COLOUR TELEVISION
HV-29JH24
HV-29JH54
HV-29JH74
HV-29VH14
HV-29VH54
INSTRUCTIONS
Contents
Introduction of the functions
Setting up your TV
TV buttons and functions
Remote control buttons
and functions
Using the TV's menu
Basic operation
. . . . . . . . . . . . . . 19
PICTURE SETTING menu
PICTURE FEATURES menu
SOUND SETTING menu
FEATURES menu
INSTALL menu
. . . . . . . . . . . . . . 29
Additional preparation
Troubleshooting
. . . . . . . . . . . . . . 37
Specification
. . . . . . . . . . . . . . . . . 40
. . . . . . 2
. . . . . . . . . . . . . 3
. . . . . . . . 6
. . . 8
. . . . . . . . . . . . 19
. . . . . 20
. . . 21
. . . . . . 25
. . . . . . . . . . . 26
. . . . . . . . . . 35
GGT0056-001A-H

Advertisement

Table of Contents
loading

Related Manuals for JVC HV-29JH24

Summary of Contents for JVC HV-29JH24

  • Page 1 Setting up your TV ... . . 3 TV buttons and functions ..6 HV-29JH24 Remote control buttons and functions . . . 8...
  • Page 2 Thank you for buying this JVC colour television. To make sure you understand how to use your new TV, please read this manual thoroughly before you begin. WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
  • Page 3 Setting up your TV CAUTION • Turn off all the equipment including the TV before connecting anything. 1 Connecting the aerial and VCR • Aerial cable is not supplied. Use a good quality 75-ohm coaxial cable. Fig. A • Read the manual that came with the VCR before connecting.

  • Page 4: Connecting The Power Cord

    VOLUME TV/VIDEO OVER L/MONO EXIT The TV is turned on, and the JVC logo appears. • If the POWER lamp on the TV lights POWER red and does not change to green, your TV is in the standby mode. Press...
  • Page 5 0 (AV). • If you do not need to use the EDIT/ FAVORITE CH MANUAL function, press the MENU/ OK button to close the EDIT menu. Now, setting up is complete. Please enjoy your new JVC TV! HV-29VH14...

  • Page 6: Turn The Main Power On

    TV buttons and functions Turn the main power on HV-29JH24 / HV-29JH54 / HV-29JH74 Press the main power button 1. The POWER lamp 2 lights red and your TV is in the standby mode. To turn the main power off: Press the main power button again.
  • Page 7 TV buttons and functions VIDEO-1 terminal 0 • See pages 3 and 35. VIDEO-2 terminal - • See page 35. VIDEO-3/COMPONENT terminal = AUDIO VIDEO L/MONO OVER • See pages 28 and 35. VIDEO-1 VIDEO-2 Y/VIDEO AUDIO VIDEO-3 L/MONO COMPONENT OUTPUT AUDIO VIDEO...

  • Page 8: Remote Control Buttons And Functions

    COLOUR SOUND SURROUND ZOOM • You can turn on the TV from the standby mode by pressing the TV/ DISPLAY Except HV-29JH24 VIDEO button, the CHANNEL-/+ MENU HV-29VH14 buttons or the number buttons. TV/TEXT Except To turn the TV off: HV-29JH54 Press the POWER button again.

  • Page 9: Muting Button

    Remote control buttons and functions MUTING button CINEMA SURROUND button Press the MUTING button to turn off the You can enjoy an enhanced sound for a volume. Pressing the MUTING button again wider audience by using CINEMA resumes the previous volume level. SURROUND function.
  • Page 10 Remote control buttons and functions RETURN+ button RETURN function The TV temporarily memorises the TV The RETURN+ button has two functions; channel that was chosen right before the the RETURN+ function and the RETURN current TV channel as the “Last Channel”. function.

  • Page 11: Display Button

    Remote control buttons and functions DISPLAY button COLOUR SYSTEM button You can display the PR LIST, programme The colour system is chosen automatically. number or VIDEO terminal number on the However, if the picture is not clear or no screen. colour appears, choose the colour system manually.

