Summary of Contents for Monacor DMR1908LCD
-
Page 2: Table Of Contents
User Manual CONTENTS SAFETY INSTRUCTIONS ..............................1 CHAPTER 1: DVR FEATURES............................2 CHAPTER 2:LAYOUT ................................3 ................................3 2.1 P ANEL UTTONS ..............................4 2.2 S ANEL NTERFACE ..............................5 2.3 M I/O ‘L’ A ULTI DAPTER ................................ - Page 3 User Manual ................................21 5.7 S TOP RECORDING CHAPTER 6: NET-VIEWER PROGRAM ......................... 22 ........................22 6.1 P INS DOWNLOAD AND INSTALLATION ..............................22 6.2 L IN TO IEWER ..........................23 6.3 M NTERFACE OF VIEWER 6.3.1 Menu column ..............................
-
Page 4: Safety Instructions
User Manual Safety Instructions Use proper power source. Do not use this product with a power source that applies more than specified voltage (100-240V AC). Never insert anything metallic into the DVR case. Putting something into the DVR case can be a source of dangerous electric shock. Do not operate in wet &... -
Page 5: Chapter 1: Dvr Features
User Manual Chapter 1: DVR Features Real time monitoring Supports real time surveillance via Monitor Saves Recordings DVR saves real-time recording image to HDD Backup Recordings Supports DVR backup via USB flash drive and hard drive. Playback Recordings Supports DVR single CH and multiple CH playback of recorded files Network operation Supports remote surveillance by multiple users simultaneously Supports HDD &... -
Page 6: Chapter 2:Layout
User Manual Chapter 2:Layout 2.1 Panel Buttons (Please refer to actual product for detail) Buttons/ Item Marks Functions Indicators ON/OFF ON/OFF Turns the screen on or off. MENU MENU Opens the Main Menu screen. Move up Down DOWN Move Down... -
Page 7: Side Panel Interface
User Manual 2.2 Side Panel Interface (Please see actual product for detail) Item Physical ports Connection method Power Port Connect power supply - DC12V 5A Connect intranet, internet (RJ45 interface) Ethernet Port USB Port Connect USB mouse USB Port Connect USB device (Flash Drive, Hard Drive) Audio output Connect signal output (RCA interface) Video outputs... -
Page 8: Multi I/O 'L' Adapter
User Manual 2.3 Multi I/O ‘L’ Adapter (Please see actual product for detail) Item Physical Jacks Connection method Audio Input Connects to the audio output of an audio enabled camera Connect to the signal output of cameras Video Inputs PTZ Outputs Connect to the PTZ input of any Pan-Tilt-Zoom enabled camera... -
Page 9: Remote Control
User Manual 2.4 Remote Control Channel Select 1-8 ; Numeric key 9、0 Numeric Key Preview all Channel Enter/Exit Main Menu Menu ▲ Up Key ▼ Down Key ◄ / Left / Right Key Select Key/ Edit Key Rewind key Play Key, Enter to recording search menu Forward Key ●... -
Page 10: Chapter 3: Dvr Installation
User Manual Chapter 3: DVR Installation 3.1 Hard Drive Installation Caution： Please do not Install or take out hard drive when DVR is running! (1) Remove screws and open DVR upper cover carefully; (2) Insert Power Cord and data cable into Pin of hard drive securely; (3) Put the upper cover back carefully, re-attach screws. -
Page 11: Chapter 4: Dvr Boot Up
User Manual Chapter 4: DVR Boot up 4.1. System Initialization After connecting the power adapter the system will boot-up and start initializing. 4.2. Main Interface After initialization, the system will display main interface. When there are video inputs, live images from the cameras will be displayed on screen. -
Page 12: Main Menu Preview
User Manual Chapter 5. DVR Menu 5.1. Main Menu Preview Color set Camera Dwell time display Recording Search Playback Network File List Rec. Search HDD Management Main Menu E-mail setting Alarm Setting Device Management PTZ Setting Mobile Motion Area setting Time Setting User password Video Setting... -
Page 13: Main Menu
User Manual 5.2 Main Menu After clicking right button of mouse, pop-up menu will be displayed on the screen. You can click [main menu] button on pop-up menu to enter into Main menu interface (Shown as Picture 5-2). You can also use the Menu button on the front panel to bring up the window, when using the front panel buttons use the FWD and REW button to move in the menu, and the SEL button to select the icon. -
Page 14: Record Setup
User Manual 5.2.2 Record setup Click [Main Menu] [Record] to enter into [Record Setup] menu (Shown as Picture 5-5) Functions： 1、The [Rec Mode] button allows you to setup recording 24 hours, on motion, or on a set schedule. 2、[PACK time] indicates maximum continuous time length of recorded files (15, 30, 45, 60 min). - Page 15 User Manual When selecting DHCP, DHCP server will allocate DVR IP address automatically. When selecting PPPoE, you need to input user and password provided by ISP supplier and set up web port (details please refer to the below picture 5-8). Picture 5-8 When selecting static allocation, you need to setup IP address, net-mask, gateway and web port (shown as picture 5-9).
