Raymarine ST60+ Depth Instrument Quick Start Manual

Switch off & on
Switch off
ON
PWR OFF
COUNTDOWN (3 - 2 - 1 - 0)
Hold
down
DEPTH
until instrument switches off (approx. 8 seconds)
Switch on
OFF
DEPTH
Hold down
1 second
Note:
When power is first applied, the instrument powers up in the ON
condition. You do not need to use the DEPTH button to switch it on.
Adjust backlighting & contrast
Adjust
backlighting
OFF
Times out to normal operation after 7 seconds
DEPTH
D8331-1
Adjust
contrast
ON
Times out to
normal operation
after 7 seconds
D8330-1
Raymarine Ltd, Quay Point, Northarbour Road, Portsmouth, Hampshire PO6 3TD, UK
Raymarine, Inc, 21 Manchester Street, Merrimack, NH 03054, USA
Document number: 86116-1
Hold down
DEPTH
1 second
DEPTH DEPTH
DEPTH
DEPTH DEPTH
Hold down
DEPTH
2 seconds
DEPTH
DEPTH
DEPTH
DEPTH
+44 (0) 23 9269 3611
Toll Free: 800-539-5539
+1 603-881-5200
Date: December 2005
ST60+ Depth
Instrument
ST60 +
D8332-1
DEPTH
ALARM
Quick Start Guide
D8333-1
DEPTH
RESET
OFFSET