  • Page 12: Favorite Channel

    Remote control buttons and functions BROADCASTING SYSTEMS Favorite channel For sound and colour systems in your registration country or region, refer to the table below: You can register your favorite TV channels COLOUR SYSTEM with the colour buttons (Red, Green, Yellow and Blue).
  • Page 13 Remote control buttons and functions Viewing a teletext • The picture effect dedicated for the colour button applies. For details, see programme “Setting the picture effect” below: [Except HV-29JH54/HV-29VH14/ Setting the picture effect HV-29VH54] Each colour button has a dedicated picture 1 Choose a TV channel with a teletext effect.
  • Page 14 Remote control buttons and functions (Hold) button 3 Press the (Cancel) button to return to a teletext page when the You can hold a teletext page on the screen page number is on the screen. for as long as you want, even while several •...

  • Page 15: Using The List Mode

    Using the List mode You can store the numbers of your favorite picture) function teletext pages in memory and call them up [Except HV-29JH24/HV-29VH14] quickly using the colour buttons. You can display two different pictures, the To store the page numbers: main picture and sub picture, at a time.
  • Page 16 Remote control buttons and functions • When you exit the Twin or PIP mode, For the sub picture: the sub picture lastly displayed will be Press the (Input) button. saved, and it will appear next time. Each time you press the button, the input •...
  • Page 17 Remote control buttons and functions Multi-display function in the Multi-display mode. • If you press the MULTI button when [Except HV-29JH24/HV-29VH14] receiving the Progressive video signal You can watch nine different TV (525P or 625P signal), "525P" or programmes at a time. As you can display “625P”...
  • Page 18 Remote control buttons and functions Freeze function Strobe function [Except HV-29JH24/HV-29VH14] [Except HV-29JH24/HV-29VH14] While watching a picture, you can capture a You can display eight consecutive still still picture you want. The captured still pictures and one moving picture at a time.
  • Page 19 Using the TV’s menu This TV has a number of functions you can operate using menus. To fully utilize all your TV’s functions, you need to understand the basic menu operating techniques fully. • The following remote control is for HV-29JH74. However, the buttons used for setting TV menus are common to all models.

  • Page 20: Picture Mode

    You can also operate the menus using the Softens contrast and sharpness. buttons on the front panel of the TV. • You can also operate the PICTURE MODE function with the PICTURE HV-29JH24/HV-29JH54/HV-29JH74 MODE button on the remote control. For details, see “PICTURE MODE MENU CHANNEL...

  • Page 21: Digital Vnr

    Using the TV’s menu PICTURE FEATURES menu COLOUR You can adjust the picture colour. 2 : lighter 3 : deeper TINT You can adjust the picture tint. 2 : reddish 3 : greenish • You can change the TINT setting (picture tint) only when the colour system is NTSC 3.58 or NTSC 4.43.
  • Page 22 Using the TV’s menu DigiPure MIN: The level of the DigiPure effect is set to the The Digipure function uses the latest in minimum. When you set the DigiPure digital technology to give you a natural function to AUTO and notice some noise, looking picture.

  • Page 23: Colour System

    Using the TV’s menu COLOUR SYSTEM ZOOM The colour system is chosen automatically. You can change the screen size according However, if the picture is not clear or no to the picture aspect ratio. Choose the colour appears, choose the colour system optimum one from three ZOOM modes.

  • Page 24: Video Setting

    Using the TV’s menu FAVORITE CH SETTING • For details of each item, see “PICTURE MODE” on page 20, You can set a dedicated picture effect for “DIGITAL VNR” on page 21, “WHITE the favorite channels registered to the BALANCE” on page 21, “DigiPure” on colour buttons (Red, Green, Yellow and page 22.

  • Page 25: Adjusting The Sound

    Using the TV’s menu SOUND SETTING menu 3 Set the picture effect. Press the 6 button to choose an item listed in the following table and press the 5 button to choose one of options. • As explained in the table, the PICTURE EFFECT for the video inputs is set to OFF when shipped.

  • Page 26: Sleep Timer

    Using the TV’s menu FEATURES menu BALANCE You can adjust the volume balance between the left and right speakers. 2 : turn the left speaker’s volume level up. 3 : turn the right speaker’s volume level up. AI VOLUME You can prevent the sudden increase or decrease of sound that occurs when changing the channel to another channel or SLEEP TIMER...