-
Page 16: Recording Search
User Manual 5.2.4 Recording Search Click [Main menu search] to enter into [Video Search] menu (shown as the below picture 5-20). Searched playback: If you input specific date and click [Search], you will find all the recordings for that day. When you select [Date] item, you will playback the recordings in 4 channel mode;... -
Page 17: Multi Player
User Manual 5.2.5 Multi player 1、Copy backup file to your PC. 2、Open multimedia player and click [File Local (F)] to find/select the backup file, and then click [open] button Note: the file type you have selected should be *.264 format. Picture 5-24 Picture 5-25 3、Open backup file:... -
Page 18: Device Management
User Manual Recording date and time processing for the current recording file Play All the windows Previous recording file Add window Pause Start Stop Previous frame / Next frame Delete Slow play, Normal play, Fast Play Convert AVI Next Hour Capture picture Mute switch Reduce window... -
Page 19: Hdd Management
User Manual 5.2.6.1 HDD Management Click [Main Menu Device HDD] to enter [HDD Management] menu (shown as Picture 5-30) Picture 5-30 When you install a HDD, the system will automatically detect if HDD is formatted or not; If HDD needs to be formatted, HDD status will be shown as “Not format”, otherwise, the HDD status will be shown as “Normal”... -
Page 20: Email Alarm Notification
User Manual Email Alarm Notification (to send notice to email account when motion alarm is triggered) Click the [Email setup] menu to enter into its sub menu (shown as Picture 5-33). Picture 5-33 On the [Email setup] mode, refer to its parameter setup shown as picture 5-34 when setting email alarm to “on”. -
Page 21: Ptz Setup
User Manual picture 5-35A. Picture 5-35A 5.2.6.3 PTZ Setup Enter into [Main menu Device PTZ Setup] to select the channel you want to control and set PTZ protocol (Pelco-D or Pelco-P), Baud Rate (1200, 2400, 4800, 9600), Stop bit (1, 2), Parity Check (None, Odd, Even Mark Space), Address Code and Cruise status respectively. -
Page 22: System Function
User Manual MD AREA: This option allows you select the area you want to be sensitive to motion. The channel is separated into a 13*10 area. When any object moves into the motion detection area, and the area where the object is located is displayed in red recording will be triggered. In the semi-transparent area the motion detection is off. -
Page 23: Video Setup
User Manual 5.2.7.3 Video Setup Click [Main Menu System VIDEO] to setup Video, here you can set Camera system（PAL, NTSC）In the USA we use NTSC. You can also set the resolution for the VGA video out port. Your options are 600x480, 800x600, or 1024x768, or 1280x1024. Picture 5-44 5.2.7.4 Language Enter into [System Language] menu to select the language... -
Page 24: Video Search
User Manual 5.4 Video Search Click pop-up menu video search to enter into [Video Search] menu you search files and playback recordings. For more information on this operation refer to the previous section 5.24. 5.5 PTZ Control We introduced setting PTZ parameters previously in chapter 5.2.5.3. Here we will discuss how to operate PTZ controls. -
Page 25: Chapter 6: Net-Viewer Program
User Manual Chapter 6 Net-Viewer Program 6.1 Plug-ins download and installation Open IE browser and input IP address and web port of DVR, such as http://172.18.6.202:80/ and confirm to download and install webcam. If your computer is connected to internet, computer will auto download and install the webcam. -
Page 26: Main Interface Of Net-Viewer
