Airflow Direction Control

Horizontal Airflow Direction(AUTO)
The Left/Right(Horizontal Airflow) can be adjusted
by using the remote control or unit control.
Press the"AUXILIARY FUNCTION" button on the
unit control panel, then press the ADJUST
button to select the
ouvers will swing left and right. Repeat the above
procedures to stop the swing operation.
Never touch the vertical louvers by hand.
Vertical Airflow Direction(MANUAL)
The Up/Down(Verticall Airflow) air flow can be
adjusted by horizontal louvers. Hold the edge
of the horizontal louver and move it up or down
to set the desired air flow direction.
Note:
The starting angle of the horizontal louver should not be too small, otherwise the
narrow air outlet will affect cooling or heating efficiency.
Do not set the starting angle of the louvers too small during cooling or drying operation.
Otherwise, condensation may occur on the surface of the horizontal louver and cause
dew dripping.
During the operation, if the louvers can not swing normally, shut off the unit and unplug
for several minutes, then plug it again and restart the operation.
The horizontal louver may slightly vibrate during the operation. This is normal.
and
feature and the
10
OPERATING INSTRUCTIONS