  • Page 27: Blue Back

    Using the TV’s menu BLUE BACK 2 Set the ID number you want. You can set the TV to automatically change To choose a number: to a blue screen and mute the sound if the Press the 6 buttons. signal is weak or absent, or when there is To move a cursor: no input from an external device.

  • Page 28: Auto Shutoff

    Progressive video signal (525P signal and 625P signal) only when the component video signal is input. 3 Press the number buttons to enter the [Except HV-29JH24/HV-29VH14] ID number. You can enter the Twin or PIP mode from The lock is temporarily released so you the menu without using the remote control.

  • Page 29: Auto Program

    Using the TV’s menu INSTALL menu • To stop the AUTO PROGRAM function, press the MENU/OK button. LANGUAGE 2 After the TV channels have been You can choose the language you want to stored in the programme number list, the EDIT menu appears. use for the on-screen display from the language list in a menu.
  • Page 30 Using the TV’s menu EDIT/MANUAL INSERT: This function adds a new TV channel in The EDIT/MANUAL functions are divided the current programme numbers list by into two types: editing of the current using the CH/CC number. programme numbers (EDIT functions) and DELETE: manual registration of a TV channel you This function deletes an unnecessary TV...
  • Page 31 Using the TV’s menu 1 Press the 6 buttons to choose a TV channel. 2 Press the red button to start the ID function. 3 Enter a channel name (ID). Press the 6 buttons to choose a character. Press the 5buttons to move the cursor.
  • Page 32 Using the TV’s menu INSERT Preparation: • Find the CH/CC number corresponding to the channel number of the TV channel from page 33. 1 Press the 6 buttons to choose a programme number for which you will register a new TV channel. •...
  • Page 33 Using the TV’s menu CH/CC number When you want to use the INSERT function on page 32, find the CH/CC number corresponding to the Channel number of the TV channel from this table. US: The US channel numbers are the channel numbers used in the United States, Philippines, etc.

  • Page 34: Teletext Language

    Using the TV’s menu TELETEXT LANGUAGE 3 Press the MENU/OK button to complete the setting. [Except HV-29JH54/HV-29VH14/ The menu disappears. HV-29VH54] • Languages that are not included in the There are five types of teletext language teletext language group that you groups.
  • Page 35 Additional preparation Connecting the external devices HV-29JH24 Connect the devices to the TV, paying HV-29VH14 HV-29JH54 attention to the following connection HV-29VH54 HV-29JH74 diagram. Before connecting anything: • Read the manuals provided with the devices. Depending on the devices, POWER...

  • Page 36: Connecting Headphones

    Additional preparation Connecting methods • In the VIDEO-4 terminal, the VIDEO jack is indicated by “V”. 1 Connect the TV’s VIDEO jack and the device’s VIDEO OUT (video output) 2 Connect the TV’s AUDIO jacks (L/ jack with a video cable. MONO and R) and the device’s AUDIO If connecting a device to the TV with an OUT (audio L/R output) jacks with an...

  • Page 37: Poor Picture

    Troubleshooting If a problem arises while you are using the TV, please read this “Troubleshooting” well before you request having the TV repaired. You may be able to fix it easily by yourself. For example, if the AC plug is disconnected from the AC outlet, or the TV aerial has problems, you may think there is a problem with the TV itself.
  • Page 38 Troubleshooting • When a white and bright still image • When you are viewing a teletext (such as a white dress) is displayed on programme, you cannot operate the the screen, the white part may look as menus. if it were coloured. Press the TV/VIDEO button to return It is a phenomenon unavoidable due to the teletext programme to the ordinary...
  • Page 39 Troubleshooting phenomena, use the magnetic- shielded speaker instead. • A picture may be tilted due to the influence of the earth’s magnetism. In this case, use the “PICTURE TILT” on page 23 to complete the tilt. • It takes a short period of time from the time an operation such as changing channels is performed until an image is displayed.

