- Page 2 1. Safety Guidelines Caution: Always use a power cable is properly grounded. Please use the AC cords listed below for each area: USA ...... UL Canada ....CSA/cUL FCC Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
-
Page 3: Important Safeguards
Important Safeguards Before using your TV, please read these instructions completely, and keep this manual for future reference. Carefully observe and comply with all warnings, cautions and instructions placed on the unit or described in the operating instructions or service manual. The User Manual uses the following symbols to ensure a safe operation and prevent any damage to operators or properties: WARNING----- Ignorance or inappropriate use may cause... - Page 4 Never use a damaged power cord: Heavy objects, heat or tensile force may damage the power cord and cause fire or electric shock. Never block or cover the slots or openings in the TV cabinet back, bottom, and sides. Never place the TV: - on a bed, sofa, rug, or similar surface;...
- Page 5 The power cable should be kept away from heat sources: The heat produced by any heat source may melt the covering of the power cable. Unplug the connector Hold the power connector when removing the power cable: Pulling the power cable itself may damage the wires inside the cable and cause fire or electric shock.
- Page 6 Others: 1). The LCD panel on this TV is manufactured using an extremely high level of precision technology; however, an occasional pixel (dot of light) may display constantly on the screen. This is a structural property of LCD technology and is not a sign of malfunction.
- Page 7 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
- Page 8 Contents 1. Before use .......... 8 Setting of “Parental” ......36 Selection of “Blue Mute” ....38 1.1 Open the Package ......8 Using “Default” ......... 38 1.2 Installation .......... 8 2. Product Features ........ 9 4 Using the TV Menu ......39 3.
-
Page 9: Before Use
1. Before use The product is a 27” WXGA (WXGA resolution) LCD TV/DVD Player Combo. It has passed the UL and cUL safety certifications, and is an ideal product for personal and commercial use. The product is a precise electronic product. Users should read the following instructions carefully to maximize the performance and life span of the product: 1.1 Open the Package The product is packaged in a carton together with other standard accessories. -
Page 10: Product Features
2. Product Features The 27˝ LCD TV/DVD Player Combo provides quality image displays and is suitable for a variety of multi media applications: 1. Available input signals The standard PC module provides VGA (D-SUB 15 PIN), and a RS-232 (D-SUB 9 PIN MALE) communication connector. -
Page 11: Side View
4. Names and Functions of Parts 4.1 Side View The functions of the buttons are described as follows: (OPEN/CLOSE): Press to open or close the disc tray. Sketch map (STOP): Press to stop playing the disc. (PLAY/PAUSE): Press to play or pause the disc. STANDBY: Press (Standby) to turn on and turn off. - Page 12 4.3 Rear View Sketch map Push the power switch (O: Off, I: On). The power indicator on the front of the panel should now display red, indicating that the LCD TV is in standby mode. Use the included power cord and connect to an earthed 100-240V, 50/60Hz AC outlet. Note: Shut down the power switch, turn on it again after the power indicator is extinguished entirely.
-
Page 13: Remote Control
4.4 Remote Control Power ( ): Press to turn on and off. Mute ( ): Press to mute the sound. Press again or press to restore the sound. CCD: Press to select the Closed Caption mode. V-CHIP: Press to select the child protect mode. - Page 14 Freeze: Press to freeze the picture, press again to restore the picture. Menu: Press to enter into the on-screen setup menu, press again to exit. S.Mode: Press repeatedly to cycle through the sound mode: Normal, News, Cinema, Flat and User. , Enter: Press to move the on-screen cursor.
- Page 15 DVD Info: Press to display DVD information. Setup: Press to display a menu. Press it again to exit menu. Repeat: Press repeatedly to cycle through the options: CHAPTER, TITLE, ALL and nothing. Audio: Press to select desired audio track. Prog: Press to display the program menu.
- Page 16 Range of Remote Control Sketch map 20° 20° 30°...
- Page 17 5. Connect Accessory Devices Connecting a DVD player or other equipment Switch off LCD TV and external equipment before connecting cables. 1. Connect a DVD player or other equipment’s Component Video Out Green (Y,Pb,Pr) to the LCD TV’s corresponding Blue White Component In (Y,Pb,Pr) terminal.
- Page 18 Connecting the DVD or VCR player devices Switch off LCD TV and external equipment before connecting cables. 1. Connect a DVD or VCR player’s Video Out to the LCD TV’s Video In terminal by a Video cable. 2. Connect a DVD or VCR player’s S-VIDEO Out to the LCD TV’s S-VIDEO In terminal by a S-VIDEO cable.
- Page 19 Connect audio amplifier Switch off LCD TV and external equipment before connecting cables. 1. Connect the LCD TV-combo’s COAXIAL OUT to the Audio Amplifier COAXIAL Input terminal by a coaxial cable. 2. Press Power to turn on the LCD TV-combo. Turn on external equipment also.
-
Page 20: Basic Operation
6. Basic Operation 6.1 Power ON/OFF: The Display is in Power Standby mode - Press the Power on the remote control or Favorite on the control panel to turn on the unit. The power indicator changes from red to green. - Press the Power on the remote control or on the control panel again to return the...
