- Page 1 Itona TC15yy Hardware User’s Guide VXL Instruments Ltd, NO.17, House of Excellence, Electronics City, Hosur Road, Bangalore – 560 100, INDIA www.vxl.net...
- Page 2 Itona TC15yy VXL Instruments Ltd Hardware User’s Guide Copyright and Trademark notices ALL RIGHTS RESERVED. Information in this document is subject to change without notice and does not represent a commitment on the part of the manufacturer. No part of this guide may be reproduced or transmitted in any form or means, electronic or mechanical, including photocopying and recording, for any purpose, without the express written permission of the manufacturer.
- Page 3 Itona TC15yy VXL Instruments Ltd Hardware User’s Guide Federal Communication Commission (FCC) Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 4 Itona TC15yy VXL Instruments Ltd Hardware User’s Guide Preface Thank you for purchasing the Itona TC15yy Series Thin Client. This guide contains information to setup and use the hardware of Itona TC15yy Series. The guide consists of the following chapters: •...
-
Page 5: Table Of Contents
Itona TC15yy VXL Instruments Ltd Hardware User’s Guide Table of Contents Introduction ............................6 Overview................................6 Features ................................7 Optional Features ................Error! Bookmark not defined. Installation............................8 Step One: Unpack ............................8 Step Two: Prepare............................8 Step Three: Connect accessories and power ....................9 Caution: ...............................10 Step Four: Connect to the Server........................11... -
Page 6: Introduction
2 USB Port Itona TC15yy Itona TC15yy Series deliver smart and robust solutions for Thin Client computing. They are aesthetically and ergonomically designed compact desktop, providing simultaneous full screen connectivity to Windows and UNIX application servers – a powerful business alternative to users using Win32 applications while continuing access to legacy UNIX applications. -
Page 7: Features
Itona TC15yy VXL Instruments Ltd Hardware User’s Guide Features The product is equipped with a 10/100/1000 Ethernet port that gives an instant connection to a multi- user Windows NT application server. Also provided video display port. USB compatible keyboard/Mouse ports are available for quick setup and use. -
Page 8: Installation
NSURE THAT THE POWER INLET PLUG IS PROPERLY REGULATED AND EARTHED FLOATING GROUND CHASSIS COULD CAUSE AN ELECTRIC SHOCK • Fix the pedestals at the bottom of the Itona TC15yy. • Well ventilated, clean, dry and dust free atmosphere • Specified environmental conditions (refer to the section on specifications ) •... -
Page 9: Step Three: Connect Accessories And Power
Itona TC15yy VXL Instruments Ltd Hardware User’s Guide Step Three: Connect accessories and power EFORE CONNECTING ANY CABLES ENSURE POWER CABLE IS UNPLUGED FROM THE UNIT. PLEASE 250V AC 0.75 sq mm, H05VV-F C USE 6A (MIN) / ERTIFIED POWER CORD. -
Page 10: Caution
Itona TC15yy VXL Instruments Ltd Hardware User’s Guide The table below identifies the devices to be used with each connector of the client. Instructions to connect various accessories Connector Symbol Connect the video cable from your display unit to the video port... -
Page 11: Step Four: Connect To The Server
ICA Server Press the power button to power up the Itona TC15yy. The front panel LED lights up and the client boots up with a BEEP sound and takes you to the Connection Manager screen. Refer to the Software User’s Guide for configuring the client. -
Page 12: Specifications
Itona TC15YY VXL Instruments Ltd Hardware User’s Guide Specifications Hardware • Processor: VIA C7 / TC1000 • VGA Memory: Shared Video Memory 32MB min • Flash : IDE 44Pin / 90D • RAM: DDR2 SO DIMM • Networking 10/100/1000 Mbps •... -
Page 13: Connectors
Itona TC15YY VXL Instruments Ltd Hardware User’s Guide Connectors and Cables Connectors The following tables provide pin details for various connectors on the rear panel of the client. 10/100/1000 LAN Port RJ-45 modular 8-pin jack. 10/100/1000 Mbps Signal TxD+ TxD-... -
Page 14: Cables
Itona TC15YY VXL Instruments Ltd Hardware User’s Guide Cables 10/100/1000 LAN Cable Cross Connection - (Without Hub) RJ45 RJ45 TXD+ 1 3 RXD+ TXD- 2 6 RXD- 1 TXD+ RXD+ 3 RXD- 6 2 TXD- Straight Connection - (With Hub) -
Page 15: Troubleshooting
Itona TC15YY VXL Instruments Ltd Hardware User’s Guide Troubleshooting This chapter contains solutions for problems you may encounter while using the product. Problem Solution • Ensure that the power cord is plugged into an AC outlet. The Power-LED on front panel does not glow when Check the fuse in the power-plug, if available.
