Citizen 0S22 Instruction Manual

Hide thumbs Also See for 0S22:

CHRONOGRAPH FUNCTION :

1/20 SEC CHRONOGRAPH WITH RETROGRADE DEMO TIMING UP TO 59 minutes 59 seconds.

A) DISPLAYS AND BUTTONS

B) SETTING THE TIME

C) SETTING THE DATE

D) USING THE CHRONOGRAPH

E) CHRONOGRAPH RESET (INCL. AFTER REPLACING BATTERY)

A) DISPLAYS AND BUTTONS

Chronograph second hand

Hour hand

Chronograph

minute hand

B) SETTING THE TIME

1. Pull the crown out to the 2nd position so that the second hand stops at ZERO position.

2. Turn the crown to set hour and minute hands.

3. When the crown is pushed back to the normal position in synchronization with a time signal,

small second hand begins to run.

Cal. 0S22 Instruction manual

Second hand or 1/20 sec

chronograph hand

1/3

Minute hand

ButtonA

24 hour hand

1st Click position

2nd Click position

Normal crown

position

Button

Calender

Table of Contents

Do you have a question about the 0S22 and is the answer not in the manual?

Page 1 Cal. 0S22 Instruction manual CHRONOGRAPH FUNCTION : 1/20 SEC CHRONOGRAPH WITH RETROGRADE DEMO TIMING UP TO 59 minutes 59 seconds. A) DISPLAYS AND BUTTONS B) SETTING THE TIME C) SETTING THE DATE D) USING THE CHRONOGRAPH E) CHRONOGRAPH RESET (INCL. AFTER REPLACING BATTERY)
Page 2 C) SETTING THE DATE 1. Pull the crown out to the 1st Click Position. 2. Turn the crown anticlockwise to set the date. * If the date is set between the hours of around 9:00 PM and 1:00 AM, the date may not change on the following day. 3.
Page 3 E) CHRONOGRAPH RESET (INCL. AFTER REPLACING BATTERY) This procedure should be performed when the chronograph second hand and chronograph 1/20(1/1) second hand do not return to the ZERO second position after the chronograph has been reset, and including after the battery has been replaced. 1.
