Saunatec 1106-105 Installation And Operating Instructions Manual

SAUNA HEATER
MODELS 10.5, 12.0 & 14.4 (-3 signifies 3 phase)
(With separate control panel & contactor box)
Read all instructions carefully before installation. Please leave all
instructions and warranty with the owner.
WARNING
Prolonged exposure to elevated temperatures is capable of inducing
hyperthermia. Hyperthermia occurs when the internal temperature of the
body reaches several degrees above the normal body temperature of
98.6°F. The symptoms of hyperthermia include an increase in the normal
temperature of the body, dizziness, lethargy, drowsiness, and fainting. The
effects of the hyperthermia include failure to perceive heat, failure to
recognize the need to exit the room, unawareness of impending hazard,
fetal damage in pregnant women, physical inability to exit the room and
unconsciousness.
WARNING
The use of alcohol, drugs, or medication is capable of greatly increasing
the risk of fatal hyperthermia.

SECTION 1: GENERAL INFORMATION

These heaters are UL approved for permanent installations and electrical
connections. Built with splash proof construction, the conducting parts are
protected against water. All wiring must be performed in accordance with
local codes. See Diagram 2 for wire and room size requirements.
These heaters are free standing, secured to the floor, 22 W x 22 D x 30 H,
with separate controls.
05-4211-710 05/11/01
INSTALLATION AND OPERATING INSTRUCTIONS
1201-7-1 or 1201-7-3
1106-105, 1106-120 & 1106-140
19-8....
SET TI M ER
0
50 10
40 20
30
Sauna Heati n g
0 S E T T E M P E R A T U R E
10
Contactor Box
9 1
8 2
7 3
6 5 4
R o o m L i g h t
TEMPERATURE
CONTROL
MODEL 19-8
U L
L i s t e d
S a u n a h e a t e r
N o . 3 3 9 B
Page 1
WARNING
Do not take a sauna if using
alcohol, drugs or medications.
Pregnant women or persons
with poor health should
consult their physician before
using any sauna.
Caution fire hazard: Do not
use the sauna room for drying
clothes, bathing suits, etc. Do
not hang towels above heater
or place any object other than
the rocks supplied on the
heater. If any darkening of the
wall around the heater is
noticed discontinue sauna use
immediately.
Inspect sauna regularly for
required maintenance to
heater, control and benches.
Replace wood surfaces which
show any signs of
deterioration.
The heater gets extremely hot
during operation and should
not be touched or burns may
result.
Minors should be adequately
supervised whenever near a
hot or warming sauna.
314 SKLF 17 A
