Arena Par
System Menu.
The Arena Par comes with an easy to navigate system
menu. This next section will detail the functions of each command in
the system menu. Please read the next section thoroughly!
To access the main menu press the MENU button. Tap the UP or DOWN
buttons until you reach function you wish to change. When you reach
the function you wish to change press the ENTER button. When a
function is selected use the UP or DOWN buttons to change the func-
tion settings. Once your changes are made press the ENTER button,
and then press and hold the MENU button for at least three seconds
to confirm and lock the change into the system memory. If the MENU
button is not pressed and held within eight seconds the fixture will
automatically confirm and lock the change into the system memory. To
exit without making any changes press the MENU button.
ADDR -
DMX Address Setting.
1. First set the unit to your desired DMX Channel mode.
2. To set your address, tap either the MENU, UP, or DOWN
buttons until "ADDR" is displayed, press ENTER. "1" will now be
displayed and flashing.
3. Press the UP or DOWN buttons to find your desired address.
When you have found your desired DMX address press ENTER,
then press and hold MENU for 3 secs.
4. Connect your DMX Controller.
CHND -
This will let you switch between the 3 DMX
Modes.
1. Press the MENU button until "CHND" is displayed, press
ENTER. Either "4 CH" (4 Channel Mode), "5 CH" (5 Channel
Mode), or "7 CH" (7 Channel Mode) will be displayed
2. Press the UP or DOWN buttons to choose your desired DMX
mode and press ENTER to confim and exit.
©Elation Pr fessionals® - www.elationlighting.com - Arena Par Instruction Manual Page 9
o
System Menu Arena Par
SLND -
master/slave configuration.
1. Tap the MENU button until "SLND" is displayed, press ENTER.
Either "SL 1" or "SL 2" will be displayed.
2. Tap the UP or DOWN buttons until your desired setting is dis-
played, press ENTER and then hold MENU for at least 2-3 seconds
to confim.
NOTe: In a Master/Slave configuration you can make one fixture the
Master and then set the next fixture to "SL 2", the fixtures will now
have contrast movement to each other. Also, when a slave fixture
is set as "SL 1" and one is set "SL 2", the fixtures will have contrast
movement to each other.
SHND
show, color mode, or fade mode. Show mode can be run
with sound activity or without. For show mode to run without
sound activity turn sound activity off.
1. Press the MENU button until "SHND" is displayed, press ENTER.
2. Either "FADE", "COLO", or "SH 0" will be displayed. The modes are
explained below.
Fade mode will fade through the different colors. The speed of the
Fade mode is adjustable, 1 being the fastest and 3 being the slowest.
Color Mode you can choose 1 of 10 colors to remain static.
Show 0 is a random show.
3. Press the UP or DOWN buttons to find your desired show mode
and press ENTER, then press and hold the MENU button for at least 3
seconds to confirm.
SOUN -
1. Tap the MENU button until "SOUN" is displayed, press ENTER.
2. The display will show either "ON" or "OFF". Press the UP or DOWN
©Elation Pr
This will let you set unit as a master or slave in a
- In show mode you can choose either a random
Sound Active mode.
fessionals® - www.elationlighting.com - Arena Par Instruction Manual Page 10
