SECTION 7: OPERATION

The heater is intended for use with a 19-8-1517, 19-8-1817, or 19-8-17
Control Panel only. For health and fire safety, never attempt to alter or
bypass the timer or thermostat. If the sauna is to be used without an
automatic timer provided, (Model 19-8-17 Control Panel) an attendant
must be present at all times.
MODEL 19-8-1517 CONTROL PANEL ( 9 Hour Delay /1 Hour Operation)
This control panel is equipped with a 60 minute timer with a 9 hour delay,
an electronic thermostat, a light switch, and a pilot lamp that indicates
when the heater is on. A pilot lamp in the sauna light switch indicates when
the sauna light is on.

SETTING THE TEMPERATURE:

turning the thermostat knob. To raise the temperature, turn the knob
clockwise; to lower the temperature, turn the knob counter-clockwise.
SETTING THE TIME: If you want the heater to begin heating immediately,
turn the dial clockwise past the first marked section labeled "off to 1" (See
Diagram 4), then turn the dial back (counter-clockwise) until you feel it
"click", near the on position, into the one hour operating zone.
The heater has a "9 plus 1" timer, which means you can set the heater to
begin heating after a delay of up to 9 hours. If you set the timer dial in the
"1 to 9" zone, the heater will automatically turn on after the selected delay
time has elapsed.
Light Switch: Use the light switch to turn the sauna room light on and off.
MODEL 19-8-1817 CONTROL PANEL ( 60 minute timer ) This control
panel is equipped with a 60 minute timer, an electronic thermostat, a light
switch, and a pilot lamp that indicates when the heater is on. A pilot lamp in
the sauna light switch indicates when the sauna light is on.
SETTING THE TEMPERATURE:
turning the thermostat knob. To raise the temperature, turn the knob
clockwise; to lower the temperature, turn the knob counter-clockwise.
SETTING THE TIME: Use the timer to turn the heater on. To start the
heater, turn the timer knob clockwise to the desired time setting. Maximum
operating time is one hour.
Light Switch: Use the light switch to turn the sauna room light on and off.
05-4211-710 05/11/01
INSTALLATION AND OPERATING INSTRUCTIONS
The temperature can be adjusted by
The temperature can be adjusted by
Page 5
WARNING
Do not locate benches over
heater. Minimum height of
ceiling above heater 46¾".
Minimum clearance from heater
to wooden surfaces (benches,
heater fence etc. Refer to
Diagram 1)
Use only copper wire of the size
and type indicated in the Heater
Specification Chart and the
temperature rating indicated on
the heater junction box.
All heaters and controls must be
grounded per NEC to prevent
electrical shock in case of unit
failure.
Electrical outlets or receptacle
must not be installed in a sauna
room.
A guardrail or fence is required
around the heater to prevent
burns from accidental contact.
314 SKLF 17 A
