTi/DH773USTi) 287.5mm — 65—...

  • Page 74: Projector Dimensions (Dw770Ust/Dh772Ust)

    Projector Dimensions (DW770UST/DH772UST) 287.5mm — 66—...

  • Page 75: Projector Dimensions (Dw771Ustie/Dh773Ustie)

    Projector Dimensions (DW771USTie/DH773USTie) 287.5mm — 67—...

  • Page 76: Regulatory Compliance

    EGULATORY OMPLIANCE FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.

  • Page 77: For Dw770Ust / Dw771Usti

    PPENDIX FOR DW770UST / DW771USTi RS-232C Protocol RS232 Setting Baud rate: 9600 Parity None check: Data bit: Stop bit: Flow None Control Control Command Structure Header code Command code Data code End code Command Data ‘V’ ASCII Command Data Operation Command Note: "CR"...
  • Page 78 Command Group 01 Return ASCII Function Description Value VXXS0103n 56h Xh Xh 53h 30h 31h 30h 33h nh 0Dh Set Color n=0~100 VXXG0104 56h Xh Xh 47h 30h 31h 30h 34h 0Dh Get Tint n=0~100 Pn/F VXXS0104n 56h Xh Xh 53h 30h 31h 30h 34h nh 0Dh Set Tint n=0~100 VXXG0105...
  • Page 79 Command Group 03 Return ASCII Function Description Value 0: Fill 1: 4:3 2: 16:9 VXXG0301 56H 39H 39H 47H 30H 33H 30H 31H 0DH Get Scaling Pn/F 3 :Letter Box 4 :Native 5: 2.35:1 0 = Fill 1 = 4:3 2 = 16:9 VXXG0301 56h Xh Xh 47h 30h 33h 30h 31h 0Dh...
  • Page 80 Command Group 03 Return ASCII Function Description Value 0:Eco VXXG0319 56h xh xh 47h 30h 33h 31h 39h 0Dh Get Lamp Mode 1:Normal Pn/F 2:Dynamic Eco 0:Eco VXXS0319n 56h xh xh 53h 30h 33h 31h 39h nh 0Dh Get Lamp Mode 1:Normal 2:Dynamic Eco 0:STD...
  • Page 81 Command Group 03 Return ASCII Function Description Value VXXG0345 56h xh xh 47h 30h 33h 34h 35h 0Dh Get G_Gain n= 0~100 Pn/F VXXS0345n 56h xh xh 53h 30h 33h 34h 35h nh 0Dh Set G_Gain n= 0~100 VXXG0346 56h xh xh 47h 30h 33h 34h 36h 0Dh Get B_Hue n= 0~100 Pn/F...

  • Page 82: For Dh772Ust / Dh773Usti

    FOR DH772UST / DH773USTi Communication parameter setup You can use the serial control command to input commands for projector control or retrieve its operational data through Windows client terminal software Item Parameter: Bit per Second 9600 bps Data Bit 8-bit Parity None Stop Bit...
  • Page 83 Function Operation Set Get Inc Dec EXE Values 0 = Off Auto Source auto.src 1 = On 0 : Off Video AGC video.agc 1 : On Video Saturation video.saturation 0 ~ 100 Video Tint video.tint 0 ~ 100 0 : Off Closed Captioning 1 : On -5 ~ +5...
  • Page 84 Function Operation Set Get Inc Dec EXE Values Brilliant Color bri.color 0 ~ 10 Sharpness sharp 0 ~ 31 0 = 1.8 1 = 2.0 2 = 2.2 Gamma gamma 3 = 2.4 4 = B&W 5 = Linear 0 = Warm Color Temperature color.temp 1 = Normal...
  • Page 85 Function Operation Set Get Inc Dec EXE Values 0 : Off Low Power Mode standby.power 1 : On 2 : On By Lan No Signal Power Off nosignal.poweroff V 0 ~ 36 Sleep Timer sleep.timer 0 ~ 120 Volume volume 0 ~ 10 0 : Off 1 : On...
  • Page 86 Function Operation Set Get Inc Dec EXE Values 0 = English 1 = French 2 = German 3 = Spanish 4 = Portugues 5 = Simplified Chinese 6 = Traditional Chinese 7 = Italian 8 = Norwegian 9 = Swedish 10 = Dutch 11 = Russian Language...

  • Page 87: About The Vivitek Support

    PPENDIX About the Vivitek Support If you cannot find solutions from this user guideline, please contact us using the contact information below: Europe, Middle East and Africa Vivitek Service & Support Zandsteen 15 2132 MZ Hoofddorp The Netherlands Tel: +31-(0)-20-721-9318 Email: support@vivitek.eu...
