Identification information
24
24
25
The Minibike - Ultima is designated for driving on enclosed tracks on flat and dust free sur-
25
faces. Adults and also children can ride on it. Children can only ride on it under the supervi-
25
sion of a responsible adult. With its construction and equipment the minibike is designated
25
mainly for races on special tracks. The minibikes Blata are not designated to be used during
winter and under worsened climatic conditions. When the minibikes Blata are used during
25
winter and during worsened climatic conditions there occurs an increase of the mechanical
wear and tear of most of the product's parts and corrosion of these parts, especially of the
groups that are exposed to the direct acting of the external effects. Besides this, the driver
exposes themselves to the danger of injury or permanent damage to health, especially whi-
le riding under worsened climatic conditions and mainly during winter.
The minibike is equipped with a single cylinder two-stroke gasoline engine, which is fitted
with an air filter and an exhaust with a damper. The transfer of the driving torque from the
motor to the driven rear wheel is done by a chain drive, whose ratio can be modified in
small limits by the replacement of the sprocket wheels. Both of the minibike's wheels are
fitted with disc brakes. The rear brake is controlled by a lever on the left side and the front
brake is controlled by a lever on the right side of the handlebars.
