13-1/2 LINGE, 3 EYES CHRONOGRAPH WITH
1. BASIC SPECIFICATIONS
(1) Cal. No.
CALIBRE
Ligne
Size*mm
Date
Total height
Battery life
Battery
(* 60 minutes chronograph operation per day)
(2) Time standard
Type of quartz : Tuning fork type quartz crystal
Frequency
: 32,768Hz
Accuracy
: +/-20 s/month worn under normal circumstances
(3) Balanceable weight of hand
Minute hand Max. 0.4 μN.m
Center Chrono Second hand Max. 0.11 μN.m
Other small hands Max. 0.02 μN.m
(4) Function
Chronograph 1/1 sec. basis (Up to 59 min. 59 sec.)
Powercell Saving Reset Mechanism(PSRM)
Over-loading Compensation Device(OLCD)
Digital Frequency Control(DFC) for time adjustment
Chrono
Minute
Small
Second
Small Hands
Height
750(～700)μm
0S20
MOVEMENT SPECIFICATIONS
CAL.0S2A
ANALOGUE QUARTZ, 0 JEWEL
BY CITIZEN WATCH CO., LTD. JAPAN
MANUFACTURED IN JAPAN
SILVER OXIDE SR927W or equivalent
0S2A
24H
0S20
1200(～1150)μm
0S20
HIGH HAND
*TO CONFIRM WITH MOV'T DRAWING ATTACHED
0S2A
13-1/2
Φ30.80mm
O
5.10mm
Approx. 5 years*
Eye position of 0S2A is the same as 0S20.
Center Hands
Height
350(～300)μm
380(～330)μm
350(～300)μm
380(～330)μm