User Manual 6.3 Main Interface of Net-viewer Picture 6.3 Log in Net-viewer and show the interface as follows 6.3.1 Menu column (Section 1 on Picture 6-3) 6.3.2 PTZ Control (Numbers 2, 3, 4 on Picture 6-3) 6.3.3 Live Play Control (Numbers 6 through 10 on Picture 6-3) 6.3.1 Menu column (Section 1 on Picture 6-3) Menu column include [Live] menu, [Replay] menu and [Setup] menu and [Logout] menu. -
Page 27: Setup
User Manual F.F. button: fast forward playback recording Slow button: slow playback recording. Next Frame: play frame by frame. 264 TO AVI button: convert file from H.264 format to AVI format The native format of the backup files is H.264, you can convert H.264 format into more familiar AVI format by clicking the key of 264 to AVI. -
Page 28: Host Info
User Manual System allows you setup motion detection settings for each channel of DVR remotely (shown as Picture 6-8) Picture 6-8 ③ PTZ Control Click [PTZ control] to setup PTZ cameras. Remote setup methods are the same as local DVR setup. Please refer to Section 5.2.5.3 (shown as Picture 6-9). -
Page 29: Log Out
User Manual 6.3.1.4 Log out Log out of the system. 6.3.2 PTZ Control (Numbers 2, 3, 4 on Picture 6-3) Note: below-mentioned series no will be consistent with the remark no shown as Picture 6-2. ○ 2 .PTZ direction control: Control PTZ moving direction ○... -
Page 30: Chapter 7: Specifications
User Manual Chapter 7: Specifications Model Video System NTSC / PAL(Optional) Compression Format Video：H.264 / Audio：8kHz*16bit ADPCM 4-CH BNC Input/ 2-CH BNC Output / 1-VGA output 8-CH BNC input/2-CH BNC output / 1- Video Output (Optional) VGA output (Optional) Audio I/O 1-CH RCA audio input/ 1-CH RCA audio output Display Resolution D1：704×576(PAL) 704×480 (NTSC) -
Page 31: Chapter 8: Windows Vista User
User Manual Chapter 8 Windows Vista User 1、Open IE browse firstly, then enter into Tool bar- and select appear the below picture: 2、Second, select icon tick the settings of “ActiveX controls and plug-ins”to Enable, details as follows: Lastly after tick all the “Enable”, please click to exit. - Page 32 Open IE browser and input IP address and web port of DVR…computer will auto downloadand install the widget. We suggest Visita user set user access authority in order to make your PC safer. Setting processing as follows: Click [Start Set Control panel User account] to set user access authority shown as below picture. Remind: If the widgets are not downloaded successfully, please check if your browser’s safety level or firewall setting is too advanced.
-
Page 33: Chapter 9: Appendix
Chapter 9 Appendix 9.1 Recording Alarm setting Please refer the below matrix: “⊥” stand for “only alarm but no recording”; “AMR” stand for “alarm recording”; “NLR” stand for “normal recording”; and “NOR” stand for “ no recording”. Once alarm is triggered, alarm icon will occur, and when many alarms are triggered, alarm remarks will occur on the screen. -
Page 34: Mail Server Check List
put into the DVR. Make sure the data cables are attached firmly to the RS485 port on the DVR. . Q: Why does the Buzzer keep sounding? A: Please check to see if motion detection is on and the system has detected motion, make sure the hard drive is being detected and has sufficient space available, and that none of your cameras have lost video. -
Page 35: System Connection Configuration
9.5 System connection Configuration 4-CH 8-CH... - Page 36 The material in this document is the intellectual property of our department . No part of this manual be reproduced, copied, translated, transmitted, or published in any form or by any means without our department prior written permission. Our products are under continual improvement and we reserve the right to make changes without noti ce.
