Hang ups EZ Stretch F5-1124 User Instructions

Traction handles

Advertisement

EZ Stretch
EZ Stretch
EZ Stretch
EZ Stretch
EZ Stretch
Teeter Hang Ups
®
decompression. DO NOT use if you are not comfortable with the stretch achieved during regular inversion.
DO NOT use until you have reviewed all accompanying documents regarding your table and Traction Handles.

PRE-ASSEMBLY

IMPORTANT: The EZ Stretch
and are designed to add stretching and decompression benefits to inversion. It is recommended that you first become
comfortable using the inversion table as instructed in the Owner's Manual before attempting to utilize the Traction Handles.
This accessory will not interfere with the normal operation of the table.
Note: If your inversion table roller hinges have not been pre-drilled for Traction Handle installation, you may purchase a
Traction Handle Adapter Kit, which comes complete with a set of handles and a set of Roller Hinges.
BEFORE STARTING to assemble your EZ Stretch
Traction Handles, remove all the individual parts from
the carton. You should have the following items:
ITEMS FOR ASSEMBLY
Traction Handles w/ Derattler Screw
Bolt Caps (2)
Screwdriver

ASSEMBLY

TM
EZ Stretch
Traction Handles are designed with a diagonal off-set to accommodate various arm lengths and desired traction
intensity. The handles can be positioned within closer reach to accommodate users with shorter arms or those who desire greater
traction. For users with longer arms or those who want less of a stretch, the handles can be reversed so that they are positioned
a greater distance from the shoulders. Refer to the drawings on the left side of the page if you desire a greater stretch or have
shorter arms; follow the right side if you have longer arms or desire a lesser stretch.
Figure 1A
Roller Hinge Bolt
Figure 2A
De-rattler
Screw
Figure 3A
For information about the Teeter
Hang Ups
5-year warranty, or if you
®
have any problems assembling the
equipment or questions about its use,
please contact Customer Service at
the appropriate location:
Teeter Hang Ups
is a registered trademark of STL International, Inc., Inversion International, Ltd. and Teeter Ltd. © COPYRIGHT 2006, STL International, Inc., Inversion International, Ltd. Teeter Ltd. Item #LF-7017 09/06-1
®
USER INSTRUCTIONS
TM
TM
TM
TM
TM
!
EZ Stretch
TM
Traction Handles are designed for the advanced user to achieve maximum
Improper use can result in serious injury or death!
TM
Traction Handles are an optional accessory to be used with Teeter Hang Ups
ITEM #'S
F5-1124
F5-1126
F5-1130
• Use the Screwdriver (F5-1130) to remove the Roller
Hinge Screw from the left Roller Hinge Bolt (See
Figure 1 or 1B). Do not discard! You will need this
part to assemble the Traction Handle.
• Place the bracket of the handle over the top of the
Roller Hinge Bolt, making sure that the bolt fits inside
of the hole in the handle bracket. The handle should
point away from the table. (See Figure 2A or 2B)
• Place the Bolt Cap (F5-1126) over the Roller Hinge
Bolt.
Traction
Handle
• Reinsert the Roller Hinge Screw into the pre-drilled
offset
hole on the Roller Hinge Bolt and tighten using the
UP
Screwdriver.
• Tighten the De-rattler Screw. (See Figure 3A or 3B)
Only tighten the screw until the Traction Handle is
reduced of excess movement. Part of the screw may
still protrude from the Traction Handle.
• Repeat on the opposite side.
USA & Canada:
STL International, Inc.
nd
9902 162
St. Ct. E.
Puyallup, WA 98375
(Phone) 253-840-5252,
(Fax) 253-840-5757
(email) Info@STLIntl.com
(web) www.STLIntl.com
DO NOT DISCARD - KEEP FOR FUTURE REFERENCE.
Traction Handles
Traction Handles
Traction Handles
Traction Handles
Traction Handles
WARNING
TM
F5-1124
International:
Inversion International, Ltd.
PO Box: AP 59245
New Providence Island, Bahamas
(Phone) +1-242-362-1001
(Fax) +1-242-362-1002
(email) Info@InversionInternational.com
(web) www.InversionInternational.com
for Teeter Hang Ups
De-rattler Screws
Roller Hinge Bolt
De-rattler
Screw
Europe:
Teeter Ltd.
Cygnet House, Sydenham Road
Croydon, Surrey CR0 2EE, UK
(Phone) +44-20-8667-0060
(Fax) +44-20-8680-3999
(email) mail@TeeterLtd.com
(web) www.TeeterLtd.com
Inversion Tables
®
Inversion Tables
®
F5-1126
F5-1130
Figure 1B
Figure 2B
Traction
Handle
offset
DOWN
Figure 3B