  • Page 40: Specifications

    • Video output and Audio L/R outputs are available. Headphone jack Stereo mini-jack (3.5 mm in diameter) Remote control unit × 1 Accessories HV-29JH74 RM-C1350 [ HV-29JH24 RM-C1351 [ HV-29VH14 RM-C1352 [ HV-29JH54/HV-29VH54 RM-C1353 [ AA/R6 dry cell battery × 2 (13cm ×...

  • Page 41: Table Of Contents

    COLOUR TELEVISION Contents Introduction of the functions ..2 Setting up your TV ... . . 3 TV buttons and functions ..6 HV-29JH14 Remote control buttons and functions...

  • Page 42: Introduction Of The Functions

    Thank you for buying this JVC colour television. To make sure you understand how to use your new TV, please read this manual thoroughly before you begin. WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

  • Page 43: Setting Up Your Tv

    Setting up your TV CAUTION • Turn off all the equipment including the TV before connecting anything. 1 Connecting the aerial and VCR • Aerial cable is not supplied. Use a good quality 75-ohm coaxial cable. Fig. A • Read the manual that came with the VCR before connecting.
  • Page 44 TV/VIDEO OVER L/MONO EXIT 1 Press the main power button on the The TV is turned on, and the JVC logo appears. POWER • If the POWER lamp on the TV lights red and does not change to green, POWER lamp your TV is in the standby mode.
  • Page 45 TV channel to the programme number 0 (AV). • If you do not need to use the EDIT/ MANUAL function, press the MENU/ OK button to close the EDIT menu. Now, setting up is complete. Please enjoy your new JVC TV!

  • Page 46: Tv Buttons And Functions

    TV buttons and functions Turn the main power on Press the main power button 1. The POWER lamp 2 lights red and your TV is in the standby mode. To turn the main power off: Press the main power button again. The POWER lamp 2 goes off.

  • Page 47: Aerial Socket

    TV buttons and functions VIDEO-1 terminal 0 • See pages 3 and 28. VIDEO-2 terminal - • See page 28. VIDEO-3/COMPONENT terminal = • See pages 22 and 28. AUDIO L/MONO VIDEO OVER VIDEO-1 VIDEO-2 Y/VIDEO AUDIO VIDEO-3 L/MONO COMPONENT OUTPUT VIDEO AUDIO...

  • Page 48: Remote Control Buttons

    Remote control buttons and functions Turn the TV on from standby mode Press the POWER button. The POWER lamp lights red to green and your TV will be turned on. • You can turn on the TV from the standby mode by pressing the TV/ POWER MUTING VIDEO button, the CHANNEL-/+...
  • Page 49 Remote control buttons and functions MUTING button CINEMA SURROUND button Press the MUTING button to turn off the You can enjoy an enhanced sound for a volume. Pressing the MUTING button again wider audience by using CINEMA resumes the previous volume level. SURROUND function.
  • Page 50 Remote control buttons and functions RETURN+ button RETURN function The TV temporarily memorises the TV The RETURN+ button has two functions; channel that was chosen right before the the RETURN+ function and the RETURN current TV channel as the “Last Channel”. function.
  • Page 51 Remote control buttons and functions DISPLAY button COLOUR SYSTEM button You can display the PR LIST, programme The colour system is chosen automatically. number or VIDEO terminal number on the However, if the picture is not clear or no screen. colour appears, choose the colour system manually.
  • Page 52 Remote control buttons and functions BROADCASTING SYSTEMS Favorite channel For sound and colour systems in your registration country or region, refer to the table below: You can register your favorite TV channels COLOUR SYSTEM with the colour buttons (Red, Green, Yellow and Blue).
  • Page 53 Remote control buttons and functions Setting the picture effect Each colour button has a dedicated picture effect. When you choose a favorite channel, the dedicated picture effect is used. When shipped, the factory set picture effect is used for this purpose. However, you can set this picture effect as required.

  • Page 54: Using The Tv's Menu

    Using the TV’s menu This TV has a number of functions you can operate using menus. To fully utilize all your TV’s functions, you need to understand the basic menu operating techniques fully. Basic operation 1 Press the MENU/OK button to display the MENU (main menu).

