- Page 1 METROLOGIC INSTRUMENTS, INC. ® TECH 7 Laser Bar Code ® Projection Scanner Installation and User’s Guide...
- Page 2 Copyright © 2006 by Metrologic Instruments, Inc. All rights reserved. No part of this work may be reproduced, transmitted, or stored in any form or by any means without prior written consent, except by reviewer, who may quote brief pas...
-
Page 3: Table Of Contents
Table of Contents Introduction ......... . 1 Unpacking List . -
Page 5: Introduction
Algorithm). An Application Specific Integrated Circuit (ASIC) is in the © decoding system and virtually eliminates misreads. MECCA (Metrologic Enhanced Code Correcting Algorithm) enables the TECH 7 scanner to read poorly printed, wrinkled or even torn bar codes on the first pass. -
Page 6: Scanner Installation
3. Connect the other end of the communication cable to the host device. Note: The following statement is applicable if the optional power adapter available through Metrologic does not power the bar code scanner and the scanner receives power from a host device such as a computer system. -
Page 7: Configuration To The Host System
Configuration to the Host System The scanner is shipped from the factory programmed to a set of default conditions noted in the ScanSelect™ Scanner Programming Guide by an asterisk that appears before the brief definition located next to the bar code. In order for the scanner to communicate with a host system properly, it may need to be programmed. -
Page 8: Stand Installation
Stand Installation With the Metrologic stand (Part #45475), the scanner can be posi tioned in one of two directions. The two orientation choices are vertical or horizontal. (Refer to Figure 1) Horizontal Mount Vertical Mount Figure 1: Stand Orientation To install this stand, use the four 6-32 x ½ inch machine screws and two #10 pan head wood screws. -
Page 9: Back Plate Installation
Back Plate Installation With the Metrologic back plate (Part #45473), position the scanner in one of two directions. The two Vertical Mount orientation choices are vertical or horizontal. (Refer to Figure 4). To use this stand, use the four 6-32 x ½ inch machine screws and... -
Page 10: Parts Of Scanner
Parts of Scanner Figure 6: Scanner Parts G reen and Red LEDs When the green LED is on, this indicates that the unit is receiving power and the laser is on. When the red LED flashes on, the scanner has read a bar code successfully. When the red light turns off, communication to the host is complete. -
Page 11: Visual Indicators
Visual Indicators There is a red and green LED at the top of the scanner. When the scanner is on, the flashing or stationary activity of the LEDs indicates the status of the scan and scanner. Steady Green When the laser is on, the green LED is also on. This occurs when an object is in the scan field. - Page 12 Signaux Optiques Sur la partie supérieure du scanner se trouvent une diode LED rouge et une diode LED verte. Quand le scanner est sous tension, les diodes rouge et verte clignotantes ou allumées vous informent sur l'état du scanner. Ni la diode rouge, ni la diode verte n'est allumée Il existe deux raisons possibles pour que les diodes ne s'allument pas.
- Page 13 Optische Anzeigen Auf dem Scanner befinden sich eine rote und eine grüne Leuchtdiode. Bei eingeschaltetem Scanner geben Ihnen die blinkenden bzw. feststehenden Leuchtdiodenanzeigen Aufschluß über den Abtast-und Scannerstatus. Weder rote noch grüne Leuchtdiodenanzeige Es gibt zwei mögliche Gründe, weshalb die Leuchtdiodenanzeigen nicht aufleuchten.
- Page 14 Segnali Ottici Sullo scanner si trovano due diodi luminosi: uno rosso e uno verde. Quando lo scanner è inserito, i diodi luminosi, che possono o essere accesi in continuazione o lampeggiare, Vi informano sullo stato della scansione e dell'apparecchio. Né il diodo luminoso rosso né quello verde sono accesi Vi sono due possibili cause se i diodi luminosi non sono accesi.
