Major Assembly
The Comtech EF Data Digicast Media Router CMR-5995 (CMR-5995) is available in
a standalone configuration. The following table lists the components provided with a
standard configuration. In the event any listed item is missing, please contact Comtech
EF Data Customer Support.
Digicast Media Router CMR-5995 Standalone Configuration
Installation
The CMR-5995 is designed for ease of installation and configuration. Once the unit
has been removed from the packing container, please follow these instructions:
Step
Procedure
1
Place the unit on a flat surface with free airflow, where the LEDs can be clearly
observed and with unrestricted access to the rear panel of the unit.
2
Until the unit has been fully configured, the coaxial connection to the Low Noise
Block (LNB) should NOT be connected to the unit . If the unit will not be powering
the LNB, it is recommended that 'Polarity' (on the 'Tuner' configuration page) be
set to 'Off'
3
Connect the DC power connection from the SPU30-102 (external power supply) to
the connection labeled PWR on the back of the unit and tighten the restraining nut
to ensure secure operation.
4
Connect an RJ-45 Ethernet cable (patch cord) to the port labeled ETHERNET and
to an Ethernet concentrator (hub) or switch.
5
Connect a terminal cable P/N CA-TERMINAL (supplied) to the port labeled TERM
and to a PC's serial port (DB-9), to initially configure the CMR-5995.
6
Connect the AC power (via the IEC power cord) between a standard wall outlet
and the power supply. The Blue LED will illuminate.
7
Upon startup, the LEDs on the front panel may illuminate as follows:
Color
Blue
Green
Red
Green
Green
Amber
Green
Green
Green
Copyright © 2008 Comtech EF Data, 2114 West 7th Street, Tempe, Arizona 85281 USA. All rights reserved. Printed in the USA.
Quantity
Description
1
CMR-5995 [CMR-5995]
1
SPU30-102 Power Supply
1
IEC Power Cable
1
CA-TERMINAL Terminal Cable
1
Quick Start sheet
Label
PWR
Illuminates if power is properly applied
RED
Redundancy indicator
ALARM
May illuminate if the unit is not yet configured
LOCK
Illuminates if the tuner is locked
E-SPD
Ethernet speed indicator
E-COL
Ethernet collision indicator
E-RX
Flashes if there is Ethernet traffic/activity
E-TX
Illuminates if the Ethernet connection to the Hub/Switch
E-LINK
is operational
MN-CMR5995-QSG Revision 1