  • Page 55: Picture Setting Menu

    Using the TV’s menu PICTURE SETTING menu 4 Press the 5 buttons to choose the setting of that function. • If you want to operate a function which appears only with its name, follow the descriptions of that function on the following pages.

  • Page 56: Picture Features Menu

    Using the TV’s menu PICTURE FEATURES menu COLOUR You can adjust the picture colour. 2 : lighter 3 : deeper TINT You can adjust the picture tint. 2 : reddish 3 : greenish • You can change the TINT setting (picture tint) only when the colour system is NTSC 3.58 or NTSC 4.43.
  • Page 57 Using the TV’s menu DigiPure MIN: The level of the DigiPure effect is set to the The Digipure function uses the latest in minimum. When you set the DigiPure digital technology to give you a natural function to AUTO and notice some noise, looking picture.
  • Page 58 Using the TV’s menu ZOOM FAVORITE CH SETTING You can change the screen size according You can set a dedicated picture effect for to the picture aspect ratio. Choose the the favorite channels registered to the optimum one from three ZOOM modes. colour buttons (Red, Green, Yellow and Blue).
  • Page 59 Using the TV’s menu • For details of each item, see 3 Set the picture effect. “PICTURE MODE” on page 15, Press the 6 button to choose an item listed in the following table and press the “DIGITAL VNR” on page 16, “WHITE 5 button to choose one of options.

  • Page 60: Sound Setting Menu

    Using the TV’s menu SOUND SETTING menu BALANCE You can adjust the volume balance between the left and right speakers. 2 : turn the left speaker’s volume level up. 3 : turn the right speaker’s volume level up. AI VOLUME You can prevent the sudden increase or decrease of sound that occurs when changing the channel to another channel or...

  • Page 61: Features Menu

    Using the TV’s menu FEATURES menu BLUE BACK You can set the TV to automatically change to a blue screen and mute the sound if the signal is weak or absent, or when there is no input from an external device. This function is turned on.
  • Page 62 Using the TV’s menu Press the 5 buttons. 3 Press the number buttons to enter the ID number. 3 Press the MENU/OK button. The lock is temporarily released so you can view the TV channel. If you have forgotten the ID number: Perform step 1 of “To set this function:”...

  • Page 63: Install Menu

    Using the TV’s menu INSTALL menu • To stop the AUTO PROGRAM function, press the MENU/OK button. LANGUAGE 2 After the TV channels have been stored in the programme number list, You can choose the language you want to the EDIT menu appears. use for the on-screen display from the language list in a menu.
  • Page 64 Using the TV’s menu EDIT/MANUAL INSERT: This function adds a new TV channel in The EDIT/MANUAL functions are divided the current programme numbers list by into two types: editing of the current using the CH/CC number. programme numbers (EDIT functions) and DELETE: manual registration of a TV channel you This function deletes an unnecessary TV...
  • Page 65 Using the TV’s menu 1 Press the 6 buttons to choose a TV channel. 2 Press the red button to start the ID function. 3 Enter a channel name (ID). Press the 6 buttons to choose a character. Press the 5buttons to move the cursor.
  • Page 66 Using the TV’s menu INSERT Preparation: • Find the CH/CC number corresponding to the channel number of the TV channel from page 27. 1 Press the 6 buttons to choose a programme number for which you will register a new TV channel. •...
  • Page 67 Using the TV’s menu CH/CC number When you want to use the INSERT function on page 26, find the CH/CC number corresponding to the Channel number of the TV channel from this table. US: The US channel numbers are the channel numbers used in the United States, Philippines, etc.

  • Page 68: Additional Preparation

    Additional preparation Connecting the external devices Connect the devices to the TV, paying attention to the following connection diagram. Before connecting anything: POWER IN (VIDEO-4) MENU CHANNEL VOLUME TV/VIDEO OVER L/MONO EXIT • Read the manuals provided with the (Behind the cover) devices.
  • Page 69 Additional preparation Connecting methods • In the VIDEO-4 terminal, the VIDEO jack is indicated by “V”. 1 Connect the TV’s VIDEO jack and the device’s VIDEO OUT (video output) 2 Connect the TV’s AUDIO jacks (L/ jack with a video cable. MONO and R) and the device’s AUDIO If connecting a device to the TV with an OUT (audio L/R output) jacks with an...

