Hang ups SR 250 Assembly Instructions Manual

Inversion table

Advertisement

Quick Links

R
SR
250
Inversion Table Assembly Instructions
2
YEAR

Advertisement

loading
Need help?

Need help?

Do you have a question about the SR 250 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hang ups SR 250

  • Page 1 ™ Inversion Table Assembly Instructions YEAR...
  • Page 2: Important Safety Instructions

    BEFORE YOU BEGIN: Review all steps before beginning assembly and read all precautions before using the inversion table. Carefully adhere to the Assembly Instructions and Owner’s Manual to help ensure safety and product integrity. IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THE INVERSION TABLE. WARNING WARNING - To reduce the risk of injury to persons: •...
  • Page 3: Items For Assembly

    Items for Assembly Items are not shown to scale. If you have any questions on assembly, contact Customer Service at 1-800-847-0143 or visit our website at teeter-inversion.com. ITEMS FOR ASSEMBLY ITEM NUMBER ITEMS FOR ASSEMBLY ITEM NUMBER ITEMS FOR ASSEMBLY ITEM NUMBER A-Frame FF-1100...
  • Page 4: Before Beginning

    Before Beginning Before reading further, study the drawing below to familiarize yourself with the important components of your new Teeter Hang Ups ® inversion table. Table Bed Handles 3-Hole Roller Hinge Hinge Cover Height-Selector Locking Pin Spreader Arm Main Shaft...
  • Page 5 Step 1 Figure 1 Right Left Open the A-Frame (FF-1100) • Open the A-Frame on the floor and make sure the Spreader Arms are locked open (Figure 1). • Familiarize yourself with the Front, Back, Left and Right of the A-Frame. You may want to refer back to this diagram throughout the assembly process.
  • Page 6 Step 3 Figure 6 Attach the Table Bed (F2-1130) to the A-Frame (FF-1100) • Pick up the Table Bed, holding each side near the Roller Hinges, and stand in front of the A-Frame where the Crossbar is located (refer to Figure 1 to determine A-Frame Front). •...
  • Page 7 Step 4 Figure 8 Assemble the T-Pin Ankle Lock System onto the Main Shaft (F1-1600) Install the Ankle Comfort Dial • Slide the Ankle Comfort Dial (IA-1119) with pre-assembled Ankle Comfort Dial into the hole at the front base of the Main Shaft (Figure 8). •...
  • Page 8 Step 4 (continued) Figure 13 Install the Front Ankle Bar • Insert the Front Ankle Bar (EP-1045B) into the Front Ankle Bar Housing (Figure 13). Pull up on the T-Pin Lock to insert the Front Ankle Bar all the way and release in the shortest setting (the hole closest to the Front Ankle Bar). •...
  • Page 9 Step 5 Figure 16 Insert the Main Shaft (F1-1600) into the Table Bed • With the Height Adjustment Settings on the Main Shaft facing up, slide the end of the Main Shaft into the Main Shaft Housing (Figure 16) on the Table Bed. •...
  • Page 10 Step 6 Figure 18 Assemble the Handles (FF-1140) onto the A-Frame (FF-1100) Bolts/Nuts may come pre-assembled in the Handles. Simply unscrew to remove. • Insert the Handles (FF-1140) into the A-Frame (Figure 18). • From the rear of the A-Frame, insert the Chicago Nut (IA-1148) through the corresponding 1/4” hole, located on the Handle Housing (Figure 19).
  • Page 11 • For your reference, the serial number can be found on the back of the Table Bed. WARNING Read the Owner’s Manual thoroughly before using your Teeter Hang Ups Inversion Table. Improper settings could result in serious injury or death!
  • Page 12 Adjustments / Maintenance / Storage Figure 22 Adjustments: Changing the Roller Hinge Setting To adjust the Roller Hinge setting, you’ll need to fully remove the Table Bed from the A-Frame. • Pull the Height-Selector Locking Pin and slide the Main Shaft in all the way. •...
  • Page 13 30175 Hannover, Germany the UL Listing. U.S. and Foreign Patents Pending. Teeter Hang Ups is a registered trademark of Teeter. Specifi cations subject to change without notice. © COPYRIGHT 2011 Teeter. International Law Prohibits Any Copying...
