User Manual
WORKSHOP MANUAL
Extra Small Fold-a-Way Spring
Large Fold-a-Way Spring
Extra Large Fold-a-Way Spring
In case of difficulty contact: -
Tendercare Ltd
PO Box 3091, Littlehampton, BN16 2WF
Tel (01903) 726161
Fax (01903) 734083
Document. 045-02v1Foldaway Spring workshop manual.doc.
Authority.
Quality Controller
Authorised. J Adams
Fold-A-Way Spring Workshop Manual
Small Fold-a-Way Spring
Please read these instructions carefully
Before attempting to maintain the pushchair
Tendercare Ltd
Sept 05
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Tendercare Extra Small Fold-a-Way Spring
Summary of Contents for Tendercare Extra Small Fold-a-Way Spring
- Page 1 Tendercare Ltd Fold-A-Way Spring Workshop Manual WORKSHOP MANUAL Extra Small Fold-a-Way Spring Small Fold-a-Way Spring Large Fold-a-Way Spring Extra Large Fold-a-Way Spring Please read these instructions carefully Before attempting to maintain the pushchair In case of difficulty contact: - Tendercare Ltd...
- Page 2 Tendercare Ltd Fold-A-Way Spring - Workshop Manual Harness Mounting Frame Slots Lock “L” Shaped Footrest Brake Pedal Seat Tilt Lock FOLD-A-WAY SPRING PUSHCHAIR Document No 045-02v1Foldaway Spring workshop manual.doc Page 2 Authority. Quality Controller Authorised. J Adams Sept 05...
-
Page 3: Table Of Contents
Tendercare Ltd Fold-A-Way Spring - Workshop Manual Item Description Page Your Fold-A-Way Spring Workshop Manual……………………..…………….. Transit Packaging…….………………………..……….……….…………………. Tools & Torque Settings………………………………….…….………………….. Preparing for use and operation……...………………………….………………... 4.1 Unfolding and assembling the pushchair…………….………….….…………… 4.1.1 Unfolding the frame…..……..………………….…….……………… 4.1.2 Folding the backrest…………..……………….……..………………. -
Page 4: Your Fold-A-Way Spring Workshop Manual
The recommended maximum user weight includes the occupant, carrying tray and any other items carried. All sizes and weights are given as a guide. Tendercare Ltd reserves the right to amend specifications at any time as part of their product development programme. -
Page 5: Tools & Torque Settings
5 point harness User Manual If any items are damaged or missing please contact Tendercare, Preferably by fax 01903-734083 within 36 hours of delivery. 5) Remove the upholstery from the plastic bag and any protective bubble wrap from the frame. Take particular note to remove the foam pads from the backrest folding mechanism. -
Page 6: Preparing For Use And Operation
Tendercare Ltd Fold-A-Way Spring - Workshop Manual 4. Preparing for use and operation Warning. When opening or folding the pushchair, ensure that you hold the frame so that you avoid any danger of catching your fingers in moving parts. The following pre-delivery procedures should be carried out to check that the pushchair has not suffered damage during transit and that all features operate satisfactorily. -
Page 7: Seat Pads
Tendercare Ltd Fold-A-Way Spring - Workshop Manual 3) Check that there are no signs of cuts, nicks or fraying in the webbing or stitching. 4) Check that the length adjustment mechanism and release button on the 5-point harness works correctly. -
Page 8: Tilt In Space
Tendercare Ltd Fold-A-Way Spring - Workshop Manual 4.3 Tilt in Space: - Follow the instructions in section 4.9 of the user manual. Check that the tilting and seat locking system operates properly throughout its range of adjustment. Important – Always support the front of the seat when operating the gas spring release lever. -
Page 9: Patterned "L" Shaped Pad Cover
If a fault is found stop using the pushchair until it has been corrected. Advice can be obtained from Tendercare Ltd. See the front cover or page 3 for contact details. 1) Always wipe the pushchair dry. Never put it away damp. -
Page 10: Repairs
Remove with a dry lint free cloth. Note that the bearings are maintenance free and should not be lubricated. 8) Examine tyres for sharp objects, cuts or splits. For all other repairs refer to your issuing authority or Tendercare Ltd. 7.0 Repairs Only an authorised repairer should carry out the following repairs. -
Page 11: Castor Assemblies
Tendercare Ltd Fold-A-Way Spring - Workshop Manual 7.2 Castor Assemblies: - Replace as follows if damaged or worn. Retaining Nut 1. Always replace castors as a complete assembly. Never change the wheels alone. 2. Unscrew the retaining nut (see picture opposite) using a 19mm spanner and remove the assembly from the frame. -
Page 12: Brake Rod
Tendercare Ltd Fold-A-Way Spring - Workshop Manual Re-assembly 1) Screw a new lock nut onto the new gas strut. See photo “A” above. 2) Screw the gas strut into the operating lever assembly until the operating lever is just touching the pin that extends from the end of the gas strut. - Page 13 1) Do not reuse Nyloc nuts. Always replace with a new Nyloc nut. 2) Always use Loctite thread locking compound Grade 241. 3) Always use recommended components and parts available from Tendercare Ltd. 4) Do not modify or repair the frame...
-
Page 14: Document No 045-02V1Foldaway Spring Workshop Manual.doc Page
Tendercare Ltd Fold-A-Way Spring - Workshop Manual General Assembly Fold-A-Way Spring Document No 045-02v1Foldaway Spring workshop manual.doc Page 14 Authority. Quality Controller Authorised. J Adams Sept 05... - Page 15 Tendercare Ltd Fold-A-Way Spring - Workshop Manual Parts List Extra Small Fold-A-Way Spring Ref No Part No Description Quantity Req. MS7MA Handlebar (Extra Small) MS5MA Front Wheel Frame (Extra Small) MS11MA Rear Wheel Frame (Extra Small) MS1MA Seat Frame Cradle (Extra Small)
- Page 16 Tendercare Ltd Fold-A-Way Spring - Workshop Manual Parts List Small & Large Fold-A-Way Spring Ref No. Part No. Description. Quantity Req. MS7M Handlebar (Small & Large) MS5M Front Wheel Frame (Small & Large) MS11M Rear Wheel Frame (Small & Large) MS1M Seat Frame Cradle (Small &...
- Page 17 Tendercare Ltd Fold-A-Way Spring - Workshop Manual Parts List Extra Large Fold-A-Way Spring Ref No. Part No. Description Quantity Req. MX7M Handlebar (Extra Large) MX5M Front Wheel Frame (Extra Large) MX11M Rear Wheel Frame (Extra Large) MX1M Seat Frame Cradle (Extra Large)