  • Page 70: Troubleshooting

    Troubleshooting If a problem arises while you are using the TV, please read this “Troubleshooting” well before you request having the TV repaired. You may be able to fix it easily by yourself. For example, if the AC plug is disconnected from the AC outlet, or the TV aerial has problems, you may think there is a problem with the TV itself.
  • Page 71 Troubleshooting • When viewing images from again to turn on the main power. If the commercially available video software TV returns to a normal state, it is not a products, or videos from videotapes failure. which have been recorded improperly, •...

  • Page 72: Specification

    • Touching the screen may cause you feel a slight electric shock due to its static electricity. It is an unavoidable phenomenon due to the construction of the picture tube. It is not a problem with the TV. You can rest assured that this static discharge does not have harmful influence over the human body.
  • Page 73 COLOUR TELEVISION Contents Introduction of the functions ..2 Setting up your TV ... . . 3 TV buttons and functions ..6 HV-29VH73 Remote control buttons and functions...

  • Page 74: Introduction Of The Functions

    Thank you for buying this JVC colour television. To make sure you understand how to use your new TV, please read this manual thoroughly before you begin. WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

  • Page 75: Setting Up Your Tv

    Setting up your TV CAUTION • Turn off all the equipment including the TV before connecting anything. 1 Connecting the aerial and VCR • Aerial cable is not supplied. Use a good quality 75-ohm coaxial cable. Fig. A • Read the manual that came with the VCR before connecting.
  • Page 76 When the TV is first turned on, it enters the initial setting mode, and the JVC logo is displayed. 1 Press the main power button on the The TV is turned on, and the JVC logo POWER appears. • If the POWER lamp on the TV lights...
  • Page 77 TV channel to the programme number 0 (AV). • If you do not need to use the EDIT/ MANUAL function, press the MENU/ OK button to close the EDIT menu. Now, setting up is complete. Please enjoy your new JVC TV!

  • Page 78: Tv Buttons And Functions

    TV buttons and functions Turn the main power on HV-29VH73 / HV-29VH74 Press the main power button 1. The POWER lamp 2 lights red and your TV is in the standby mode. To turn the main power off: Press the main power button again. The POWER lamp 2 goes off.
  • Page 79 TV buttons and functions VIDEO-1 terminal 0 • See pages 3 and 35. VIDEO-2 terminal - • See page 35. VIDEO-3/COMPONENT terminal = AUDIO L/MONO VIDEO OVER • See pages 28 and 35. VIDEO-1 VIDEO-2 Y/VIDEO AUDIO VIDEO-3 L/MONO COMPONENT OUTPUT VIDEO AUDIO...