-
Page 15: Labels
The following are samples of the labels located on the unit. Metrologic ® This product complies with US Metrologic Instruments, Inc. DHHS Standard 21 CFR Chapter 1 Blackwood, New Jersey, USA Subchapter J. Class IIa Laser Contains no user serviceable Product. -
Page 16: Depth Of Scan Field For The Ms770 Scanner
Depth of Scan Field for the MS770 Scanner The depth of field for the scanner is 76mm to 254mm (3.00” - 10.00”) from the laser output window. Pass the symbol through the scan area in order for the scanner to recognize the bar code. (Refer to Figure 7) 76 mm [3.00 in] 254 mm [10.00 in] 152 mm [6.00 in]... -
Page 17: Depth Of Field For The Ms775 Scanner
Depth of Scan Field for the MS775 Scanner The depth of field for the scanner is 76mm to 254mm (3.00” - 10.00”) from the laser output window. Pass the symbol through the scan area in order for the scanner to recognize the bar code. (Refer to Figure 8) 76 mm [3.00 in] 254 mm [10.00 in] 229 mm [9.00 in]... -
Page 18: Maintenance
Maintenance Smudges and dirt can interfere with the proper scanning of a bar code. Therefore, the output window will need occasional cleaning. 1. Spray glass cleaner onto lint free, nonabrasive cleaning cloth. 2. Gently wipe the output window. Applications and Protocols The model number on each scanner includes the scanner number and communications protocol. -
Page 19: Appendix A Specifications
Appendix A Specifications Application: Industrial Projection Scanner Light Source: Visible Laser Diode 650 ± 5 nm or 670 ± 5 nm CDRH: CLASS IIa laser product Certifications: CE, UL listed for the US and CUL for Canada EMC: EN 60825: Class 1 EMI: FCC, ICES-003 &... -
Page 20: Operational
Appendix A (Continued) Operational Depth of Scan Field: 76mm to 254 mm (3 in to 10 in) Scan Speed: Model 770: 2000 scan lines per second Model 775: 1200 scan lines per second Scan Pattern: Model 770: Omnidirectional (20 interlocking lines) Model 775: 12-line raster Indicators: LED: green = laser on;... -
Page 21: Appendix B Pin Assignments
Appendix B Pin Assignments Version "1" Pin Assignments for RS-232, OCIA, and Bi-direc tional RS-232 Each TECH 7 scanner has a 19-pin male Mil spec connector that is located on the side of the unit. To connect the scanner to the host device, use a communication cable with a female Mil spec connector. - Page 22 Appendix B (Continued) Version "15" Pin Assignments for Light Pen Emulation Each TECH 7 scanner has a 19-pin male Mil spec connector that is located on the side of the unit. To connect the scanner to the host device, use a communication cable with a female Mil spec connector. The communication cable may include a power supply or it may be designed to draw power directly from the host device.
-
Page 23: Warranty And Disclaimer
In the event that it is determined the equipment failure is covered under this warranty, Metrologic shall, at its sole option, repair the Product or replace the Product with a functionally equivalent unit and return such repaired or replaced Product without charge for service or return freight, whether distributor, dealer/reseller, or retail con... -
Page 24: Appendix D Notices
Appendix D Notices This equipment has been tested and found to comply with limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. - Page 25 Appendix D (Continued) European Standard Warning This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Funkstöreigenschaften nach EN 55022:1998 Warnung! Dies ist eine Einrichtung der Klasse A. Diese Einrichtung kann im Wohnbereich Funkstörungen verursachen;...
-
Page 26: Appendix E Patents
Appendix E Patents For patent information, please refer to www.honeywellaidc.com/patents. -
Page 27: Index
Index AC 2 Labels 11 Applications 1, 14, 15 LED ASIC 1 green 2, 6, 7, 8, 9, 10 Atrium option 6 red 2, 6, 7, 8, 9, 10 Autodiscriminate 1, 16 Light Pen Emulation 14, 16, 18 Back Plate 1, 5, 15 Maintenance 14, 16 Bidirectional RS-232 14, 17 MECCA 1... - Page 28 Index Scan pattern 1, 16 Scan Speed 16 ScanSelect 3 ScanSet® 3 Service Center 7 Specifications 15 Stand 1, 4, 15 Visual Indicators 7, 8, 9, 16 Voltage 15 Warning 21 Warranty 19 Window 6, 11, 14...
- Page 32 March 2006 Printed in the USA...
