CARE AND MAINTENANCE

Cleaning the Lower front panel and Air Filter:

If the air filter becomes clogged, the performance will decrease and electricity will be wasted.
The air filter should be checked and cleaned about once every 2 weeks to maintain optimal
performance of the air conditioner.
1. The air filter is located under the lower front panel (see figure above).
2. First take down the screw cover on both side of the panel, then remove the screws using the
screwdriver.
3. Hold both side of the panel and pull it downwards, then take it down.
4. Take hold of the air filter holder and pull it up, and then take it out.
3. The lower front panel can be wiped with water or a cloth dipped water. Wash it with water and dry it in
a cool place.
4. Use a vacuum cleaner to remove the dust or wash the air filter with water, and dry it in the shadow.
5. Installation process of the air filter and lower front panel is the reverse of the removal process.
CAUTION:
Make sure nothing has been forgotten or fallen into the fan before installing the lower front panel.
Restart the unit after the front panel and the air filter are correctly installed.
Before long time idleness
1. Clean the indoor unit and air filter.
2. Dry the inner parts by keeping the fan running for half a day.
3. Turn off the unit and switch off the power switch, remove the batteries from the remote control.
4. Periodically check and clean the inner parts of the outdoor unit. Our local dealer will help you
handle this if you contact us.
After long time idleness
Before restarting, please check if the air inlet and air outlet of the indoor and outdoor units are
blocked up. Clean it so.
Aftersales
If the air conditioner operate abnormally, turn off the unit and switch off the power supply, and
contact the local dealer or service centre.
Air Filter
