Page 1: User Manual
New Aluminium Mini Tilt Wheelchair New Aluminium Mini Tilt Wheelchair User Manual IMPORTANT Please read these instructions carefully Before using the Wheelbase or Interface Document No: 054-01 v3 Page 1 of 23 August 2010 Mintilt (newstyle) user manual.doc... - Page 2 New Aluminium Mini Tilt Wheelchair Fig 0.1: 14” Mini Tilt with standard accessories (full tilt) Fig 0.2: 14” Mini Tilt folded for transport Document No: 054-01 v3 Page 2 of 23 August 2010 Mintilt (newstyle) user manual.doc...
-
Page 3: Table Of Contents
New Aluminium Mini Tilt Wheelchair Item Description Page Who to contact in difficulty Intended User 2.1 Size and weight 4 - 5 Unpacking Preparing the wheelchair for use 4.1 Unfold and lock the backrest 7 - 8 4.2 Adjust the push handles 8 - 9 4.3 Fit and adjust the armrests... -
Page 4: Who To Contact In Difficulty
The maximum carrying weight is to include occupant, seating systems and all accessories and should not exceed 57Kg (9 stone). 2.1: Size and weight: All sizes and weights are given as a guide. Tendercare ltd reserves the right to amend specifications at any time as part of their product development programme. Weight*: 12”: 15kg... - Page 5 New Aluminium Mini Tilt Wheelchair Mini Tilt Open (no tilt) Dimensions (mm) 12” 14” 16” 1050 1050 1050 Mini Tilt Folded Dimensions (mm) 12” 14” 16” Document No: 054-01 v3 Page 5 of 23 August 2010 Mintilt (newstyle) user manual.doc...
-
Page 6: Unpacking
QTY. Mini Tilt Wheelchair Armrests User Manual IMPORTANT: If any items are damaged or missing, then please contact Tendercare, preferably by email at info@tendercareltd.com or alternatively please call us on (01903) 726161 within 36 hours of delivery. After unpacking and checking you have all components and they are in good condition dispose of the packaging at your local recycling centre. -
Page 7: Unfold And Lock The Backrest
New Aluminium Mini Tilt Wheelchair 4.1: Unfold and lock the backrest: The Mini Tilt will be supplied complete, but in its folded position. First unfold the back by lifting the backrest as far as it will move (see left). Please note that the locking bolts must be in the “unlocked”... -
Page 8: Adjust The Push Handles
New Aluminium Mini Tilt Wheelchair Always ensure that the bolts have moved the full length of the slot, and cannot move any further. To release the locking bolts, lift the full length of the slot and move towards the inside of the chair. - Page 9 New Aluminium Mini Tilt Wheelchair Once loose, simply move the handle to the required height and angle, and lock by rotating the clamping lever in the opposite direction until the handle no longer moves. push handles have safety mechanism, which prevents the handle from being fully removed from the frame.
-
Page 10: Fit And Adjust The Armrests
New Aluminium Mini Tilt Wheelchair 4.3: Fit and adjust the armrests: To fit the armrest, loosen thumbscrew A (turn anti clockwise) and release the spring catch B by turning 90 degrees in either direction. Whilst holding catch B in this position, push the armrest into the socket. -
Page 11: Tilt In Space
New Aluminium Mini Tilt Wheelchair To adjust the footrest height: Using a 5mm hexagon key loosen the screw on the side of the footrest (see left). Move the footrest to the desired height and retighten the screw. IMPORTANT: Make sure the screw fits into one of the indentations in the support rod. -
Page 12: Tyres And Brakes
New Aluminium Mini Tilt Wheelchair 4.6 Tyres and brakes: The tyres are made from a solid material and do not require any attention other than being cleaned with a damp cloth when dirty. Check both brakes by moving lever “D” (see fig 4.6.1) forwards as far as it will go. - Page 13 New Aluminium Mini Tilt Wheelchair To move the rear wheel position: Using two 19mm spanners undo the axle- mounting nut. Make sure you note the position of the washer and spacer bushing. Reassemble in the rear position, apply loctite to the threads and tighten the nut.
-
Page 14: Tipping The Wheelchair
New Aluminium Mini Tilt Wheelchair 4.8: Tipping the wheelchair To tip the wheelchair backwards when climbing kerbs, stand behind the wheelchair holding onto both push handles. Place one foot; either right of left whichever suits you, onto the tipping point (see right). Press down with your foot and pull back with your arms. - Page 15 New Aluminium Mini Tilt Wheelchair To fit the tray to the seat, locate the 2 vertical stems on the bottom of the tray into the 2 receivers on the armrests. Position the tray to the required height, and then secure it in place by tightening the thumbscrews (‘A’...
-
Page 16: User Instructions
New Aluminium Mini Tilt Wheelchair Notes: • The tray must be removed when transporting the chair in specially adapted vehicles. • The tray and armrests must be removed before folding the wheelchair. • Never leave the occupant unattended with the tray fitted, especially when items are positioned on the tray. -
Page 17: Attendant Pushing
New Aluminium Mini Tilt Wheelchair 6: Attendant pushing 6.1 Pushing 1. The wheelchair is easy to push over hard, even surfaces but may be more difficult over rough; uneven surfaces and the wheels may sink into soft ground. Never force the wheelchair if it becomes stuck, this may cause the rear wheels to lift and the user may be tipped out of the chair. -
Page 18: Comfort
New Aluminium Mini Tilt Wheelchair 6.3 Comfort Always be considerate to the occupant. Before setting out on a journey make sure the occupant is comfortably and correctly seated and that any safety harness is correctly fitted and adjusted. Always ensure that both feet are supported and that clothing is tucked in and cannot catch on doorways or other obstructions. -
Page 19: Maintenance
4. Check operation of the brake, folding and reclining mechanisms (weekly). 5. Clean frame when necessary (we suggest at least once a week). If you find any faults refer to your issuing authority or Tendercare Ltd. 8.2 Six-monthly maintenance Only someone who is a competent tradesman or repairer should carry out this work. If a major fault is found stop using the wheelchair until it has been corrected. -
Page 20: Warranty
12 months from the date of delivery. Tendercare Limited will not repair or replace free of charge any part or parts found to be defective due to abuse, misuse or lack of correct maintenance. -
Page 21: Attaching Wheelchair
New Aluminium Mini Tilt Wheelchair 10.2 Attaching wheelchair to vehicle The wheelchair must be attached to the vehicle using a 4-point wheelchair webbing restraint (not karabiner) that complies with ISO 10542, SAE2249 or DIN7507/2. No other restraint system can be used. -
Page 22: Fig 11.2.3
New Aluminium Mini Tilt Wheelchair Rear anchorage point The rear anchorage point is located around the hinges between the seat base and backrest frames. Fig 11.2.3 Attach the rear restraint to the floor track and then around the back frame tube as shown (right). -
Page 23: Repairs
New Aluminium Mini Tilt Wheelchair Fitting Passenger Belts: The passenger MUST be restrained using an approved vehicle safety belt. Tendercare Ltd recommends the use of either a split reel double inertia seat belt or a 3 – point occupant restraint system (Such restraints are manufactures by Unwin Safety Systems & Q ‘Straint).