  • Page 80: Remote Control Buttons

    Remote control buttons and functions Turn the TV on from standby mode Press the POWER button. The POWER lamp lights red to green and MUTING POWER your TV will be turned on. SYSTEM CINEMA SURROUND COLOUR SOUND ZOOM • You can turn on the TV from the standby mode by pressing the TV/ DISPLAY Except...
  • Page 81 Remote control buttons and functions MUTING button CINEMA SURROUND button Press the MUTING button to turn off the You can enjoy an enhanced sound for a volume. Pressing the MUTING button again wider audience by using CINEMA resumes the previous volume level. SURROUND function.
  • Page 82 Remote control buttons and functions RETURN+ button RETURN function The TV temporarily memorises the TV The RETURN+ button has two functions; channel that was chosen right before the the RETURN+ function and the RETURN current TV channel as the “Last Channel”. function.
  • Page 83 Remote control buttons and functions DISPLAY button COLOUR SYSTEM button You can display the PR LIST, programme The colour system is chosen automatically. number or VIDEO terminal number on the However, if the picture is not clear or no screen. colour appears, choose the colour system manually.
  • Page 84 Remote control buttons and functions BROADCASTING SYSTEMS Favorite channel For sound and colour systems in your registration country or region, refer to the table below: You can register your favorite TV channels COLOUR SYSTEM with the colour buttons (Red, Green, Yellow and Blue).
  • Page 85 Remote control buttons and functions Viewing a teletext • The picture effect dedicated for the colour button applies. For details, see programme “Setting the picture effect” below: 1 Choose a TV channel with a teletext Setting the picture effect broadcast. Each colour button has a dedicated picture 2 Press the TV/TEXT button.
  • Page 86 Remote control buttons and functions (Hold) button 3 Press the (Cancel) button to return to a teletext page when the You can hold a teletext page on the screen page number is on the screen. for as long as you want, even while several •...
  • Page 87 Remote control buttons and functions Twin and PIP (picture in Using the List mode You can store the numbers of your favorite picture) function teletext pages in memory and call them up [Except HV-29WH24] quickly using the colour buttons. You can display two different pictures, the To store the page numbers: main picture and sub picture, at a time.
  • Page 88 Remote control buttons and functions • When you exit the Twin or PIP mode, For the sub picture: the sub picture lastly displayed will be Press the (Input) button. saved, and it will appear next time. Each time you press the button, the input •...
  • Page 89 Remote control buttons and functions Multi-display function in the Multi-display mode. • If you press the MULTI button when [Except HV-29WH24] receiving the Progressive video signal You can watch nine different TV (525P or 625P signal), "525P" or programmes at a time. As you can display “625P”...
  • Page 90 Remote control buttons and functions Freeze function Strobe function [Except HV-29WH24] [Except HV-29WH24] While watching a picture, you can capture a You can display eight consecutive still still picture you want. The captured still pictures and one moving picture at a time. picture and the moving picture are (They are the pictures of the same source.) displayed at a time.

  • Page 91: Using The Tv's Menu

    Using the TV’s menu This TV has a number of functions you can operate using menus. To fully utilize all your TV’s functions, you need to understand the basic menu operating techniques fully. • The following remote control is for HV-29VH74. However, the buttons used for setting TV menus are common to all models.

  • Page 92: Picture Setting Menu

    Using the TV’s menu PICTURE SETTING menu 4 Press the 5 buttons to choose the setting of that function. • If you want to operate a function which appears only with its name, follow the descriptions of that function on the following pages.

  • Page 93: Picture Features Menu

    Using the TV’s menu PICTURE FEATURES menu COLOUR You can adjust the picture colour. 2 : lighter 3 : deeper TINT You can adjust the picture tint. 2 : reddish 3 : greenish • You can change the TINT setting (picture tint) only when the colour system is NTSC 3.58 or NTSC 4.43.
  • Page 94 Using the TV’s menu DigiPure MIN: The level of the DigiPure effect is set to the The Digipure function uses the latest in minimum. When you set the DigiPure digital technology to give you a natural function to AUTO and notice some noise, looking picture.
  • Page 95 Using the TV’s menu COLOUR SYSTEM ZOOM The colour system is chosen automatically. You can change the screen size according However, if the picture is not clear or no to the picture aspect ratio. Choose the colour appears, choose the colour system optimum one from three ZOOM modes.
  • Page 96 Using the TV’s menu FAVORITE CH SETTING • For details of each item, see “PICTURE MODE” on page 20, You can set a dedicated picture effect for “DIGITAL VNR” on page 21, “WHITE the favorite channels registered to the BALANCE” on page 21, “DigiPure” on colour buttons (Red, Green, Yellow and page 22.

  • Page 97: Sound Setting Menu

    Using the TV’s menu SOUND SETTING menu 3 Set the picture effect. Press the 6 button to choose an item listed in the following table and press the 5 button to choose one of options. • As explained in the table, the PICTURE EFFECT for the video inputs is set to OFF when shipped.

