ComforTrak Series Assembly Instructions EP-560, EP-860, EP-960 & EP-970 Models *Inversion Table images may vary slightly from your model. The EP-560 is shown here.
BEFORE YOU BEGIN: Review all steps before beginning assembly and read all precautions before using the inversion table. Carefully adhere to the Assembly Instructions and Owner’s Manual to help ensure safety and product integrity. IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THE INVERSION TABLE. WARNING WARNING - To reduce the risk of injury to persons: equipment before using the inversion table.
Page 3
BEFORE YOU BEGIN: Review all steps before beginning assembly and read all precautions before using the inversion table. Carefully adhere to the Assembly Instructions and Owner’s Manual to help ensure safety and product integrity. IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THE INVERSION TABLE. WARNING DO NOT Owner’s Manual.
Items for Assembly ITEM NUMBER ITEMS FOR ASSEMBLY ITEMS FOR ASSEMBLY ITEM NUMBER ITEMS FOR ASSEMBLY ITEM NUMBER This column is ONLY for the Assembly of the A-Frame E6-1100 Handle Assembly Main Shaft with T-Pin Ankle Lock System (E6-1600) Angle Tether F5-1007 Strech Assist Handles (2)
BEFORE BEGINNING the important components of your new Teeter Hang Ups ® inversion table. Head Pillow Angle Tether Bed Frame Extension Crossbar ComforTrak™ Table Bed A-Frame 3-Hole Roller Hinges Main Shaft Handles Ankle Lock System Height-Selector Locking Pin Ankle Comfort Dial™ Spreader Arms Stability Feet What Model Do You Own?
WARNING LABEL PLACEMENT Important: Please review all labels and supporting materials before using your inversion table. This drawing indicates the locations of the warning labels found on your product. contact Customer Service at the phone number or website found at the bottom of this page to request a complimentary replacement label.
Page 8
Step FIGURE 1 Assemble the front Stability Feet (F7-1033) onto the A-Frame (E6-1100) Feet may come pre-assembled. the front Stability Feet. FIGURE 2 bottom (Figure 2). Tighten using the Screwdriver (F5-1130) provided. refer back to this diagram for reference throughout the assembly process. FIGURE 3 Right Left...
Page 9
Step EP-560, EP-560 Sport & EP-560 Limited Models FIGURE 4 Depending on the model you have purchased, the items in this step will vary. See “Which Model Do you Own?” (page 4) for more information. Assemble the Handles to the Table Bed (EP-1300) FIGURE 4A Bolts/Nuts may come pre-assembled in the Handles.
Page 10
Step (continued) FIGURE 5 Assemble the Handles to the Table Bed (EP-1300) Bolts/Nuts may come pre-assembled in the Handles. Simply unscrew to remove. EP-860, EP-960 & EP-970: Assemble the Stretch Max Handles (E6-1520) EP-860, EP-960, EP-970 Models FIGURE 6 keep one of the Washers. to Figure 6).
Page 11
Step 3 FIGURE 7 Depending on the model you have purchased, the items in this step will vary. See “Which Model Do you Own?” (page 4) for more information. EP-560 models & EP-860: Complete this step. EP-560 Sport: Complete this step to use the standard Ankle Lock System. To use with the EZ-Up Gravity Boots refer to either the ComforTrak DVD or the insert that can be found with the Conversio Bar.
Page 12
Step (continued) FIGURE 8 Install the Rear Ankle Bar Assembly (IA-1113) into the large hole at the back of the Main Shaft (Figure 8). 1 Ridge 2 Ridges FIGURE 8A end of the Rear Ankle Bar (Figure 8A). TIP: To assist with assembly, repeatedly rotate the Heel Cup while pushing it onto the Rear Ankle Bar.
Page 13
Step (continued) FIGURE 10 Install the Front Ankle Bar Assembly Housing (Figure 10). Pull up on the T-Pin Lock to allow the Front Ankle Bar to insert all the way into the housing. Release the T-Pin to engage in the hole setting closest to the Front Ankle Cups.
Page 14
Step 4 FIGURE 12 Assemble the Table Bed (E6-1300) and Bed Frame Extension (E6-1380) NOTE: This assembly will be referred to as Table Bed (E6-1300) for the remainder of the Assembly Instructions. ComforTrak™ Bed - Upper Portion (E6-1300A) ComforTrak™ Bed Frame (E6-1300) Bed Frame Extension (E6-1380) Bolts &...
Page 15
Step 5 FIGURE 15 Depending on the model you have purchased, the items in this step will vary. See “Which Model Do you Own?” (page 4) for more information. Assemble the Roller Hinges to the Table Bed (EP-1300) EP-560, EP-560 Ltd. & EP-860: Use 3-Hole Roller Hinges (F5-1064) EP-560 Sport, EP-950 &...
Page 16
Step 6 FIGURE 19 Attach the Table Bed (E6-1300) to the A-Frame (E6-1100) A-Frame where the Crossbar is located (refer to Figure 3 to determine A-Frame Front). NOTE: You may need to push outward on the A-Frame in order for the 2nd Pivot Pin FIGURE 19A to lock in place.
Page 17
Step 7 FIGURE 21 Depending on the model you have purchased, the items in this step will vary. See “Which Model Do you Own?” (page 4) for more information. Insert the Main Shaft into the Table Bed EP-560 and EP-860 models will use the Main Shaft with T-Pin Ankle Lock System (E6-1600) EP-960 model will use the EZ-Reach Ratchet Ankle Lock System (E6-1630) EP-970 model will use the Deluxe EZ-Reach Ratchet Ankle Lock System (NX-1630B) Main Shaft...
Page 18
WARNING Improper assembly could result in serious injury or death! Image B Image A Go back to Step 6 for instruction. Go back to Step 5 for instruction Demonstrates that the Table Bed has been assembled Demonstrates that the Roller Hinges have been assembled into the A-Frame backwards and must be corrected.
Page 19
Step 8 FIGURE 23 Depending on the model you have purchased, the items in this step will vary. See “Which Model Do you Own?” (page 4) for more information. Assemble the Tether to the Table Bed (EP-1300) EP-560 & EP-560 Sport: use the Angle Tether (F5-1007) EP-860, EP-960 &...
Page 20
Step 9 FIGURE 24 Attach the Head Pillow (EP-1105) (Figure 24). The position of the pillow can be adjusted depending on the user. Attach the Owner’s Maunal The Owner’s Manual contains important information on how to use your Teeter Hang Ups, including how to personalize the user settings, properly secure and release the Ankle Lock System, and test and adjust the rotation control.
Page 21
Adjusting the Roller Hinge Setting FIGURE 26 Adjustments: Changing the Roller Hinge Setting To adjust the Roller Hinge setting, you’ll need to fully remove the Table Bed from the A-Frame. hole setting. the Crossbar of the A-Frame (Figure 26). FIGURE 27 the Self-Locking Hooks over the Pivot Pin (Figure 27).
Maintenance/ Storage FIGURE 29 Maintenance cleaners or solvents. Storage last hole setting. the Crossbar of the A-Frame. legs open to a width of 12” for stability. NOTE: This operation may pinch fingers if not done slowly and carefully. WARNING...