  • Page 98: Features Menu

    Using the TV’s menu FEATURES menu BALANCE You can adjust the volume balance between the left and right speakers. 2 : turn the left speaker’s volume level up. 3 : turn the right speaker’s volume level up. AI VOLUME You can prevent the sudden increase or decrease of sound that occurs when changing the channel to another channel or SLEEP TIMER...
  • Page 99 Using the TV’s menu BLUE BACK 2 Set the ID number you want. You can set the TV to automatically change To choose a number: to a blue screen and mute the sound if the Press the 6 buttons. signal is weak or absent, or when there is To move a cursor: no input from an external device.
  • Page 100 Using the TV’s menu 2 Press the DISPLAY button to display This Television is compatible with the “ID NO.” (ID number input screen). Progressive video signal (525P signal and 625P signal) only when the component video signal is input. [Except HV-29WH24] 3 Press the number buttons to enter the ID number.

  • Page 101: Install Menu

    Using the TV’s menu INSTALL menu • To stop the AUTO PROGRAM function, press the MENU/OK button. LANGUAGE 2 After the TV channels have been stored in the programme number list, You can choose the language you want to the EDIT menu appears. use for the on-screen display from the language list in a menu.
  • Page 102 Using the TV’s menu EDIT/MANUAL INSERT: This function adds a new TV channel in The EDIT/MANUAL functions are divided the current programme numbers list by into two types: editing of the current using the CH/CC number. programme numbers (EDIT functions) and DELETE: manual registration of a TV channel you This function deletes an unnecessary TV...
  • Page 103 Using the TV’s menu 1 Press the 6 buttons to choose a TV channel. 2 Press the red button to start the ID function. 3 Enter a channel name (ID). Press the 6 buttons to choose a character. Press the 5buttons to move the cursor.
  • Page 104 Using the TV’s menu INSERT Preparation: • Find the CH/CC number corresponding to the channel number of the TV channel from page 33. 1 Press the 6 buttons to choose a programme number for which you will register a new TV channel. •...
  • Page 105 Using the TV’s menu CH/CC number When you want to use the INSERT function on page 32, find the CH/CC number corresponding to the Channel number of the TV channel from this table. US: The US channel numbers are the channel numbers used in the United States, Philippines, etc.
  • Page 106 Using the TV’s menu TELETEXT LANGUAGE 3 Press the MENU/OK button to complete the setting. There are five types of teletext language The menu disappears. groups. Set the teletext language group that • Languages that are not included in the corresponds to the language of the teletext teletext language group that you program that you want to watch.

  • Page 107: Additional Preparation

    Additional preparation Connecting the external devices Connect the devices to the TV, paying HV-29VH73 HV-29VH74 HV-29WH24 attention to the following connection diagram. Before connecting anything: • Read the manuals provided with the devices. Depending on the devices, the connection method may differ from the figure.
  • Page 108 Additional preparation Connecting methods • In the VIDEO-4 terminal, the VIDEO jack is indicated by “V”. 1 Connect the TV’s VIDEO jack and the device’s VIDEO OUT (video output) 2 Connect the TV’s AUDIO jacks (L/ jack with a video cable. MONO and R) and the device’s AUDIO If connecting a device to the TV with an OUT (audio L/R output) jacks with an...

  • Page 109: Troubleshooting

    Troubleshooting If a problem arises while you are using the TV, please read this “Troubleshooting” well before you request having the TV repaired. You may be able to fix it easily by yourself. For example, if the AC plug is disconnected from the AC outlet, or the TV aerial has problems, you may think there is a problem with the TV itself.
  • Page 110 Troubleshooting • When a white and bright still image • When you are viewing a teletext (such as a white dress) is displayed on programme, you cannot operate the the screen, the white part may look as menus. if it were coloured. Press the TV/TEXT button to return the It is a phenomenon unavoidable due to teletext programme to the ordinary TV...
  • Page 111 Troubleshooting shielded speaker instead. • A picture may be tilted due to the influence of the earth’s magnetism. In this case, use the “PICTURE TILT” on page 23 to complete the tilt. • It takes a short period of time from the time an operation such as changing channels is performed until an image is displayed.

  • Page 112: Specification

    Specifications Broadcasting systems B, G, I, D, K, K1, M Colour systems PAL, SECAM, NTSC3.58/4.43MHz Channels and frequencies VHF low channel (VL) =46.25 to 168.25 MHz VHF high channel (VH) =175.25 to 463.25 MHz UHF channel (U) =471.25 to 863.25 MHz •...
